| Hardware Specifications |
| Model |
IGW500-100 |
| Physical Ports |
5xGE RJ45 |
| PoE Enable |
N/A |
| Recommend Managed APs |
Gateway mode: 16 Units AP
Controller mode: 0~32 Units AP |
| Power Supply |
AC Power Supply |
| Dimension (W×D×H) |
440×208×44mm |
| Power Lightning Protection |
6KV for both common mode and differential mode are 6kV |
| Temperature |
Work temperature: 0-45℃ |
| Storage temperature: -40–70℃ |
| Humidity |
Work humidity: 5-85%, no-condensing
Storage humidity: 5-95%, non-condensing |
| Software specifications |
| Gateway Settings |
Dynamic IP, static IP and PPPoE, Multiple WAN, VLAN, Static NAT, Dynamic NAT, Port Mapping, IPV4/IPV6 DHCP Server, DNS, IPSec VPN |
| Wireless Features |
CAPWAP, AP upgrading, Manual and regular AP restarting, Limit numbers of access clients, Restore AP, AP status monitoring, STA status monitoring, Load balancing between RF(2.4G & 5G), Load balancing between wireless clients, Manually/Automatically work channel setting, Manually/Automatically transmission power setting, Manually 20MHz/40MHz/80MHz channel bandwidth configuration, Manually/Automatically channel optimization, L2 roaming, SSID hidden, STA isolation within VLAN, SSID timing ON and OFF, STA blacklist MAC & whitelist MAC, Bandwidth limitation based on AP group, Bandwidth limitation based on service name, Downlink/Uplink bandwidth control |
| Authentication Management |
Open, PSK, 802.1X, Portal (Local account authentication, External portal authentication, Local portal user groups and user management, Local password-free authentication, Customize Web authentication page/built-in authentication page template, Authentication-free network resources) |
| Advanced Security Function |
URL customization and filtering, DPI for hot APPs, Application audit, Keyword, mail, file type and other content filtering, Flow filtering, Connection limitation, IP access list, Time rule list |
| Attack Protection |
Flood/Scan attack prevention, URPF attack prevention, Single packet attack detection |
| Device Management |
Web, PING, Tracert, Packet capture, Cloud platform |
