| Specifications |
| Port |
- 24x RJ45
- 4x SFP+
- 1x Serial Console
- 1x USB |
| Hardware |
| Internal Fans |
Fanless |
| Reset Button |
Yes |
| Flash Storage |
128 MB |
| DRAM |
512 MB |
| Feature |
| Layer 2 |
802.1s multiple spanning tree, VLAN, Port, Protocol, 802.1q, 802.1d, 802.1x authentication, Auto MDI/MDIX, BPDU Guard, Root Guard, IGMP Snooping v1/v2/v3*, Fast Leave, LLDP/LLDP MED, IGMP Proxy, Static MAC, Flow Control per port, Per VLAN STP (PVST/PVRST), Port Mirroring: port based, ACL based,
VLAN based, Port Isolation/Private VLAN Edge, Link Aggregation Groups (Static/LACP), Rate Limiting/Storm Control, Jumbo frame (9k), DHCP Snooping, BPDU filtering, Broadcast/Multicast/Unlearned Unicast (Storm Control), DoS Protection, Ping/TraceRoute/ICMPv6 |
| Layer 3 |
Inter-VLAN Routing, Static ARPs, Static Routes, DHCP Relay, Dynamic Routing – RIPv1/v2, Dynamic Routing – OSPFv2, Route Redistribution |
| Management |
cnMaestro (cloud management), Industry standard Command Line Interface (CLI), DHCP Client, Embedded web management (HTTP/HTTPS), Embedded DHCP server, USB file management and storage, Out-of-Band Ethernet Management, SSH / SSH v2, SNMP v1/v2/v3, DHCP relay, Simple Network Time Protocol (SNTP), Local/remote system logging, Policy Based Automation, Display log messages multiple terminals*, TFTP/SFTP, Telnet client/server, IPv6 management, Password management, Autoinstall support for firmware images and config files |
| Security |
Source/Destination IP address, TCP/UDP Source/Destination port, IP Protocol Type, Type of Service (ToS) or differentiated services
(DSCP) field, Source/Destination MAC address, EtherType, IEEE 802.1p user priority, VLAN ID, RFC 1858—Security Considerations for IP
Fragment Filtering |
| Performance |
| Throughput |
128 Gbps |
Forwarding Rate in Mpps
(64 Byte Packets) |
120 |
MAC Address
Table Size |
16K |
| VLANs |
4K |
| Port Based VLANs |
4K |
| LACP/Trunking |
8 LAGs/8 links per LAG |
| QoS Priority Queues |
8 |
| PVRST |
32 |
| Ingress/Egress ACL |
128 |
| Static ARP Entries |
512 |
| ARP Entries |
512 |
| Static Routes |
64 |
| Dynamic Routing |
512 |
| IGMP Multicast Groups |
256 |
| Policy Based Automation |
Yes |
