CPAK-100G-PSM4 Cisco 100GBASE PSM4 CPAK Module for SMF
- Danh mục sản phẩm Module Quang Cisco
- Fiber Type
-
Form Factor
- CPAK
-
Data Tranfer
- 100 GbE
- Distance
-
Wave Length
- 1310nm
-
Connecter
- MPO/MTP
Cisco 100GBASE PSM4 CPAK Module CPAK-100G-PSM4
Cisco Part Number : CPAK-100G-PSM4
List Price : $
Giá bán : Liên hệ
Bảo hành : 12 tháng
Made In : China
Stock : Liên hệ
Module Cisco CPAK-100G-PSM4 hỗ trợ độ dài liên kết lên tới 500 mét, single-mode (SMF) với đầu nối MPO.
| View Datasheet CPAK-100G-PSM4 |
Tín hiệu Ethernet 100 Gigabit được truyền qua 12 sợi song song và kết thúc bằng đầu nối đa sợi MPO.
CPAK-100G-PSM4 Module Features and Benefits
|
Requirement |
Cisco CPAK Module Supporting Feature |
|
Accommodate ever-growing bandwidth requirements |
Up to 10 100-Gigabit Ethernet connections deliver as much as 1 Tbps of front-panel bandwidth |
|
Control costs |
Form factor consumes 40% less power than CFP2 and 70% less power than CFP form factors |
|
Real estate conservation |
Minimal footprint allows 20% greater port density and bandwidth than competing products |
|
High availability for business continuity |
Hot-swappable input/output device plugs into a Cisco CPAK-module-based switch, router, or optical platform port |
|
Accommodate a variety of distance and fiber type requirements |
Flexible interface choices |
|
Investment protection, affordable migration to higher bandwidth |
- Support for a “pay-as-you-grow” model - Can plug any Cisco 100-Gbps, 40-Gbps, and 10-Gbps line cards into Cisco CPAK modules (supports the Cisco AnyPort solution) |
|
Manage performance |
Digital optical monitoring (DOM) support |
|
Standards compliance for equipment flexibility and choice |
Interoperability with any IEEE-compliant: 100GBASE-SR4, 100GBASE-LR4, 100GBASE-SR10, 40GBASE-SR4, 10GBASE-SR, 10GBASE-LR |
|
MSA compliant to: 100GBASE CWDM4 |
|
|
Proper functioning and high performance with all Cisco platforms |
Cisco quality identification (ID) feature enables a Cisco platform to identify whether the module is certified and tested by Cisco |
CPAK-100G-PSM4 Specifications
|
Cisco CPAK Module |
Wavelength (nm) |
Cable Type |
Core Size (Microns) |
Modal Bandwidth (MHz*km)a |
Cable Distanceb |
|
Cisco CPAK 100GBASE-LR4 |
1295 to 1325 |
SMF (12 fibers) |
9-micron core |
- |
500m |
CPAK-100G-PSM4 có thể sử dụng cho
- ASR 9000 Series Router
- CRS-X Carrier Routing System
- NCS 2000, 4000, and 6000 Series Routers
- Nexus 7000 and 7700 Series Switches
- Cisco ONS Transport Platform
