| Hardware specifications |
| Physical ports |
One 10/100/1000Base-T Ethernet port, support POE power supply (rear panel)
Four 10/100/1000Base-T Ethernet ports (front panel) |
| Management Port |
One Micro USB interface |
| Power supply mode |
Support 802.3at POE |
| IP protection level |
IP41 |
| Temperature |
Working temperature: 0 ℃– 45 ℃
Storage temperature: -40℃–70℃ |
| Storage humidity |
Working humidity: 5%–95%, no-condensing
Storage humidity: 5%–95%, no-condensing |
| Transmitting power |
≤100mW (20dBm) |
| Working frequency band |
2.4 – 2.483GHz |
| 5.150–5.350GHz, 5.47–5.725GHz, 5.725–5.850GHz (Note: the working frequency band varies according to the configuration of different countries) |
| Wireless type |
Inbuilt 2x2 MIMO antenna |
| Installation types |
In-wall |
| Software specifications |
| Max. access users |
1024 |
| Recommended access quantity |
100 |
| Virtual AP |
Max. support 32 |
| Supported protocols |
TCP/IP, IPX, NetBEUI, IEEE802.3/u 10/100Base-Tx RJ-45, IEEE 802.3z 1000BaseX , 802.1d, 802.1p, 802.1q, 802.1x, 802.11, 802.11b, 802.11a, 802.11g, 802.11h, 802.11i, 802.11e, 802.11n, 802.11ac, 802.11ax, CAPWAP, DHCP Server, DHCP Client, DHCP Relay, DNS Client, NTP (Server and Client), and so on |
| Work mode |
Centralized forwarding mode, local forwarding mode |
| Wireless features |
Auto adjusting of frequency, auto power adjusting, auto adjusting of channel, Radio switch, wireless mode selection (802.11a/b/g/n/ac), auto rate selection, support WMM, support Multi BSSID |
| AP discovery mode |
Static IP discovery, DHCP discovery, DNS discovery and so on |
| QoS service |
Load balancing (traffic, number of users), bandwidth control, link detection, WMM, access quantity control |
| Management features |
Web, SSH, CLI, SNMP, CAPWAP |
| Network service |
DHCP Server, FTP, DNS, NTP |
| Fat-AP functions |
Support DHCP Server, NAT, PPPoE, black and white list, security policy, etc; |
| Security features |
802.1x authentication, web authentication, DoS attack prevention, ARP suppression, ACL control (support access control based on MAC address and IP address), wireless user isolation, static blacklist, whitelist, broadcast storm control, MAC address access control (ACL), CAPWAP tunnel encryption, scanning reaction |
