H3C EWP-WA6628-FIT Access Point.

Name

WA6628

Weight

1.28 kg

Dimensions (H × W × D)

52 × 239 × 236 mm (2.05 × 9.41 × 9.29 in)

Uplink Ethernet ports

Port 1: 100/1000M/2.5G/5G/10G, RJ-45

Port 2: 100/1000M, RJ-45

PoE+

Port 1: 802.3bt/at

Port 2: 802.3at

Both ethernet ports support PoE and they can work simultaneously

Local power supply

54 VDC

Passive Power over Ethernet (48V)

Supported

Console port

One (RJ-45)

USB port

One

Built-in antenna

Built-in omni-directional antenna

3dBi antenna gain @2.4GHz

4dBi antenna gain @5GHz

Built-in Bluetooth

Supported (Support to switch RFID through software)

Working frequencies

802.11ax/ac/n/a: 5.725 to 5.850 GHz; 5.47 to 5.725 GHz; 5.15 to 5.35 GHz

802.11ax/b/g/n: 2.4 to 2.483 GHz

Modulation technology

OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps

DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps (file://dbpsk@1mbps, dqpsk@2mbps, cck@5.5/11Mbps)

MIMO-OFDM (11n): MCS 0-31

MIMO-OFDM (11ac): MCS 0-9

MIMO-OFDM (11ax): MCS 0-11

Modulation mode

11b: DSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps

11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps

11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM

11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM

11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM

Maximum transmit power

2.4G: 25dBm, 5G: 30 dBm (Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations)

Adjustable power granularity

1 dBm

Reset/restoration to factory default

Supported

State LED

Alternating flashing mode, orange/green/blue for different working states, breathing mode

Temperature

Operating temperature: -10°C to +55°C (32°F to 113°F)

Storage temperature: –40°C to +70°C (–40°F to +158°F)

Humidity

Operating: 5% to 95% (non-condensing)

Storage: 5% to 95% (non-condensing)

Protection class

IP42

Overall power consumption

< 30 W (excluding IoT modules and USB)

Safety compliance

GB4943, EN60601-1-2 (medical electrical equipment), UL/CSA 60950-1, EN/IEC 60950-1, EN/IEC 60950-22

EMC

GB9254, EN301 489, EN55022, FCC Part 15, RSS-210

Radio frequency certification

FCC Part 15, EN 300 328, EN 301 893, and MIIT SRRC

Health

FCC Bulletin OET-65C, EN 50385, IC Safety Code 6

MTBF

> 250000 hours
