| CAPACITY |
| Managed APs |
• Up to 1,024 per controller
• Up to 3,000 per cluster |
| Managed Switches |
• Up to 50 per controller
• Up to 150 per cluster |
| WLANs (BSSIDs) |
Up to 2,048 |
| Concurrent Devices |
• Up to 25,000 per controller
• Up to 60,000 per cluster |
| KEY FUNCTIONALITY |
| Device Management |
• Ruckus Wi-Fi APs supported: R720, R710, R700, R610, R600, R510, R500, R310, H510 H320, C110, E510, T811CM, T710, T710S, T610, T610S, T504 T310, T301, T300, FZM300, FZP300
• Ruckus ICX 7000 series switches running FastIron 8.0.80 and above supported (ICX 7150, ICX 7250, ICX 7450, ICX 7650, ICX 7750) |
| Device Type Support |
Wi-Fi APs, Switches |
| Controller Expansion |
Up to 4 controllers in N+1 active-active mode, supporting non-disruptive capacity expansion |
| Controller Redundancy |
3+1 distributed data preserving with N+1 redundancy within a cluster |
| Cluster Redundancy |
Geo-redundancy between clusters; many-to-one cluster support |
| Data Offload |
Local offload of traffic directly to the Internet |
| AP |
• Internal database up to 25,000 users
• External: RADIUS, LDAP, Active Directory |
| Access Control |
• L2 (MAC address-based)
• L3/4 (IP and Protocol based)
• L2 client isolation
• Management interface access control
• Time-based WLANs
• Device type access policies
• Two-factor authentication password, SMS |
| Wireless Intrusion Detection (WIDS/WIPS) |
• Rogue AP detection / prevention
• Evil-twin/AP spoofing detection
• Ad hoc detection |
| AAA |
RADIUS (primary and backup) |
| Hotspot |
WISPr, Wi-Fi CERTIFIED, Passpoint™, HotSpot 2.0 |
| Guest Access |
Supported |
| Captive Portal |
Supported |
| Mesh |
Self-healing, Self-forming, Zero-touch provisioning |
| DHCP Server |
Up to 100,000 IP address leases per vSZ-D (in increments of 1,000 IP address leases) |
| NAT |
Up to 2 million sessions flows per vSZ-D (in increments of 100,000 session flows) |
| Media |
802.11e/WMM, U-APSD, Wi-Fi Calling Prioritization |
| mDNS Bonjour Fencing |
Supported |
| WISPr |
WISPr authentication, SZ downlink AP Survivability |
| Software Queues |
Per traffic type (4), per client |
| SmartCast Traffic Classification |
Automatic, heuristics and TOS based or VLAN-defined |
| Rate Limiting |
Supported |
| WLAN Prioritization |
Supported |
| Client Load Balancing |
Automatic |
| Band Load Balancingt |
Supported |
| AP Provisioning |
• L3 or L2 auto-discovery
• Auto-software upgrade
• Automatic channel optimization |
| Configuration Management |
• Secure multi-operator login (RBAC)
• Large scale (bulk) AP management tools
• Switch software and firmware upgrades
• Switch configuration management to be supported in an upcoming SmartZone release
• Per zone firmware versioning control
• Configuration audit trails
• Alarm and event notification (SNMP V1 / V2 / V3)
• Event Logging (Syslog)
• Integrated on-board remote accessible EMS functionality
• RESTful APIs (JSON)
• Web-UI
• CLI |
| PHYSICAL CHARACTERISTICS |
| Hypervisor Support for VSZ |
VMware 6.5, KVM CentOS 7.3 and above, Hyper-V Windows 2012 R2 and above, AWS, Azure, GCE |
| Power |
AC input requirements: 250 Watts |
| Dimensions |
1RU rack mountable: 438 mm (W) x 292.1 mm (D) x 44 mm (H); 17.25 in (W) x 11.5 in (D) x 1.73 in (H) |
| Weight |
11.02 lbs (5 kilograms) |
| Connections |
• 4 - 1GbE ports
• 2x10GE
• Console ports: two RJ-45, one front, one rear
• USB ports: two front, two rear
• Serial port
|
| LED |
Front panel LEDs, one rear LED |
| Fans |
Six redundant, field-swappable fans in three sets |
| Environmental Conditions |
• Operating Temperature: 32°F (0°C) –104°F (40°C)
• Operating Humidity: 5% to 85%, non-condensing
• Humidity storage: 95%, non-condensing |
| REGULATORY/CERTIFICATIONS |
| EMC |
• FCC/ICES-003-Emissions (USA/Canada)
• CISPR 22-Emissions (International)
• EN55022-Emissions (Europe)
• EN55024-Immunity (Europe)
• EN61000-3-2-Harmonics (Europe)
• EN61000-3-3-Voltage flicker (Europe)
• CE-EMC Directive 89/336/EEC (Europe)
• VCCI Emissions (Japan)
• AS/NZS: CISPR 22 Emissions (Australia/New Zealand)
• BSMI CNS13438 (Taiwan)
• CCC Certification (China) |
| Safety |
• UL60950-1/CSA 60950-1 (USA/Canada)
• EN60950-1 (Europe)
• IEC60950-1 (International), CB Certificate & Report including all international deviations
• CE-Low Voltage Directive 73/23/EEE (Europe)
• CCC Certification (China) |
| Miscellaneous |
NEBS level 3 design |
