Datasheet Aruba R9G12A
|
|
Interface
|
48x ports of 100M/1GbE/10GBASE-T
4x ports of 40GbE/100GbE (QSFP+/ QSFP28)
|
|
Additional ports and slots
|
|
Additional ports and slots
|
2x field-replaceable and hot-swappable power supplies
|
|
Fans
|
3x field-replaceable and hot-swappable fans
|
|
Management
|
RJ-45 serial and USB-C console; RJ-45 Ethernet port; USB-Type A
|
|
Physical characteristics
|
|
Physical Dimensions (HxWxD)
|
1.73in x 17.4in x 16.0in 44.0mm x 442.5mm x 406.4
|
|
Full configuration weight
|
18.85 lb.
8.55 kg
|
|
Memory and Processor
|
|
CPU
|
1.8 GHz 4-core 64-bit
|
|
Memory, Drive and Flash
|
16GB RAM, 32GB Flash/Storage
|
|
Packet Buffer
|
32MB
|
|
Performance
|
|
Switching Capacity
|
1.76Tbps
|
|
MAC Address Table Size
|
212,992
|
|
IPv4 Host Table
|
145,780
|
|
IPv6 Host Table
|
145,780
|
|
IPv4 Unicast Routes
|
606,977
|
|
IPv6 Unicast Routes
|
630,784
|
|
Maximum Number of Access Control List (ACL) Entries Ingress
|
IPv4 65,536, IPv6 16,384, MAC 65,536
|
|
Maximum Number of Access Control List (ACL) Entries Egress
|
IPv4 8,192, IPv6 2,048, MAC 8,192
|
|
Maximum VLANs
|
4,094
|
|
IGMP Groups
|
7,000
|
|
MLD Groups
|
7,000
|
|
IPv4 Multicast
Routes
|
7,000
|
|
IPv6 Multicast
Routes
|
7,000
|
|
Environment
|
|
Operating Temperature
|
32°F to 113°F
(0°C to 45°C) up
to 5000 ft
|
|
Operating Relative
Humidity
|
15% to 95%
relative humidity at
113°F (45°C),
non-condensing
|
|
Non-Operating
Temperature
|
-40°C to 70°C (-40°F to 158°F) up to 4.6km (15,000 ft.)
|
|
Non-Operating/
Storage Relative
Humidity
|
15% to 95% at 149°F (65°C) non-condensing
|
|
Maximum
Operating Altitude
|
Up to 10,000ft (3.048Km)
|
|
Maximum Non-
Operating Altitude
|
Up to 15,000ft (4.6Km)
|
|
Primary Airflow
|
Port-to-Power
(PwrToPrt)
|
|
BTU/hr
|
1,706
|
|
Acoustics9
|
LWAd = 6.7 Bel
LpAm (Bystander)
= 48.7 dB
|
|
Electrical Characteristics
|
|
Frequency
|
47-63 Hz
|
|
AC Voltage
Current
|
7.1A for 100-127VAC
3.4A for 200-240VAC
|
|
Power
Consumption
|
Max: 500W
Idle: 120W
|
|
Regulatory
|
|
Compliance
|
Products comply with CE Markings according to directives 2014/30/EU (EMC) and 2014/35/EU (Safety)
|
|
RoHS
|
EN 50581:2012
|
|
Safety
|
|
EU
|
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013
EN62368-1, Ed.2:2014
|
|
North America
|
UL/CUL 69050-1: 2nd Edition
UL/CUL 63268-1:2014
UL60950-1, CSA 22.2 No 60950-1
|
|
Worldwide
|
IEC60950-1:2005 Ed.2 + Am 1:2009 + A2:2013
IEC 62368-1:2014
|
|
EMC
|
EN 55024:2010+A2016/CISPR24:2015
EN55032:2015/CISPR 32, Class A
EN55035:2017/CISPR 35
EN61000-3-2:2014, Class A
EN61000-3-3:2013
FCC CFR 47 Part 15:2010, Class A
ICES-003, Class A
VCCI Class A
CNS 13438
CNS 13438 Class A
|
|
Laser
|
|
Transceivers
|
EN60825-1:2014 / IEC 60825-1: 2014 Class 1
Class 1 Laser Products / Laser Klasse 1
|
|
Mounting
|
Mounts in an EIA standard 19-inch rack or other equipment cabinet; horizontal surface mounting only; 2-post and 4-post
mounting options available10; air duct available for 4-post deployments and sold separately
|
