Cisco Meraki MS350-24X-HW 16 Ports GE, 8 Ports mGig UPoE 740W, 4 SFP+ Uplinks

• 16 x 10/100/1000BASE-T Ethernet RJ45 with auto negotiation and auto-MDIX
• 8 x 100M/1G/2.5G/5/10G Ethernet RJ45 with auto negotiation and autoMDIX3
• 4 x SFP+ 10G uplink
• 2 x stacking ports

• 272 Gbps

• 160 Gbps

• 202.38 mpps

• 9600 byte Ethernet frame

• 802.3af (PoE) 15.4 W per port
• 802.3at (PoE+) 25.5 W per port
• Up to 60W per mGig port
• Maximum PoE output: 740 W
• PoE available simultaneously on all ports
• Intelligent PoE power allocation based on device advertisement (LLDP)

• Managed via the Web with the Meraki cloud management platform
• Integrated with Meraki wireless, security appliance, and device management
• Zero-touch remote provisioning (no staging needed)
• Detailed historical per-port and per-client usage statistics
• DHCP, client, and hostname fingerprinting
• SNMPD allows integration with third party network management solutions
• Automatic firmware upgrades

• Email, SMS and Mobile push notification alerts
• Ping, traceroute, cable testing, and link failure detection with alerting
• Remote packet capture
• Dynamic and interactive network discovery and topology
• Combined event and configuration change logs with instant search

• Physically stack up to 8 switches with 160 Gbps of stacking bandwidth on all models
• Virtual stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration

• 802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)
• 802.1Q VLAN and trunking support for up to 4,094 VLANs
• 802.1w, 802.1D Rapid Spanning Tree Protocol (RSTP, STP)
• STP Enhancements: BPDU guard, Root guard, Loop guard, UDLD
• Broadcast storm control
• 802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP)
• 802.3ad Link aggregation with up to 8 ports per aggregate, Multichassis aggregates supported on stacked switches
• Port mirroring IGMP snooping for multicast filtering
• MAC forwarding entries: 512K

• Integrated multi-factor authentication for Dashboard management
• Role-based access control (RBAC) with granular device and configuration control
• Corporate wide password policy enforcement
• IEEE 802.1X RADIUS and MAB, hybrid authentication and RADIUS server testing
• Single-Host/Multi-Domain/Multi-Host/Multi Authentication
• Port security: Sticky MAC, MAC whitelisting
• DHCP snooping, detection and blocking, Dynamic ARP Inspection
• IPv4 and IPv6 ACLs

• Non-blocking fabric
• 2.5 microsecond latency
• Jumbo frame support (9600 byte Ethernet frame)

• Static routing, OSFPv2 (with support for up to 16 ECMP Routes)
• Multicast routing [PIM-ASM]
• Warm Spare (VRRP)
• DHCP Server, DHCP Relay

• Power input: 100 - 240 VAC, 47-63 Hz
• Power consumption: 5-888W

• 1U rack-mountable with included rack mount hardware
• 2-post front mounting options available

• Operating temperature: -5°C to 50°C
• Humidity: 5 to 95% non-condensing
• Variable speed fans

• CSA (US)
• IC (Canada)
• CE (Europe)
• C-Tick (Australia/New Zealand)
• RoHS
