| Part Number |
740-080490 |
| Model Type |
40 Gigabit Ethernet |
| Transceiver Type |
QSFP+ |
| Connector |
MMF Duplex LC Connector |
| Monitoring Available |
Yes |
| Digital Optical Monitoring |
Yes |
| Additional Information |
The 40-Gbps BXSR transceiver uses two bi-directional transmitter/receivers, each supporting 20 Gbps, over two multi-mode fiber strands (duplex multi-mode cable). The left LC receptacle transmits at a nominal wavelengths of 850 nm, and receives at a nominal wavelength of 900 nm. The right LC receptacle transmits at a nominal wavelengths of 900 nm, and receives at a nominal wavelength of 850 nm. Standard OM3/OM4 MMF patch cords can be used to interconnect 40-Gbps BXSR transceiver. |
| Standard: 40GBASE-BXSR |
| Standards compliance (Ethernet/OTN Standard, for e.g. 100GBASE-LR4) |
Compliant to IEEE802.3-2015 XLPPI Electrical Specification |
| MSA compliance (SFF, for e.g. SFF-8665) |
SFF-8436 |
| Optic Type (Commercial Vs Service Provider Grade) |
MMF |
| Digital Diagnostic Monitoring |
Tx Power
Rx Power
Bias Current
Case Temperature
Power Supply Voltage
|
| NEBs (Yes or No) |
Yes |
| Signaling rate, each lane |
20.625Gbd |
| Transmitter wavelengths (range) |
Wavelength 1: 832nm to 868nm
Wavelength 2: 882nm to 918nm
|
| Receive lane wavelengths (range) |
Wavelength 1: 832nm to 868nm
Wavelength 2: 882nm to 918nm
|
| Transmitter RMS spectral width (maximum) |
0.59 nm |
| Transmitter output power, each lane (minimum) |
-4.0 dBm |
| Transmitter output power, each lane (maximum) |
5.0 dBm |
| Receiver input power, each lane (maximum) |
+5.0 dBm |
| Receiver sensitivity (OMA), each lane (maximum) |
For Center Wavelength 1 @ 850nm: -7.1 dBm
For Center Wavelength 2 @ 900nm: -7.7 dBm
|
| Stressed receiver sensitivity (OMA) each lane (maximum) |
-3.83 dBm |
| Core size/cladding |
50/125 µm |
| Effective modal bandwidth |
OM3: 2000 MHz*km
OM4: 4700 MHz*km |
| Distance |
OM3: 100 m (maximum)
OM4: 150 m (maximum) |
| Maximum Power consumption (W) |
3.5 W |
| Operating Temperature (range) |
0° C to 70° C |
| Storage temperature |
–40° C to 85° C |
| Typical Weight & Dimensions |
Typically weight: 100 grams
Dimensions(H x W x D): 13.5 x 18.4 x 72.4 mm
|
