| WI-FI |
| Wi-Fi Standards |
IEEE 802/11a/b/g/n/ac/ax, WiFi-6E |
| Supported Rates |
802.11ax: 4 to 2402 Mbps |
| 802.11ac: 6.5 to 866 Mbps |
| 802.11n: 6.5 to 300 Mbps |
| 802.11a/g: 6 to 54 Mbps |
| 802.11b: 1 to 11 Mbps |
| Supported Channels |
2.4GHz: 1-13 |
| 5GHz: 36-64, 100-144, 149-165 |
| 6GHz: 1-233 |
| MIMO |
2x2 SU-MIMO |
| 2x2 MU-MIMO |
| Spatial Streams |
2 for both SU-MIMO & MU-MIMO |
| Radio Chains and Streams |
2x2:2 |
| Channelization |
20, 40, 80, 160 MHz |
| Security |
WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPA3, WPA3-SAE, OWE, PMF (802.11w), Dynamic PSK |
| WIPS/WIDS |
| Other Wi-Fi Features |
WMM, Power Save, Tx Beamforming, LDPC, STBC, 802.11r/k/v |
| MBO |
| Web Authentication and Guest Access |
| Hotspot, Hotspot 2.0 |
| Captive Portal |
| WISPr |
| RF |
| Antenna Type |
BeamFlex+ adaptive antennas with polarization diversity |
| Adaptive antenna that provides 4,000+ unique antenna patterns per band |
| Antenna Gain (max) |
Up to 4dBi |
| |
2.4GHz: 26dBm |
| Peak Transmit Power (Tx port/ chain + Combining gain) |
5GHz: 25dBm |
| 6GHz: 22dBm |
| Frequency Bands |
ISM (2.4-2.484GHz) |
| U-NII-1 (5.15-5.25GHz) |
| U-NII-2A (5.25-5.35GHz) |
| U-NII-2C (5.47-5.725GHz) |
| U-NII-3 (5.725-5.85GHz) |
| U-NII-5 (5.925–6.425GHz) |
| U-NII-6 (6.425–6.525GHz) |
| U-NII-7 (6.525–6.875GHz) |
| U-NII-8 (6.875–7.125GHz) |
| PERFORMANCE AND CAPACITY |
| Peak PHY Rates |
2.4GHz: 591 Mbps |
| 5GHz: 1237.5 Mbps |
| 6GHz: 2882 Mbps (MCS13), 2402 Mbps (MCS11) |
| Client Capacity |
Up to 1536 clients per AP |
| SSID |
Up to 33 per AP |
| RUCKUS RADIO MANAGEMENT |
| Antenna Optimization |
BeamFlex+ |
| Polarization Diversity with Maximal Ratio Combining (PD- MRC) |
| Wi-Fi Channel Management |
ChannelFly |
| Background Scan Based |
| Client Density Management |
Adaptive Band Balancing |
| Client Load Balancing |
| Airtime Fairness |
| Airtime-based WLAN Prioritization |
| SmartCast Quality of Service |
QoS-based scheduling |
| Directed Multicast |
| L2/L3/L4 ACLs |
| Mobility |
SmartRoam |
| Diagnostic Tools |
Spectrum Analysis |
| SpeedFlex |
| NETWORKING |
| Controller Platform Support |
SmartZone |
| Standalone |
| Cloud (Future support) |
| Mesh |
SmartMesh™ wireless meshing technology. Self-healing Mesh in 2.4 GHz, 5GHz, and 6GHz |
| IP |
IPv4, IPv6, dual-stack |
| VLAN |
802.1Q (1 per BSSID or dynamic per user based on RADIUS) |
| VLAN Pooling |
| Port-based |
| 802.1x |
Authenticator & Supplicant |
| Tunnel |
GRE, Soft-GRE |
| Policy Management Tools |
Application Recognition and Control |
| Access Control Lists |
| Device Fingerprinting |
| Rate Limiting |
| URL Filtering |
| IoT Capable |
Intelgrated BLE and Zigbee (1 radio, selectable) |
| PHYSICAL INTERFACES |
| Ethernet |
One 100M/1/2.5/5G Ethernet (PoE) port and one 10M/ 100M/1G Ethernet port |
| Power over Ethernet (802.3af/at/bt) with Category 5e (or better) cable |
| LLDP support |
| USB |
1 USB 2.0 port, Type A |
| PHYSICAL CHARACTERISTICS |
| Physical Size |
23.3cm (L), 23.3cm (W), 4.8cm (H) |
| 9.2in (L) x 9.2in (W) x 1.9in (H) |
| Weight |
1.09kg |
| 2.40lbs |
| Mounting |
Wall, acoustic ceiling, desk |
| Bracket (902-0120-0000) |
| Physical Security |
Hidden latching mechanism |
| Secure bracket (sold separately) (902-0120-0000) |
| Operating Temperature |
0ºC (32ºF) to 50ºC (122ºF) |
| Operating Humidity |
Up to 95%, non-condensing |
