JL810A Aruba Instant On 1830 8G Switch
Aruba Part Number |
:
|
List Price |
: $
|
Giá bán |
:
|
Bảo hành |
:
|
Made In |
:
|
Stock |
:
|
JL810A là sản phẩm chuyển mạch được quản lý, cung cấp 8 Port RJ-45 Gigabit tích hợp tính năng autosensing tự động chọn tốc độ Ethernet tương thích (10/100/1000). Thiết bị này có thiết kế không quạt và được cấp nguồn PoE 13W ở Class 3 trên Port 1 rất linh hoạt khi lắp đặt không cần bổ sung ổ cắm điện và dây điện .

Thông số kỹ thuật Switch Aruba JL810A
Datasheet JL810A |
Specifications |
I/O ports and slots |
8 RJ-45 autosensing 10/100/1000 ports
IEEE 802.3af Class 3 PD (port 1) (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
|
Physical Characteristics |
Dimensions |
157.0(d) x 173.0(w) x 39.1(h) mm |
Weight |
1.70 lb (0.77 kg) |
Performance |
Throughput (Mpps) |
11.90 Mpps |
Switching capacity |
16 Gbps |
100 Mb latency |
< 5.2 uSec |
1000 Mb latency |
< 2.8 uSec |
Throughput (Mpps) |
11.90 Mpps |
Switching Capacity |
16 Gbps |
MAC address table size (# of entries) |
8,000 entries |
Reliability MTBF (years) |
188.2 |
Environment |
Operating temperature |
32°F to 104°F (0°C to 40°C) |
Operating relative humidity |
15% to 95% @ 104°F (40°C) |
Nonoperating/ storage temperature |
-40°F to 158°F (-40°C to 70°C) |
Nonoperating/ storage relative humidity |
15% to 95% @ 140°F (60°C) |
Altitude |
up to 10,000 ft (3 km) |
Acoustics1 |
Idle |
Fanless |
100% traffic |
Fanless |
100% traffic / 0% PoE |
Fanless |
100% traffic / 50% PoE |
Fanless |
100% traffic / 100% PoE |
Fanless |
Electrical Characteristics |
Frequency |
50Hz/60Hz |
AC voltage |
100-127VAC / 200- 240VAC |
Current |
12V -- 1.0A |
Maximum power rating |
100-127V: 8.09W 200-220V: 8.05W |
Idle power |
100-127V: 5.8W 200-220V: 5.9W |
PoE power |
13W max Class 3 PD |
Power supply |
External power adapter (included) |
Safety |
EN/IEC 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
EN/IEC 62368-1, 2nd. & 3rd. Ed.
UL 62368-1, 2nd. & 3rd. Ed.
CAN/CSA C22.2 No. 62368-1, 2nd. & 3rd. Ed.
EN/IEC 60825-1:2014 Class 1
|
Emissions |
EN 55032:2015/CISPR 32, Class A
FCC CFR 47 Part 15: 2018 Class A
ICES-003 Class A
VCCI Class A
CNS 13438 Class A
KN 32 Class A
AS/NZS CISPR 32 Class A
|
Immunity |
Generic |
EN 55035, CISPR 35, KN35 |
EN |
EN 55035, CISPR 35 |
ESD |
EN/IEC 61000
-4-2 |
Radiated |
EN/IEC 61000
-4-3 |
EFT/Burst |
EN/IEC 61000
-4-4 |
Surge |
EN/IEC 61000
-4-5 |
Conducted |
EN/IEC 61000
-4-6 |
Power frequency magnetic field |
EN/IEC 61000
-4-8 |
Voltage dips and interruptions |
EN/IEC 61000-4-11 |
Harmonics |
EN/IEC 61000
-3-2 |
Flicker |
EN /IEC 61000-3-3 |
Device Management |
Aruba Instant On Cloud; Web browser; SNMP Manager |
Mounting |
Mounting positions and supported racking |
Supports table-top mounting
Supports wall-mounting with ports facing either up or down
Supports under-table mounting using base surface mounting holes
|
