| Name |
WA6526 |
| Weight |
1.05 kg |
| Dimensions (H × W × D) |
35 × 185 × 155 mm (1.38 × 7.28 × 6.10 in) |
| Uplink Ethernet ports |
Port 1: 100/1000M/2.5G, RJ-45 |
| Port 2: 100/1000M, RJ-45 |
| PoE+ |
Port 1: 802.3bt/at |
| Port 2: 802.3at |
| Both ethernet ports support PoE and they can work simultaneously |
| Local power supply |
54 VDC |
| Passive Power over Ethernet (48V) |
Supported |
| Console port |
One (RJ-45) |
| USB port |
One |
| Built-in antenna |
Built-in omni-directional antenna |
| 4dBi antenna gain @2.4GHz |
| 4dBi antenna gain @5GHz |
| Built-in Bluetooth |
Supported (Support to switch RFID through software) |
| Working frequencies |
802.11ax/ac/n/a: 5.725 to 5.850 GHz; 5.47 to 5.725 GHz; 5.15 to 5.35 GHz |
| 802.11ax/b/g/n: 2.4 to 2.483 GHz |
| Modulation technology |
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps |
| DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps (file://dbpsk@1mbps, dqpsk@2mbps, cck@5.5/11Mbps) |
| MIMO-OFDM (11n): MCS 0-31 |
| MIMO-OFDM (11ac): MCS 0-9 |
| MIMO-OFDM (11ax): MCS 0-11 |
| Modulation mode |
11b: DSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps |
| 11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps |
| 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM |
| 11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM |
| 11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM |
| Maximum transmit power |
2.4G: 25dBm, 5G: 26 dBm (Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations) |
| Adjustable power granularity |
1 dBm |
| Reset/restoration to factory default |
Supported |
| State LED |
Alternating flashing mode, orange/green/blue for different working states, breathing mode |
| Temperature |
Operating temperature: -10°C to +55°C (32°F to 113°F) |
| Storage temperature: –40°C to +70°C (–40°F to +158°F) |
| Humidity |
Operating: 5% to 95% (non-condensing) |
| Storage: 5% to 95% (non-condensing) |
| Protection class |
IP42 |
| Overall power consumption |
≤ 17.6w (without USB function) |
| ≤ 20.1w (with USB function) |
| Safety compliance |
GB4943, EN60601-1-2 (medical electrical equipment), UL/CSA 60950-1, EN/IEC 60950-1, EN/IEC 60950-22 |
| EMC |
GB9254, EN301 489, EN55022, FCC Part 15, RSS-210 |
| Radio frequency certification |
FCC Part 15, EN 300 328, EN 301 893, and MIIT SRRC |
| Health |
FCC Bulletin OET-65C, EN 50385, IC Safety Code 6 |
| MTBF |
>850000H |
