Switch Cisco Nexus N2K-C2224TF-1GE 24x100/1000Base-T + 2x10GE
Thiết bị mạng Switch Cisco Nexus N2K-C2224TF-1GE (N2K C2224TF 1GE) 1GE Fabric Extender, 2 AC PS, 1 Fan Module, 24x100/1000Base-T + 2x10GE chính hãng chất lượng tốt
Cam Kết Bán Hàng
✓ Đầy Đủ CO/CQ
✓ Hỗ Trợ Đại Lý Và Dự Án
✓ Giao Hàng Trên Toàn Quốc
✓ Sản Phẩm Chính Hãng™ 100%
✓ Cam Kết Giá Rẻ Nhất Thị Trường
✓ Bảo Hành, Đổi Trả Nhanh Chóng
✓ Hỗ Trợ Kỹ Thuật Chuyên Nghiệp, Nhiệt Tình
CNTTShop.vn - Trên 10 năm Uy tín cung cấp Thiết bị mạng & Dịch vụ Giải pháp mạng trên toàn quốc.
NTT03, Thống Nhất Complex, 82 Nguyễn Tuân, Thanh Xuân, Hà Nội. Số 31B, Đường 1, Phường An Phú, Quận 2 (Thủ Đức), TP HCM.Thiết bị mạng switch cisco Nexus N2K-C2224TF-1GE 1GE Fabric Extender, 2 AC PS, 1 Fan Module (Standard Airflow/port side exhaust), 24x100/1000Base-T + 2x10GE (includes 4 Fabric Extender Transceivers)
Switch cisco Nexus N2K-C2224TF-1GE Cisco Nexus® 2000 Series
Thông số kỹ thuật :
|
Cisco Nexus 2224TF-1GE Fabric Extender - expansion module |
|
|
Device Type |
Expansion module |
|
Form Factor |
Rack-mountable |
|
Ports |
Gigabit Ethernet x 24 |
|
Dimensions (WxDxH) |
43.9 cm x 45 cm x 4.4 cm |
|
Weight |
7.5 kg |
|
Cabling Type |
Ethernet 100Base-TX, Ethernet 1000Base-T |
|
Auxiliary Ports |
2 x SFP+ |
|
Data Link Protocol |
100Mb LAN, GigE |
|
Network / Transport Protocol |
TCP/IP, UDP/IP, ICMP/IP |
|
Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.3ae |
|
Manufacturer Warranty |
1 year warranty |
Extended Specification
|
General |
|
|
Device Type |
Expansion module |
|
Form Factor |
Rack-mountable |
|
Dimensions & Weight |
|
|
Depth |
45 cm |
|
Height |
4.4 cm |
|
Weight |
7.5 kg |
|
Width |
43.9 cm |
|
Environmental Parameters |
|
|
Humidity Range Operating |
5 - 95% |
|
Max Operating Temperature |
40 °C |
|
Min Operating Temperature |
0 °C |
|
Expansion / Connectivity |
|
|
Expansion Slots |
2 (total) / 0 (free) x SFP+ |
|
Interfaces |
24 x 1000Base-T - RJ-45 |
|
Manufacturer Warranty |
|
|
Service & Support |
Limited warranty - replacement - 1 year |
|
Miscellaneous |
|
|
Compliant Standards |
CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1 |
|
Included Accessories |
4 Fabric Extender transceivers |
|
Networking |
|
|
Auxiliary Ports |
2 x SFP+ |
|
Cabling Type |
Ethernet 100Base-TX, Ethernet 1000Base-T |
|
Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.3ae |
|
Connectivity Technology |
Wired |
|
Data Link Protocol |
100Mb LAN, GigE |
|
Features |
Flow control, full duplex capability, uplink, hot swap module replacement, auto-negotiation, VLAN support, IGMP snooping, Syslog support, Weighted Round Robin (WRR) queuing, IPv6 support, Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support |
|
Network / Transport Protocol |
TCP/IP, UDP/IP, ICMP/IP |
|
Ports |
Gigabit Ethernet x 24 |
|
Remote Management Protocol |
SNMP 1, SNMP 2, RMON, SNMP 3 |
|
Status Indicators |
Port status, power, system |
|
Power |
|
|
Power Device |
Power supply - hot-plug / redundant - plug-in module |
Các loại nguồn sử dụng cho switch cisco N2K-C2224TF-1GE:
| N2200-PAC-400W | Cisco Nexus 2200 AC Power supply (Std airflow, port side exhaust), spare |
| N2200-PAC-400W-B | Cisco Nexus 2200 AC Power supply, Back-to-front airflow (Reversed airflow, port side intake), spare |
| N2200-PDC-400W | Cisco Nexus 2200 DC Power supply (Std airflow, port side exhaust), spare |
| N2200-PDC-350W-B | Cisco Nexus 2200 DC Power supply, Back-to-front airflow (Reversed airflow, port side intake), spare |
