Thiết bị mạng Switch Cisco Nexus N2K-C2224TP-1GE 1GE Fabric Extender, 2 AC PS, 1 Fan Module (Standard Airflow/port side exhaust), 24x100/1000Base-T + 2x10GE

Name: N2K-C2224TP-1GE
Brand: CISCO
SKU: N2K-C2224TP-1GE
Availability: InStock
Rating: 5 (45 reviews)

Switch cisco Nexus N2K-C2224TP-1GE thuộc dòng sản phẩm Cisco Nexus^® 2000 Series, là sản phẩm được thiết kế để đơn giản hóa kiến trúc và và hoạt động tại các trung tâm dữ liệu.

Thông số kỹ thuật :

Basic Specifications
Manufacturer's Part Number	N2K-C2224TP-1GE
Product Description	Cisco Nexus 2224TP-1GE Fabric Extender - expansion module
Device Type	Expansion module
Weight	16.6 lb (7.53 kg)
Dimensions (HxWxD)	1.72 x 17.3 x 17.7 in. (4.37 x 43.94 x 44.96 cm)
Manufacturer Warranty	1 year warranty
Form Factor	Rack-mountable
Data Link Protocol	100Mb LAN, GigE
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.3ae
Cabling Type	Ethernet 100Base-TX, Ethernet 1000Base-T
Ports	Gigabit Ethernet x 24 + 10 Gigabit SFP+ x 2
Network / Transport Protocol	TCP/IP, UDP/IP, ICMP/IP
Ports Qty	24 ports
Auxiliary Ports	2 x SFP+
Model	Cisco Nexus 2224TP Fabric Extender
Environmental Parameters
Min Operating Temperature	0 °C
Max Operating Temperature	40 °C
Humidity Range Operating	5 - 95%
Miscellaneous
Compliant Standards	CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1
Networking
Ports	Gigabit Ethernet x 24 + 10 Gigabit SFP+ x 2
Connectivity Technology	Wired
Cabling Type	Ethernet 100Base-TX, Ethernet 1000Base-T
Data Link Protocol	100Mb LAN, GigE
Auxiliary Ports	2 x SFP+
Network / Transport Protocol	TCP/IP, UDP/IP, ICMP/IP
Remote Management Protocol	SNMP 1, SNMP 2, RMON, SNMP 3
Status Indicators	Port status, power, system
Features	Flow control, full duplex capability, uplink, hot swap module replacement, auto-negotiation, VLAN support, IGMP snooping, Syslog support, Weighted Round Robin (WRR) queuing, IPv6 support, Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.3ae
Power
Power Device	Power supply - hot-plug / redundant - plug-in module

Các loại nguồn sử dụng cho switch cisco N2K-C2224TP-1GE:

N2200-PAC-400W	Cisco Nexus 2200 AC Power supply (Std airflow, port side exhaust), spare
N2200-PAC-400W-B	Cisco Nexus 2200 AC Power supply, Back-to-front airflow (Reversed airflow, port side intake), spare

Các loại module quang, cable cisco sử dụng cho switch cisco N2K-C2224TP-1GE:

GLC-T	1000BASE-T SFP
GLC-SX-MM	GE SFP, LC connector SX transceiver
GLC-LH-SM	GE SFP, LC connector LX/LH transceiver
SFP-GE-T	1000BASE-T SFP, Extended Temperature Range
SFP-GE-S	GE SFP, LC connector SX transceiver, with Digital Optical Monitoring (DOM) and Extended Temperature Range
SFP-GE-L	GE SFP, LC connector LX/LH transceiver, with Digital Optical Monitoring (DOM) and Extended Temperature Range
SFP-10G-SR	10GBASE-SR SFP+ Module
SFP-10G-LR	10GBASE-LR SFP+ Module
SFP-H10GB-CU1M	10GBASE-CU SFP+ Passive Cable 1 Meter
SFP-H10GB-CU3M	10GBASE-CU SFP+ Passive Cable 3 Meter
SFP-H10GB-CU5M	10GBASE-CU SFP+ Passive Cable 5 Meter
SFP-H10GB-ACU7M	10GBASE-CU SFP+ Active Cable 7 Meter
SFP-H10GB-ACU10M	10GBASE-CU SFP+ Active Cable 10 Meter
QSFP-40G-SR4	40GBASE-SR4 QSFP module, (multi-mode fiber, MMF at 100m)
QSFP-40G-CSR4	40GBASE Extended CSR4 QSFP module, (multi-mode fiber, MMF at 300m)
QSFP-H40G-CU1M	Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 1-meter, passive
QSFP-H40G-CU3M	Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 3-meter, passive
QSFP-H40G-CU5M	Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 5-meter, passive
QSFP-H40G-ACU7M	Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 7-meter, active
QSFP-H40G-ACU10M	Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 10-meter, active
QSFP-4SFP10G-CU1M	Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 1-meter, passive
QSFP-4SFP10G-CU3M	Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 3-meter, passive
QSFP-4SFP10G-CU5M	Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 5-meter, passive
QSFP-4x10G-AC7M	Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 7-meter, active
QSFP-4x10G-AC10M	Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 10-meter, active
SFP-10G-AOC1M	Cisco 10GBASE-AOC SFP+ Cable 1 Meter
SFP-10G-AOC2M	Cisco 10GBASE-AOC SFP+ Cable 2 Meter
SFP-10G-AOC3M	Cisco 10GBASE-AOC SFP+ Cable 3 Meter
SFP-10G-AOC5M	Cisco 10GBASE-AOC SFP+ Cable 5 Meter
SFP-10G-AOC7M	Cisco 10GBASE-AOC SFP+ Cable 7 Meter
SFP-10G-AOC10M	Cisco 10GBASE-AOC SFP+ Cable 10 Meter
QSFP-4X10G-AOC1M	Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 1-meter
QSFP-4X10G-AOC2M	Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 2-meter
QSFP-4X10G-AOC3M	Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 3-meter
QSFP-4X10G-AOC5M	Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 5-meter
QSFP-4X10G-AOC7M	Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 7-meter
QSFP-4X10G-AOC10M	Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 10-meter
QSFP-H40G-AOC1M	Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 1-meter
QSFP-H40G-AOC2M	Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 2-meter
QSFP-H40G-AOC3M	Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 3-meter
QSFP-H40G-AOC5M	Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 5-meter
QSFP-H40G-AOC7M	Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 7-meter
QSFP-H40G-AOC10M	Cisco 40GBase-AOC QSFP direct-attach Active Optical, 10-meter
QSFP-H40G-AOC15M	Cisco 40GBase-AOC QSFP direct-attach Active Optical, 15-meter
SFP-10G-AOC1M	Cisco 10GBASE-AOC SFP+ Cable 1 Meter
