| Datasheet Maipu IAP300-821-PE |
| Version |
v5 |
| Interface Specification |
| Service Port |
1*10/100/1000Mbps Base-T adaptive Ethernet Port, 802.3af PoE (LAN1)
1*10/100/1000Mbps Base-T adaptive Ethernet Port (LAN2) |
| Power Interface |
1*12VDC (Nominal, +/- 5%) |
| Indicators |
1* Green LED (For System and Radio status) |
| Reset Button |
1* Rest Button (Factory reset) |
| Environment Specification |
| Working Temperature |
0℃ to +45℃ |
| Working Humidity |
10% to 90% non-condensing |
| Storage Temperature |
-40℃ to +70℃ |
| Storage Humidity |
5% to 95% non-condensing |
| IP Rating |
IP41 |
| Weight |
0.4 kg |
| Dimension (W*D*H) mm |
180mm*180mm*31mm |
| Hardware Specification |
| Installation Mode |
Ceiling Mounting |
| Power Supply |
Adapter: DC 12 V/1.5 A (optional)
PoE: IEEE 802.3af/802.3at-compliant (compatible). |
| Power Consumption |
<13W (without USB output) |
| Wireless Specification |
| RF Design |
Dual-radio design, one 2.4 GHz radio and one 5 GHz radio
- Radio1: 2.4 GHz, 2 streams: 2*2
- Radio2: 5 GHz, 2 streams: 2*2 |
| Operating Bands |
- Radio1:
2.400 to 2.4835GHz
- Radio2:
5.150–5.350GHz, 5.47–5.725GHz, 5.725–5.850GHz |
| Transmission Rate |
- 802.11b: 1Mbps, 2Mbps, 5.5Mbps, 11Mbps
- 802.11a/g: 6Mbps, 9Mbps, 12Mbps, 18Mbps, 24Mbps, 36Mbps, 48Mbps, 54Mbps
- 802.11n: 6.5Mbps-300Mbps (MCS0-MCS31, HT20-HT40), 400Mbps with 256-QAM
- 802.11ac: 6.5Mbps-866Mbps (MCS0-MCS9, NSS=1-2, VHT20-VHT80)
- 802.11ax (2.4GHz): 8.6Mbps-574Mbps (MCS0-MCS11, NSS=1-2, HE20-HE40)
- 802.11ax (5GHz): 8.6Mbps-1,202Mbps (MCS0-MCS11, NSS = 1-2, HE20-HE80) |
| Antenna |
Internal 4 Antennas |
| Antenna Gain |
2.4 GHz: 4.0dBi
5 GHz: 4.0dBi |
| Transmit Power |
2.4 GHz: +20dBm
5 GHz: +20dBm
The actual transmit power complies with the regulatory requirements for radio frequency
emissions in various countries and regions |
| Transmit Power Adjustment |
1 dBm |
| Modulation Mode |
- 802.11b: BPSK, QPSK, CCK |
| Modulation Mode |
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
- 802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
- 802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM |
| Modulation and Encoding |
- Low Density Parity Check (LDPC)
- Maximum Likelihood Detection (MLD)
- Beamforming |
| Advanced RF Features |
- Channel Rate Adjustment, include TPC (Transmit Power Control)
- ACS (Automatic Channel Scanning) |
| Fast Roaming |
- 802.11 K/V/R |
| Rate Limitation |
- Based On SSIDs
- Based On Users |
| Load Balancing |
- Based On Users |
| Software Specification |
| WIFI Standards |
IEEE 802.11a/b/g/n/ac/ax |
| SSID Numbers |
16*SSIDs (2.4GHZ+5GHZ) |
| Channelization |
20, 40, 80 MHz |
| STA Capacity |
512 |
| Network Features |
PPPoE Client, DHCP Server/Client, Static IP, DNS Proxy, Bridge, NAT
(Note: FAT Working Mode) |
| Security Type |
Open, PSK, WPA-Personal, WPA-Enterprise, WPA2-Personal, WPA2-Enterprise, WPA3-
Personal, WPA3-Enterprise, Portal, 802.1X, Radius |
| Working Bandwidth |
802.11ax: HE80, HE40, HE20
- 802.11ac: VHT80, VHT40, VHT20
- 802.11n: HT40, HT20 |
| Data Rate |
Radio1: 2.4 GHz, 574 Mbps
- Radio2: 5 GHz, 1201 Mbps
- Combined: 1.775 Gbps |
| MIMO Technologies |
- Multi-User Multiple Input Multiple Output (MU-MIMO)
- Maximum Ratio Combining (MRC)
- Space-Time Block Coding (STBC)
- Cyclic Delay/Cyclic Shift Diversity (CDD/CSD)
- Dynamic MIMO power saving |
| Energy Saving |
- U-APSD
- Green AP mode |
| Advanced WIFI Features |
- Orthogonal Frequency Division Multiple Access (OFDMA)
- Short GI (Short Guard Interval)
- DFS (Dynamic Frequency Selection)
- Spectrum Navigation |
