Swittch HPE FlexNetwork 5940 48p 10GbE SFP/SFP+ and 6p 40/100GbE QSFP28 with 2 Fans 2 PS Switch Bundle
HPE Part Number : JH684A
Bảo hành : 12 tháng
Made In : China
Stock : Hàng có sẵn
Mô tả sản phẩm
Thiết bị chuyển mạch HPE JH684A được thiết kế để hoạt động phù hợp cả 3 lớp mạng (lớp truy nhập mạng đầu cuối) với chi phí đầu tư là thấp trong dòng HPE FlexFabric 5940 Switch Series.
Thiết bị chuyển mạch HPE JH684A tăng cường bảo mật bằng cách sử dụng các công nghệ virtual LANs, link aggregation, hoặc IGMP Snooping boost uplink performance, và loop prevention enhances network reliability. Switch HPE JH684A sử dụng điện AC 220V.
Thông số kỹ thuật chi tiết của thiết bị chuyển mạch HPE JH684A :
I/O ports and slots |
48 fixed 1000/10000 SFP+ ports
6 QSFP28 100GbE ports
|
Additional ports and slots |
1 RJ-45 serial console port
1 RJ-45 out-of-band management port 1 SFP GbE port
1 USB 2.0
1 Mini USB 2.0
|
Power supplies |
2 power supply slots
|
Fan tray |
2 fan tray slots
This system requires two same-direction airflow fan trays to function properly. The system should not be operated with only one fan tray for more than 24 hours. The system should not be operated without a fan tray for more than two minutes. The system should not be operated outside of the temperature range of 32°F (0°C) to 113°F (45°C). Failure to comply with these operating requirements may void the product warranty.
|
Physical characteristics |
Dimensions: 17.32(w) x 18.11(d) x 1.72(h) in (44 x 46 x 4.36 cm)
Weight: 24.25 lb (11 kg) shipping weight
|
Memory and processor |
1 GB flash; Packet buffer size: 12.2 MB, 4 GB SDRAM
|
Mounting and enclosure |
|
Performance |
10 Gbps Latency < 1 µs (64-byte packets)
ThrougHPEut up to 1607 Mpps
Switching capacity: 2160 Gbps
Routing table size 120000 entries (IPv4), 60000 entries (IPv6)
MAC address table size 288000 entries
|
Environment |
Operating temperature: 32°F to 113°F (0°C to 45°C)
Operating relative humidity: 10% to 90%, noncondensing
Nonoperating/Storage temperature:-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage relative humidity:5% to 95% @ 140°F (60°C)
Acoustic: Low-speed fan: 65.7 dB, High-speed fan: 70.6 dB
|
Electrical characteristics |
Frequency: 50/60 Hz
Maximum heat dissipation 87 BTU/hr (935.79 kJ/hr)
Voltage:
100 - 240 VAC, rated-40 to -60 VDC, rated
(depending on power supply chosen)
Maximum power rating: 196 W W
Idle power is the actual power consumption of the device with no ports connected.
Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.
|
Safety |
UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products- Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR Subchapter J; NOM; ROHS Compliance
|
Emissions |
VCCI Class A; EN 55022 Class A; ICES-003 Class A; ANSI C63.4 2003; AS/NZS CISPR 22 Class A; EN 61000-3-2:2006; EN 61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A; ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED)
|
Management |
IIMC - Intelligent Management Center; Command-line interface; Out-of-band management; SNMP manager; Telnet; FTP |
Các loại Module quang HPE được sử dụng cho switch HPE JH684A :
JD093B HPE X130 10G SFP+ LC LRM Transceiver
JD092B HPE X130 10G SFP+ LC SR Transceiver
JD094B HPE X130 10G SFP+ LC LR Transceiver
JG234A HPE X130 10G SFP+ LC ER 40km Transceiver
JL250A HPE X130 10G SFP+ LC LH80 tunable Transceiver
JH673A HPE X150 100G QSFP28 CWDM4 2km SM Transceiver
JH419A HPE X150 100G QSFP28 LC SWDM4 100m MM Transceiver
JH682A HPE X150 100G QSFP28 MPO SR4 100m MM Campus-Transceiver
JH683A HPE X150 100G QSFP28 LC LR4 10km SM Campus-Transceiver
JD061A HPE X125 1G SFP LC LH40 1310nm Transceiver
JD062A HPE X120 1G SFP LC LH40 1550nm Transceiver
JD063B HPE X125 1G SFP LC LH70 Transceiver
JD089B HPE X120 1G SFP RJ45 T Transceiver
JD118B HPE X120 1G SFP LC SX Transceiver
JD119B HPE X120 1G SFP LC LX Transceiver
JH679A HPE X140 40G QSFP+ MPO SR4 Campus-Transceiver
JH677A HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Campus-Transceiver
JH681A HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Campus-Transceiver
JG915A HPE X130 10G SFP+ LC LH 80km Transceiver
JH678A HPE X140 40G QSFP+ LC BiDi 100m MM Campus-Transceiver
Các loại cable DAC HPE - Direct attack copper sử dụng cho switch HPE JH684A :
JH696A HPE X240 10G SFP+ to SFP+ 7m Direct Attach Copper Campus-Cable
JH694A HPE X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Campus-Cable
JH695A HPE X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Campus-Cable
JH695A HPE X240 10G SFP+ to SFP+ 3m Direct Attach Copper Campus-Cable
JL290A HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable
JL291A HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable
JL292A HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable
JL282A HPE X240 QSFP28 4xSFP28 1m Direct Attach Copper Cable
JL283A HPE X240 QSFP28 4xSFP28 3m Direct Attach Copper Cable
JL284A HPE X240 QSFP28 4xSFP28 5m Direct Attach Copper Cable
JH703A HPE X240 100G QSFP28 to QSFP28 5m Direct Attach Copper Campus-Cable
JH701A HPE X240 100G QSFP28 to QSFP28 1m Direct Attach Copper Campus-Cable
JH702A HPE X240 100G QSFP28 to QSFP28 3m Direct Attach Copper Campus-Cable
JL276A HPE X2A0 100G QSFP28 to QSFP28 7m Active Optical Cable
JL277A HPE X2A0 100G QSFP28 to QSFP28 10m Active Optical Cable
JL278A HPE X2A0 100G QSFP28 to QSFP28 20m Active Optical Cable
JH693A HPE X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Campus-Cable
JG081C HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable
JH697A HPE X240 40G QSFP+ to QSFP+ 1m Direct Attach Copper Campus-Cable
JH698A HPE X240 40G QSFP+ to QSFP+ 3m Direct Attach Copper Campus-Cable
JH699A HPE X240 40G QSFP+ to QSFP+ 5m Direct Attach Copper Campus-Cable
JG329A HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable
JH700A HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Campus-Cable
JG331A HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable
Các loại nguồn Switch HPE sử dụng cho switch HPE JH684A :
JC680A HPE 58x0AF 650W AC Power Supply
JC681A HP 58x0AF 650W DC Power Supply
Các loại fan tray HPE sử dụng cho Switch HPE JH684A :
JC682A HPE 58x0AF Back (Power Side) to Front (Port Side) Airflow Fan Tray
JC683A HPE 58x0AF Front (Port Side) to Back (Power Side) Airflow Fan Tray
JG552A HPE X711 Front (Port Side) to Back (Power Side) Airflow High Volume Fan Tray
JG553A HPE X712 Back (Power Side) to Front (Port Side) Airflow High Volume Fan Tray
