| PHYSICAL CHARACTERISTICS |
| Power |
• 220 watt internal power supply
• 100 – 250V AC Universal, IEC 320 connector |
| Physical Size |
1RU: 35.52cm(L), 43.18cm(W), 4.39cm(H) |
| Weight |
14 lbs (6.37 kilograms) |
| Ports |
2 ports, auto MDX, auto-sensing 10/100/1000 Mbps, RJ-45 |
| Environmental Conditions |
Operating Temperature: 41°F (5°C) – 104°F (40°C) |
| CAPACITY |
| Managed APs |
Up to 500 |
| WLANs (BSSIDs) |
1,024 |
| Concurrent Stations |
Up to 10,000 |
| APPLICATIONS |
| Hotspot |
WISPr |
| Guest Access |
Supported |
| Captive Portal |
Supported |
| Mesh |
Supported |
| Voice |
• 802.11e/WMM
• U-APSD
• Tunneling to AP |
| NETWORK ARCHITECTURE |
| IP |
IPv4, IPv6, dual-stack |
| VLANS |
802.1Q (1 per BSSID), dynamic VLAN |
| Redundancy |
1+1 with auto-synchronization |
| DCHP Server |
Supported |
| MANAGEMENT |
| Configuration |
Web user interface, CLI, FlexMaster, SNMP v1, v2, v3 |
| AAA |
RADIUS (primary and backup) |
| AP Provisioning |
• L2 or L3 auto-discovery
• Auto-software upgrade
• Automatic channel and power optimization |
| Client Provisioning |
• Zero-IT |
| Wireless Packet Capture |
Supported |
| SUPPORTED WIRELESS STANDARDS |
| IEEE |
802.11a, 802.11b, 802.11g, 802.11n, 802.11ac, 802.11r, 802.11k, 802.11v, 802.11d, WMM/802.11e, 802.11u |
| SECURITY |
| Standards |
WPA, WPA2, 802.11i |
| Encryption |
• TKIP, AES
• Ruckus Dynamic Pre-Shared Key |
| Authentication |
802.1x, MAC address |
| User Database |
• Internal database up to 10,000 users
• External: RADIUS, LDAP, Active Directory |
| Access Control |
• L2 (MAC address-based)
• L3/4 (IP and Protocol based)
• L2 client isolation
• Management interface access control
• Time-based WLANs |
| Wireless Intrusion Detection (WIDS) |
• Rogue AP detection
• DoS attack prevention
• Evil-twin/AP spoofing detection
• Ad hoc detection
• Password guessing protection |
| MULTIMEDIA AND QUALITY OF SERVICE |
| 802.11e/WMM |
Supported |
| Software Queues |
Per traffic type (4), per client |
| Traffic Classification |
Automatic, heuristics and TOS based or VLAN-defined |
| Rate Limiting |
Supported |
| WLAN Prioritization |
Supported |
| Client Load Balancing |
Automatic |
| CERTIFICATIONS |
| Certifications |
• U.S., Europe, Australia, Brazil, Canada, Chile, China, Colombia, Ecuador, Egypt, Hong Kong, India, Indonesia, Korea, Malaysia, Mexico, New Zealand, Pakistan, Philippines, Saudi Arabia, South Africa, Taiwan, Thailand, UAE, Uruguay, Vietnam
• Wi-Fi Alliance Certification (Wi-Fi Certified™) |
