Vender :BDCOM
Part Number : S2218PB
Bảo hành : 12 tháng
Made In : China
Switch BDCOM S2218PB là một bộ chuyển mạch truy nhập thông minh POE thế hệ mới được thiết kế dành cho mạng IP của nhà khai thác và mạng doanh nghiệp. Dựa trên phần cứng hiệu suất cao và nền tảng BDROS, nó hỗ trợ các chức năng như ACL, QinQ và QoS. Chế độ quản lý đơn giản và cài đặt linh hoạt có thể đáp ứng yêu cầu của bất kỳ yêu cầu phức tạp nào.
Item | Description |
Backplane | 21.2Gbps |
Forwarding rate | 8.4Mpps |
MAC | 8K |
Ports | 16 100M Base-T ports + 2 gigabit combo ports |
Dimensions(mm) (W×H×D) | 440×232×44 |
Consumption | <15W |
POE/POE+ | Support |
POE power | 330W |
Power supply |
AC: 100V-240V, 50Hz±10% |
Environment |
Operating temperature and humidity: 0℃-50℃, 10%-90% non-condensing Storage temperature and humidity: -20℃-70℃;5%-95% non-condensing |
MAC exchange |
Static configuration and dynamic MAC learning MAC browsing and removal Configurable aging time of the MAC address Limited number of learnable MAC addresses MAC filtration |
VLAN |
4K VLAN GVRP QinQ Private VLAN |
STP |
802.1D (STP), 802.1W (RSTP), 802.1S (MSTP) BPDU protection, root protection, and loopback protection |
Multicast |
IGMP v1/v2/v3 IGMP Snooping IGMP Fast Leave Multicast group strategy and quantity limitation Multicast flow copying over VLANs (S2108POE does not support the function.) |
IPv6 |
ICMPv6, DHCPv6, ACLv6 and IPv6 Telnet IPv6 neighbor discovery Path MTU discovery MLD V1/V2 IGMP snooping |
QoS |
Flow classification based on L2~L4 protocols (S2108POE does not support this.) CAR flow limit 802.1P/DSCP priority re-labeling (S2108POE does not support this.) SP, WRR, and “SP+WRR” Congestion avoidance mechanisms like Tail-Drop and WRED Flow monitoring and flow shaping |
Security features |
L2/L3/L4 ACL flow identification and filtration (S2108POE does not support this.) Defend against DDoS attack, TCP’s SYN Flood attack and UDP Flood attack Broadcast/multicast/unknown unicast storm-control Port isolation Port security, and “IP + MAC + port” binding (S2108POE does not support this.) DHCP Snooping and DHCP option 82 (S2108POE does not support this.) IEEE 802.1x authentication Radius, BDTacacs+ authentication Level-based command line protection |
Reliability |
Static/LACP link aggregation EAPS and ERPS (S2108POE does not support this.) ISSU uninterrupted system upgrade |
Management |
Console, Telnet, SSH2.0, Web SNMP v1/v2/v3 TFTP RMON |
100M optical modules |
|
FSFP-SX-1310 |
100M SFP multi-mode (2Km, 1310nm, LC, DDM) |
FSFP-LX-15 |
100M SFP single mode (15Km, 1310nm, LC, DDM) |
FSFP-LX-40 |
100M SFP single mode (40Km, 1310nm, LC, DDM) |
FSFP-ZX-80 |
100M SFP single mode (80Km, 1550nm, LC, DDM) |
FSFP-LX-SM1310-20-BIDI FSFP-LX-SM1550-20-BIDI |
100M SFP single mode, single core bidirectional (20Km, TX1310/RX1550, LC, DDM) 100M SFP single mode, single core bidirectional (20Km, TX1550/RX1310, LC, DDM) |
FSFP-LX-SM1310-40-BIDI FSFP-LX-SM1550-40-BIDI |
100M SFP single mode, single core bidirectional (40Km, TX1310/RX1550, LC, DDM) 100M SFP single mode, single core bidirectional (40Km, TX1550/RX1310, LC, DDM) |
FSFP-LX-SM1310-80-BIDI FSFP-LX-SM1550-80-BIDI |
100M SFP single mode, single core bidirectional(80Km, TX1310/RX1550, LC, DDM) 100M SFP single mode, single core bidirectional(80Km, TX1550/RX1310, LC, DDM) |
GE optical modules |
|
GSFP-TX-B |
GE SFP-to- RJ45 module |
GSFP-SX-D |
GE SFP multi-mode (500m, 850nm, LC, DDM) |
GSFP-LX-10-D |
GE SFP single mode (10Km, 1310nm, LC, DDM) |
GSFP-LX-20-D |
GE SFP single mode (20Km, 1310nm, LC, DDM) |
GSFP-LX-40-D |
GE SFP single mode (40Km, 1310nm, LC, DDM) |
GSFP-ZX-80-D |
GE SFP single mode (80Km, 1550nm, LC, DDM) |
GSFP-LX-SM1310-10-BIDI GSFP-LX-SM1550-10-BIDI |
GE SFP single mode, single core bidirectional (10Km, TX1310/RX1550, LC, DDM) GE SFP single mode, single core bidirectional (10Km, TX1550/RX1310, LC, DDM) |
GSFP-LX-SM1310-20-BIDI GSFP-LX-SM1550-20-BIDI |
GE SFP single mode, single core bidirectional (20Km, TX1310/RX1550, LC, DDM) GE SFP single mode, single core bidirectional (20Km, TX1550/RX1310, LC, DDM) |
GSFP-LX-SM1310-40-BIDI GSFP-LX-SM1550-40-BIDI-1310 |
GE SFP single mode, single core bidirectional (40Km, TX1310/RX1550, LC, DDM) GE SFP single mode, single core bidirectional (40Km, TX1550/RX1310, LC, DDM) |
GSFP-LX-SM1490-80-BIDI GSFP-LX-SM1550-80-BIDI |
GE SFP single mode, single core bidirectional (80Km, TX1490/RX1550, LC, DDM) GE SFP single mode, single core bidirectional (80Km, TX1550/RX1490, LC, DDM) |
GSFP-LX-SM1490-120 GSFP-LX-SM1550-120 |
GE SFP single mode, single core bidirectional (120Km, TX1490/RX1550, LC, DDM) GE SFP single mode, single core bidirectional (120Km, TX1550/RX1490, LC, DDM) |
