| Model: |
SRX340 |
| Connectivity |
| Total onboard ports |
16x1GbE |
| Onboard RJ-45 ports |
8x1GbE |
| Onboard small form-factor pluggable (SFP) transceiver ports |
8x1GbE |
| MACsec-capable ports |
16x1GbE |
| Out-of-Band (OOB) management ports |
1x1GbE |
| Mini PIM (WAN) slots |
4 |
| Console (RJ-45 + miniUSB) |
1 |
| USB 3.0 ports (type A) |
1 |
| Optional PoE+ ports |
0 |
| Memory and Storage |
| System memory (RAM) |
4 GB |
| Storage (flash) |
8 GB |
| SSD slots |
1 |
| Dimensions and Power |
| Form factor |
1U |
| Size (WxHxD) |
17.36 x 1.72 x 14.57 in.
(44.09 x 4.36 x 37.01 cm) |
| Weight (device and PSU) |
10.80 lb (4.90 kg) |
| Redundant PSU |
No |
| Power supply |
AC (external) |
| Maximum PoE power |
N/A |
| Average power consumption |
122 W |
| Average heat dissipation |
420 BTU/h |
| Maximum current consumption |
1.364 A |
| Acoustic noise level |
45.5 dBA |
| Airflow/cooling |
Front to back |
| Environmental, Compliance, and Safety Certification |
| Operating temperature |
32° to 104° F (0° to 40° C) |
| Nonoperating temperature |
4° to 158° F (-20° to 70° C) |
| Operating humidity |
10% to 90% noncondensing |
| Nonoperating humidity |
5% to 95% noncondensing |
| Meantime between failures (MTBF) |
27 years |
| FCC classification |
Class A |
| RoHS compliance |
RoHS 2 |
| Common Criteria certification |
NDPP, VPNEP, FWEP, IPSEP (based on Junos 15.1X49-D60) |
| Performance and Scale |
| Routing with packet mode (64 B packet size) in Kpps5 |
550 |
| Routing with packet mode (IMIX packet size) in Mbps5 |
1,600 |
| Routing with packet mode (1,518 B packet size in Mbps5 |
3,000 |
| Stateful firewall (64 B packet size) in Kpps5 |
350 |
| Stateful firewall (IMIX packet size) in Mbps5 |
1,100 |
| Stateful firewall (1,518 B packet size) in Mbps5 |
3,000 |
| IPsec VPN (IMIX packet size) in Mbps5 |
200 |
| IPsec VPN (1,400 B packet size) in Mbps5 |
600 |
| Application visibility and control in Mbps6 |
1,000 |
| Recommended IPS in Mbps6 |
400 |
| Next-generation firewall in Mbps6 |
200 |
| Route table size (RIB/FIB) (IPv4 or IPv6) |
1 million/600,0007 |
| Maximum concurrent sessions (IPv4 or IPv6) |
256,000 |
| Maximum security policies |
2,000 |
| Connections per second |
10,000 |
| NAT rules |
2,000 |
| MAC table size |
15,000 |
| IPsec VPN tunnels |
1,024 |
| Number of remote access uses |
150 |
| GRE tunnels |
512 |
| Maximum number of security zones |
64 |
| Maximum number of virtual routers |
64 |
| Maximum number of VLANs |
2,000 |
| AppID sessions |
64,000 |
| IPS sessions |
64,000 |
| URLF sessions |
64,000 |
| WAN Interface |
| 1 port T1/E1 MPIM (SRX-MP-1T1E1-R) |
Yes |
| 1 port VDSL2 Annex A/M MPIM (SRX-MP-1VDSL2-R) |
Yes |
| 1 port serial MPIM (SRX-MP-1SERIAL-R) |
Yes |
| 4G / LTE MPIM (SRX-MP-LTE-AA & SRX-MP-LTE-AE) |
Yes |
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: SRX340 ?
Chào anh,
Anh hoàn toàn có thể sử dụng sản phẩm Juniper SRX340 cho mạng nội bộ 100 User. Nhân viên tư vấn CNTTShop sẽ liên hệ tới anh để tư vấn, anh vui lòng để ý điện thoại ạ.
Chào anh,
Nhân viên tư vấn CNTTShop sẽ liên hệ tới anh để báo giá SRX340, anh vui lòng để ý điện thoại ạ.
Thiết bị tường lửa Juniper SRX340 sử dụng nguồn tiêu thụ 122W
Thiết bị tường lửa Firewall Juniper SRX340 hỗ trợ tính năng cân bằng tải nhiều đường truyền, để sử dụng tính năng firewall thì cần mua kèm theo license
Báo giá License UTM / UTP SRX3400-CS-BUN-3 cho Firewall Juniper SRX340 đã được gửi vào mail, vui lòng chechk mail để biết được thông tin!
