Hardware                                                      Specification

Dimensions

175mm×123mm×28mm（L×W×H）

Weight

About 0.6Kg

Operating temperature

-20℃～50℃

Operating   humidity

10%～90%（non-condensing）

Power adapter   input

100 V to   240 V AC, 50 Hz/60 Hz

System power   supply

DC 48V/2A

UNI

1*GE (PoE)   + 3*FE(PoE)

NNI

1*GPON

Static power   consumption

10W

Typical power   consumption

13W (without   PoE)

Maximum power   consumption

16W   (without PoE)

88W (within   PoE)

Maximum PoE   output power

61.6 W (4 port   PoE)

PON Port

SC/UPC   connector

SFP optical   module

Transmission   rate：

GPON:   downstream 2.5Gbps and upstream 1.25Gbps

EPON: downstream   1.25Gbps and upstream 1.25Gbps

GE   Electrical Port or FE Electrical Port

PoE, IEEE   802.3af

RJ-45   connector

Port rate   auto negotiation (10/100/1000 Mbit/s or 10/100 Mbit/s)

Auto-MDI/MDIX

Configuration   of the number of MAC addresses learned

Ethernet   port-based VLAN transparent transmission and VLAN filtering

Software Key   Feature

Automatic   Service Provisioning

Authentication   exemption

XML/OMCI or   OAM

SFU ONU

Bridging   mode

Well   connect with OLTs of mainstream (Huawei\ZTE\FH)

Layer 2   Management

802.1D&802.1ad   bridging

802.1p CoS

802.1Q VLAN

Multicast

IGMPv2/v3

IGMP   snooping

standard

IEEE802.3af   standard

ITU-T   G.984.x standard

China's CTC   3.0 standards
