| WI-FI |
| Wi-Fi Standards |
IEEE 802.11a/b/g/n/ac/ax |
| Supported Rates |
802.11ax: 4 to 1,774 Mbps (MCS0 to MCS11, NSS=1 to 2 for HE 20/40/80) |
| 802.11ac: 6.5 to 867 Mbps (MCS0 to MCS9, NSS = 1 to 2 for VHT 20/40/80) |
| 802.11n: 6.5 Mbps to 300 Mbps (MCS0 to MCS15) |
| 802.11a/g: 6 to 54 Mbps |
| 802.11b: 1 to 11 Mbps |
| Supported Channels |
2.4Ghz: 1-13 |
| 5Ghz: 36-64, 100-144, 149-165 |
| MIMO |
2x2 SU-MIMO |
| 2x2 MU-MIMO |
| Spatial Streams |
2 Streams SU/MU-MIMO (2.4Ghz & 5Ghz) |
| Radio Chains and Streams |
2x2:2 (2.4Ghz & 5Ghz) |
| Channelization |
20, 40, 80MHz |
| Security |
WPA-PSK, WPA-TKIP, WPA2 AES, WPA3-Personal, WPA3- Enterprise, 802.11i, Dynamic PSK, OWE |
| WIPS/WIDS |
| Other Wi-Fi Features |
WMM, Power Save, Tx Beamforming, LDPC, STBC, 802.11r/k/v |
| Captive Portal |
| Hotspot |
| Hotspot 2.0 |
| WISPr |
| RF |
| Antenna Type |
BeamFlex+ adaptive antennas with polarization diversity
Adaptive antenna that provides multiple unique antenna patterns |
| Antenna Gain (max) |
Up to 1dBi |
| Peak Transmit Power (aggregate across MIMO chains) |
2.4GHz: 19dBm |
| 5GHz: 22dBm |
| Minimum Receive Sensitivity1 |
-100dBm |
| Frequency Bands |
ISM (2.4-2.484GHz) |
| U-NII-1 (5.15-5.25GHz) |
| U-NII-2A (5.25-5.35GHz) |
| U-NII-2C (5.47-5.725GHz) |
| U-NII-3 (5.725-5.85GHz) |
| PERFORMANCE AND CAPACITY |
| Peak PHY Rates |
2.4GHz: 574Mbps |
| 5GHz: 1,200Mbps |
| Client Capacity |
Up to 512 clients per AP |
| SSID |
8 per radio |
| RUCKUS RADIO MANAGEMENT |
| Antenna Optimization |
BeamFlex+ |
| Polarization Diversity with Maximal Ratio Combining (PD- MRC) |
| Wi-Fi Channel Management |
ChannelFly |
| Background Scan Based |
| Client Density Management |
Adaptive Band Balancing |
| Client Load Balancing |
| Airtime based WLAN Prioritization |
| Airtime Fairness |
| SmartCast Quality of Service |
QoS-based scheduling |
| Directed Multicast |
| L2/L3/L4 ACLs |
| Mobility |
SmartRoam |
| Diagnostic Tools |
Spectrum Analysis |
| SpeedFlex |
| NETWORKING |
| Controller Platform Support |
SmartZone |
| ZoneDirector |
| Unleashed2 |
| Cloud |
| Standalone |
| Mesh |
SmartMesh™ wireless meshing technology. Self-healing Mesh |
| IP |
IPv4, IPv6, dual stack |
| VLAN |
802.1Q (1 per BSSID or dynamic per use based on RADIUS) |
| VLAN Pooling |
| Port-based |
| 802.1x |
Authenticator and Supplicant |
| Tunnel |
L2TP, GRE, Soft-GRE |
| Policy Management Tools |
Application Recognition and Control |
| Access Control Lists |
| Device Fingerprinting |
| Rate Limiting |
| IoT |
Integrated BLE and Zigbee (1 radio, switchable) |
| PHYSICAL INTERFACES |
| Ethernet |
1x 1GbE port, RJ-45, PoE In – 802.3af Class 3 |
| 2x 1GbE ports, RJ-45 |
| PHYSICAL CHARACTERISTICS |
| Physical Size |
89.5 mm (W) x 178.5 mm (L), 29.3 mm (H) |
| 3.52in (W) x 7.03in (L) x 1.15in (H) |
| Weight |
276g (0.608lbs) without bracket |
| 346g (0.763lbs) with bracket |
| Mounting |
Electrical wallbox; Standard US and EU single gang wall jack |
| Optional bracket for offset & wall mount |
| Operating Temperature |
0°C (32°F) - 40°C (104°F) |
| Operating Humidity |
Up to 95%, non-condensing |
