Feature
|
Description
|
|
Form Factor
|
Single-wide GRWIC, no slot restrictions
|
|
Dimensions (W x H x D)
|
3.25 x 2.0 x 8.5 in
|
|
Weight
|
0.9 lb (0.4 kg)
|
|
LEDs
|
• Network module status indicator
• Status LEDs for each B Channel
• Status LED for NT1
|
|
Ports
|
Single RJ-45 port
|
|
Environmental Specifications
|
|
Operating Conditions
|
|
Operating Temperature
|
32º F to 104º F (0 to +40º C) continuous operating temperature range
|
|
Shock and Vibration
|
30 G @11 ms
|
|
Altitude
|
10,000 ft (3,048 m); maximum operating temperature is de-rated with increasing altitude per
IEEE1613a-2008
|
|
Relative Humidity
|
5 to 85 percent non-condensing
|
|
Non-Operating Conditions
|
|
Temperature
|
32º F to 104º F (0º C to40º C)
|
|
Relative Humidity
|
5 to 85 percent non-condensing
|
|
Altitude
|
10,000 ft (3,048 m); maximum operating temperature is de-rated with increasing altitude per
IEEE1613a-2008
|
|
Non-Operating Free-Fall Drop
|
4 in. (100 mm) per ENG-339611
|
|
Operating Seismic Earthquake
|
IEC 61850-3 section 5.5
|
|
Non-Operating Shock and Vibration
|
40-50G (3.26 m/s minimum)
|
|
Immunity
|
• EN61000-6-2
• EN61000-4-2 (ESD)
• EN61000-4-3 (RF)
• EN61000-4-4 (EFT)
• EN61000-4-5 (SURGE)
• EN61000-4-6 (CRF)
• EN61000-4-11 (VDI)
• EN 55024, CISPR 24
• EN50082-1
|
|
Telecom Compliance
|
• US: TIA-968-A
• CA: CS-03
• EU: TBR1, 2, 4, 12, 13
• RTTE Directive
• Australia: AS/ASIF S016, S038
• Japan: JATE
|
|
Safety
|
• USA: UL 60950-1
• Canada: CAN/CSA C22.2 No. 60950-1
• Europe: EN 60950-1
• China: GB 60950-1
• Australia/New Zealand: AS/NZS 60950-1
• Rest of World: IEC 60950-1
• CSA certified to UL/CSA 60950-1, 2nd Ed.
• CB report to IEC60950-1, 2nd Ed., covering all group differences and national deviations
|
|
Electromagnetic Compliance
|
• 47 CFR, Part 15
• ICES-003 Class A
• EN55022 Class A
• CISPR22 Class A
• AS/NZS 3548 Class A
• VCCI V-3
• CNS 13438
• EN 300-386
|
