| WI-FI |
| Wi-Fi Standards |
IEEE 802.11a/b/g/n/ac |
| Supported Rates |
• 802.11ac: 6.5 to 867Mbps (MCS0 to MCS9, NSS = 1 to 2 for VHT20/40/80)
• 802.11n: 6.5 Mbps to 300Mbps (MCS0 to MCS15)
• 802.11a/g: 54, 48, 36, 24, 18, 12, 9 , 6Mbps
• 802.11b: 11, 5.5, 2 and 1 Mbps |
| Supported Channels |
• 2.4GHz: 1-13
• 5GHz: 36-64, 100-144, 149-165 |
| MIMO |
2x2 SU-MIMO |
| Spatial Streams |
2 SU-MIMO |
| Channelization |
20, 40, 80MHz |
| Security |
• WPA-PSK, WPA-TKIP, WPA2 AES, 802.11i, Dynamic PSK
• WIPS/WIDS |
| Other Wi-Fi Features |
• WMM, Power Save, TxBF, LDPC, STBC, 802.11r/k/v
• Hotspot
• Hotspot 2.0
• Captive Portal
• WISPr |
| RF |
| Antenna Type |
• BeamFlex+ adaptive antennas with polarization diversity
• Adaptive antenna that provides up 512 unique antenna patterns per band |
| Antenna Gain (max) |
up to 3dbi |
| Peak Transmit Power (aggregate across MIMO chains) |
• 2.4GHz: 25dBm
• 5GHz: 24dBm |
| Minimum Receive Sensitivity |
-99dBm |
| Frequency Bands |
• ISM 2.4-2.484GHz
• U-NII-1 5.15-5.25GHz
• U-NII-2A 5.25-5.35GHz
• U-NII-2C 5.47-5.725GHz
• U-NII-3 5.725-5.85GHz |
| PERFORMANCE AND CAPACITY |
| Peak PHY Rates |
• 2.4GHz: 300Mbps
• 5GHz: 867Mbps |
| Client Capacity |
Up to 100 clients per AP |
| SSID |
Up to 16 per AP |
| RUCKUS RADIO MANAGEMENT |
| Antenna Optimization |
BeamFlex |
| Wi-Fi Channel Management |
• ChannelFly
• Background Scan Based |
| Client Density Management |
• Adaptive Band Balancing
• Client Load Balancing
• Airtime Fairness
• Airtime-based WLAN Prioritization |
| SmartCast Quality of Service |
• QoS-based scheduling
• Directed Multicast
• L2/L3/L4 ACLs |
| Mobility |
SmartRoam |
| Diagnostic Tools |
SpeedFlex |
| NETWORKING |
| Controller Platform Support |
• SmartZone
• ZoneDirector
• Cloud Wi-Fi
• Unleashed
• Standalone |
| IP |
IPv4, IPv6 |
| VLAN |
• 802.1Q (1 per BSSID or dynamic per use based on RADIUS)
• VLAN Pooling
• Port-based |
| 802.1x |
Authenticator & Supplicant |
| Tunnel |
L2TP, GRE, Soft-GRE |
| Policy Management Tools |
• Application Recognition and Control
• Access Control Lists
• Device Fingerprinting
• Rate Limiting |
| PHYSICAL INTERFACES |
| Ethernet |
1 x 1GbE port, RJ-45 |
| PHYSICAL CHARACTERISTICS |
| Physical Size |
• 13.8(L) x 13.5(W) x 3.3(H) cm
• 5.43(L) x 5.31(W) x 1.3(H) in |
| Weight |
220g (7.8oz) |
| Mounting |
• Wall, Acoustic ceiling, Desk
• Secure Bracket (sold separately) |
| Physical Security |
• Hidden latching mechanism
• Kensington lock
• T-bar Torx |
| Operating Temperature |
0°C (32°F) - 40°C (104°F) |
| Operating Humidity |
Up to 95%, non-condensing |
| CERTIFICATIONS AND COMPLIANCE |
| Wi-Fi Alliance |
• Wi-Fi CERTIFIED™ a, b, g, n, ac
• Passpoint®
• Vantage |
| Standards Compliance |
• EN 60950-1 Safety
• EN 60601-1-2 Medical
• EN 61000-4-2/3/5 Immunity
• EN 50121-1 Railway EMC
• EN 50121-4 Railway Immunity
• IEC 61373 Railway Shock & Vibration
• EN 62311 Human Safety/RF Exposure
• UL 2043 Plenum
• WEEE & RoHS
• ISTA 2A Transportation |
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: 901-R310-WW02 ?
Chào anh,
Sản phẩm Wifi Ruckus R310 có thể xuyên tường được, tuy nhiên còn phụ thuộc vào thiết kế và môi trường xung quanh. Anh vui lòng cung cấp bản vẽ chi tiết văn phòng để CNTTShop tư vấn tốt nhất.
Chào anh/chị, báo giá bộ phát wifi Ruckus 901-R310-WW02 đã được gửi vào mail của anh/chị.
Chào anh/chị, bộ phát Ruckus R310 có thể hoạt động được ở chế độ unleashed.
Chào anh/chị, bộ wifi Ruckus 901-R310-WW02 có thể sử dụng được nguồn PoE.
Chào anh/chị, bộ phát wifi Ruckus 901-R310-WW02 có thể dùng được với ZoneDirector 3205.
