| Features |
WA6628X |
| Weight(excluding mounting accessories) |
3.2kg |
| Dimensions(H×W×D, excluding mounting accessories) |
280mm×280mm×85mm |
| Fixed port |
1×100M/1000M Ethernet port, support IoT Expansion & PSE, 802.3af
2xSFP+
1×Console port (RJ45) |
| Antenna |
External antenna support 8xN type interface |
| Operating frequencies |
802.11ax/ac/n/a : 5.725GHz-5.850GHz; 5.47～5.725GHz; 5.15~5.35GHz
802.11ax/b/g/n : 2.4GHz-2.483GHz |
| Modulation |
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps
MIMO-OFDM (11n): MCS 0-31
MIMO-OFDM (11ac): MCS 0-9
MIMO-OFDM (11ax): MCS 0-11 |
| Modulation mode |
11b: DSS: CCK@5.5/11Mbps, DQPSK@2Mbps, DBPSK@1Mbps
11a/g: OFDM: 64QAM@48/54Mbps, 16QAM@24Mbps, QPSK@12/18Mbps, BPSK@6/9Mbps
11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM
11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM
11ax: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM |
| Maximum radio power |
2.4GHz: 30dBm
5GHz: 30dBm
(Transmit power is multi-chain combined power, no antenna gain is included. The actual transmit power depends on local laws and regulations) |
| Adjustable power |
1dBm |
| Power Source |
Local Power Supply(100-264V AC) |
| Power consumption |
≤52W(Including PSE) |
| Operating temperature/storage temperature |
Operating Tem: -30ºC～55ºC(Recommended); -40 ºC～65ºC ; Storage Tem: -40ºC～85ºC |
| Operating humidity/storage humidity |
0% to 100% (non-condensing) |
| Safety compliance |
GB494, EN/IEC/UL 60950-1, EN/IEC/UL 62386-1 |
| EMC |
EN301 489-1, EN301 489-17, EN50121-4:2016/IEC62236-4:2018，EN 50121-3-2-2006, GB/T 24338.4-2009, GB/T 24338.5-2009, GB/T9254-2008 |
| Radio frequency certification |
FCC Part 15, EN 300 328, EN 301 893 |
| Health |
FCC Bulletin OET-65C, EN 50385, IC Safety Code 6 |
| Protection degree |
IP67 |
| MTBF |
>850000 hours |
