Hardware Specification
|
MP1800X-40 (V12)
|
|
CPU
|
1GHz Dual Core
|
|
Memory (Default)
|
512M
|
|
Flash (Default)
|
128M
|
|
Dual IOS
|
Yes
|
|
Fixed interface
|
5 GE RJ45 (WAN or LAN)
|
|
USB
|
1*USB2.0
|
|
Console port
|
1*RJ45 console port.
|
|
Dimension (L*D*H)
|
145mm*100mm*38mm
|
|
Power supply
|
12V DC input
|
|
Power consumption
|
≤20W
|
|
IP Security Level
|
IP30
|
|
Working Temperature
|
-20°C～60°C
|
|
Humidity
|
Work humidity: 5%-85%/RH
|
|
Weight
|
≤1KG
|
|
Software features
|
|
WAN Protocol
|
DDR, NDIS, PPPoE, Bridge Group, EDP
|
|
LAN Protocol
|
STP/RSTP/MSTP, MAC management, 802.1q VLAN, LACP, Loopback Detection, SPAN, LLDP, Port-isolate, Error-disable, ULFD, Port Security
|
|
TCP/IP Protocol
|
DHCP, DNS, DDNS, NAT, NAT64, NAT66, NAT ALG, IPIP, GRE, L2TP/L2TPv3
|
|
IPv4 Routing protocol
|
Static, RIP, OSPFv2, IS-IS, BGP, Policy Routing
|
|
IPv6 Routing Protocol
|
IPv6 Static, RIPng, OSPFv3, IS-ISv6, BGP4+, IPv6 Policy Routing
|
|
IPv6 function
|
IPv4/IPv6 Dual-Stack, IPv6 ND, IPv6 PMTU, IPv6 ACL, ICMPv6, DNSv6, DHCPv6, GREv6
|
|
IPv6 Transition Tunneling
|
IPv6 over IPv4, 6to4, ISATAP
|
|
Multicast
|
IGMP v1/v2/v3, PIM-DM/PIM-SM, SSM, MVPN, NG MVPN, MSDP, MLD, IPv6 PIM, MBGP
|
|
VPN
|
IPSec, PKI, MPLS, VPLS, VPWS, L3VPN, OAM, 6PE, VRF, DVPN, VxLAN
|
|
MPLS
|
LDP, MPLS L3VPN, MPLS L2VPN, MPLST TE, IP FRR, LDP FRR, TE FRR
|
|
Security
|
ACL, SSH, CPU protection, Firewall, IPS, URL Filter, AAA, IKE, PKI, 802.1X, URFP
|
|
QoS
|
FIFO, PQ, FQ, WFQ, CBWFQ, LLQ, RSVP, CAR, H-QoS, traffic shaping, Rate Limitation
|
|
Reliability
|
Backup interface, VRRP/VRRPv3, VBRP, IPSLA, Track, BFD/BFDv6
|
|
Automation
|
ZTP, Netconf
|
|
Management & Monitoring
|
Keepalive, NTP, EEP, RMON, CWMP, CLI, SSH, HTTP/HTTPS, SNMP V1/V2/V3, Telnet, PING, Trace Route, Login, FTP, TFTP, SFTP, TR069, IP-SLA, Telemetry, IPFIX
|
Switch