Các loại module quang, cable cisco sử dụng cho switch cisco N2K-C2224TF-1GE:
| GLC-T | 1000BASE-T SFP |
| GLC-SX-MM | GE SFP, LC connector SX transceiver |
| GLC-LH-SM | GE SFP, LC connector LX/LH transceiver |
| SFP-GE-T | 1000BASE-T SFP, Extended Temperature Range |
| SFP-GE-S | GE SFP, LC connector SX transceiver, with Digital Optical Monitoring (DOM) and Extended Temperature Range |
| SFP-GE-L | GE SFP, LC connector LX/LH transceiver, with Digital Optical Monitoring (DOM) and Extended Temperature Range |
| SFP-10G-SR | 10GBASE-SR SFP+ Module |
| SFP-10G-LR | 10GBASE-LR SFP+ Module |
| SFP-H10GB-CU1M | 10GBASE-CU SFP+ Passive Cable 1 Meter |
| SFP-H10GB-CU3M | 10GBASE-CU SFP+ Passive Cable 3 Meter |
| SFP-H10GB-CU5M | 10GBASE-CU SFP+ Passive Cable 5 Meter |
| SFP-H10GB-ACU7M | 10GBASE-CU SFP+ Active Cable 7 Meter |
| SFP-H10GB-ACU10M | 10GBASE-CU SFP+ Active Cable 10 Meter |
| QSFP-40G-SR4 | 40GBASE-SR4 QSFP module, (multi-mode fiber, MMF at 100m) |
| QSFP-40G-CSR4 | 40GBASE Extended CSR4 QSFP module, (multi-mode fiber, MMF at 300m) |
| QSFP-H40G-CU1M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 1-meter, passive |
| QSFP-H40G-CU3M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 3-meter, passive |
| QSFP-H40G-CU5M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 5-meter, passive |
| QSFP-H40G-ACU7M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 7-meter, active |
| QSFP-H40G-ACU10M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 10-meter, active |
| QSFP-4SFP10G-CU1M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 1-meter, passive |
| QSFP-4SFP10G-CU3M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 3-meter, passive |
| QSFP-4SFP10G-CU5M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 5-meter, passive |
| QSFP-4x10G-AC7M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 7-meter, active |
| QSFP-4x10G-AC10M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 10-meter, active |
| SFP-10G-AOC1M | Cisco 10GBASE-AOC SFP+ Cable 1 Meter |
| SFP-10G-AOC2M | Cisco 10GBASE-AOC SFP+ Cable 2 Meter |
| SFP-10G-AOC3M | Cisco 10GBASE-AOC SFP+ Cable 3 Meter |
| SFP-10G-AOC5M | Cisco 10GBASE-AOC SFP+ Cable 5 Meter |
| SFP-10G-AOC7M | Cisco 10GBASE-AOC SFP+ Cable 7 Meter |
| SFP-10G-AOC10M | Cisco 10GBASE-AOC SFP+ Cable 10 Meter |
| QSFP-4X10G-AOC1M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 1-meter |
| QSFP-4X10G-AOC2M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 2-meter |
| QSFP-4X10G-AOC3M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 3-meter |
| QSFP-4X10G-AOC5M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 5-meter |
| QSFP-4X10G-AOC7M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 7-meter |
| QSFP-4X10G-AOC10M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 10-meter |
| QSFP-H40G-AOC1M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 1-meter |
| QSFP-H40G-AOC2M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 2-meter |
| QSFP-H40G-AOC3M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 3-meter |
| QSFP-H40G-AOC5M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 5-meter |
| QSFP-H40G-AOC7M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 7-meter |
| QSFP-H40G-AOC10M | Cisco 40GBase-AOC QSFP direct-attach Active Optical, 10-meter |
| QSFP-H40G-AOC15M | Cisco 40GBase-AOC QSFP direct-attach Active Optical, 15-meter |
| SFP-10G-AOC1M | Cisco 10GBASE-AOC SFP+ Cable 1 Meter |
