| Interface |
- 8 x 100M/1G/2.5G/5/10G Ethernet RJ45 with auto negotiation and autoMDIX3
- 16 x 1G Ethernet RJ45
- 2 x 40G QSPF+ or 4 x 10G SFP+ uplinks
- 2 x 100G QSFP28 stacking ports
|
| Switching Capacity |
|
| Stacking Bandwidth |
|
| Forwarding rate |
|
| Jumbo frame support |
|
| Physical Dimensions (H x W x D) |
1.72” x 19.08” x 20.34” (4.37 x 48.46 x 51.66cm) |
| Weight |
12.30 lb (5.58 kg) |
| Idle / Full (with Combined Power) |
110 / 1744W |
| Redundant / Combined Power |
740 / 1440 W |
| Power Supply Configuration |
Hot-swappable |
| Supported Power Supply |
MA-PWR-1025WAC |
| Power over Ethernet |
- Up to 30W per 1G port
- Up to 60W per mGig port
- Maximum PoE output: 740 W
- PoE available simultaneously on all ports
- Intelligent PoE power allocation based on device advertisement (LLDP)
|
| Management |
- Email alerts for switch management
- Remote troubleshooting tools
- Manage ports from a GUI-based dashboard
- Zero-touch provisioning
- Per-port and per-client usage statistics
- Secure, user-scheduled firmware updates
|
| Remote Diagnostics |
- Email, SMS and Mobile push notification alerts
- Ping, traceroute, cable testing, and link failure detection with alerting
- Remote packet capture
- Dynamic and interactive network discovery and topology
- Combined event and configuration change logs with instant search
|
| Scalable Stacking |
- Physically stack up to 8 switches with 400 Gbps of stacking bandwidth on all models
- Virtual stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration
|
| Ethernet Switching Capabilities |
- Layer 3
- Warm spare redundancy (VRRP)
- OSPF Routing
- MAC forwarding entries, up to 32K
- DHCP Server, DHCP Relay
- 802.1X Authentication
- DHCP Snooping
- STP Enhancements
- IPv4 and IPv6 ACLs
|
| Security |
- Integrated multi-factor authentication for Dashboard management
- Role-based access control (RBAC) with granular device and configuration control
- Corporate wide password policy enforcement
- IEEE 802.1X RADIUS and MAB, hybrid authentication and RADIUS server testing
- Single-Host/Multi-Domain/Multi-Host/Multi Authentication
- Port security: Sticky MAC, MAC whitelisting
- DHCP snooping, detection and blocking, Dynamic ARP Inspection
- IPv4 and IPv6 ACLs
|
| Performance |
- Non-blocking fabric
- 2.5 microsecond latency
- Jumbo frame support (9600 byte Ethernet frame)
|
| Layer 3 |
- Static routing, OSFPv2 (with support for up to 16 ECMP Routes)
- Multicast routing [PIM-ASM]
- Warm Spare (VRRP)
- DHCP Server, DHCP Relay
|
| Power |
- Power input: 100 - 240 VAC, 47-63 Hz
- Power consumption: 110 - 1793W
|
| Mounting |
- 1U rack-mountable
- 4 post rack mount support
|
| Environment |
- Operating temperature: -5°C to 45°C
- Humidity: 5 to 95% non-condensing
- Variable speed fans
|
| Regulatory |
- CSA (US)
- IC (Canada)
- CE (Europe)
- C-Tick (Australia/New Zealand)
- RoHS
|
| MTBF Rating |
369,317 |
