PWR-C6-1KWAC Cisco 1KW AC Config 6 Power Supply
Nguồn Cisco PWR-C6-1KWAC 1KW AC Config 6 Power Supply for Switch Cisco Catalyst 9200
PWR-C6-1KWAC Cisco 1KW AC Config 6 Power Supply
Cisco Part Number : PWR-C6-1KWAC
List Price : $
Stock : Liên hệ
Tình trạng : Mới
Bảo hành : 12 tháng 1 đổi 1
Nguồn Cisco PWR-C6-1KWAC 1KW AC Config 6 Power Supply for Switch Cisco Catalyst 9200
Thông số kỹ thuật PWR-C6-1KWAC
| Description | Specification |
| Power supply rated maximum | 1000W |
| Total output BTU (note: 1000 BTU/hr = 293W) |
3412 BTU/hr, 1000W |
| Input-voltage range and frequency | 100 to 240 VAC, 50 to 60 Hz |
| Input current | 12-6A |
| Output ratings | 54V at 16.5A |
| Output holdup time | 20 ms minimum at 100 VAC |
| Power-supply input receptacles |
IEC 320-C16 (IEC60320-C16) |
| Power cord rating | 15A |
| Physical specifications |
(H x W x D): 1.58” x 4.0” x 7.6” Weight: 2 lb (0.9 kg) |
| Supported Product Family | C9200 |
| Operating temperature |
Normal operating temperature* and altitudes: - -5°C to +45°C, up to 5000 feet (1500m)
- -5°C to +40°C, up to 10,000 feet (3000m)
* Minimum ambient temperature for cold start is 32°F (0°C) Short-term* exceptional conditions: - -5°C to +50°C, up to 5000 feet (1500m)
- -5°C to +45°C, up to 10,000 feet (3000m)
- -5°C to +45°C, at sea level with single fan failure
* Not more than following in one-year period: 96 consecutive hours, or 360 hours total, or 15 occurrences |
| Storage temperature | -40° to 158°F (-40° to 70°C) |
| Relative humidity operating and nonoperating noncondensing | 5% to 90% noncondensing |
| Altitude | 10,000 ft. (3000 meters), up to 45°C |
| EMI and EMC compliance |
FCC Part 15 (CFR 47) Class A ICES-003 Class A EN 55032 Class A CISPR 32 Class A AS/NZS 3548 Class A BSMI Class A VCCI Class A CISPR 35 EN 55024, EN300 386*, EN 61000-3-2, EN 61000-3-3 EN 61000-6-1 |
| Safety compliance | UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking |
| LED indicators |
“AC OK”: Input power to the power supply is OK “PS OK”: Output power from the power supply is OK |
