Switch cisco Nexus N2K-C2232TM
Thiết bị mạng switch cisco Nexus N2K-C2232TM (N2K C2232TM) 10GBASE-T Fabric Extender, 2PS, 1 Fan Module, 32x1/10GBase-T + 8x10GE Module (req SFP+) chính hãng giá tốt
Câu hỏi thường gặp khi mua hàng?
Thiết bị mạng switch cisco Nexus N2K-C2232TM 10GBASE-T Fabric Extender, 2PS, 1 Fan Module, 32x1/10GBase-T + 8x10GE Module (req SFP+)
Switch cisco Nexus N2K-C2232TM thuộc dòng sản phẩm Cisco Nexus® 2000 Series, là sản phẩm được thiết kế để đơn giản hóa kiến trúc và và hoạt động tại các trung tâm dữ liệu.
Thông số kỹ thuật :
|
Cisco Nexus 2232TM 10GE Fabric Extender - expansion module |
|
|
Device Type |
Expansion module |
|
Form Factor |
Rack-mountable |
|
Ports |
Gigabit Ethernet / 10Gb Ethernet / FCoE x 32 + 10 Gigabit SFP+ x 8 |
|
Dimensions (WxDxH) |
43.94 cm x 44.96 cm x 4.37 cm |
|
Weight |
8.4 kg |
|
Cabling Type |
Ethernet 1000Base-T, Ethernet 10GBase-T |
|
Data Link Protocol |
GigE, 10 GigE, FCoE |
|
Performance |
Forwarding performance (full duplex): 160 Gbps ¦ Forwarding performance: 560 Gbps ¦ Forwarding performance: 595 Mpps |
|
Capacity |
ACL entries: 256 ¦ Policies: 64 |
|
Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ae, IEEE 802.3an |
|
Manufacturer Warranty |
1 year warranty |
Extended Specification
|
General |
|
|
Device Type |
Expansion module |
|
Form Factor |
Rack-mountable |
|
Dimensions & Weight |
|
|
Depth |
44.96 cm |
|
Height |
4.37 cm |
|
Weight |
8.4 kg |
|
Width |
43.94 cm |
|
Environmental Parameters |
|
|
Humidity Range Operating |
5 - 95% (non-condensing) |
|
Max Operating Temperature |
40 °C |
|
Min Operating Temperature |
0 °C |
|
Expansion / Connectivity |
|
|
Expansion Slots |
8 (total) / 8 (free) x SFP+ |
|
Interfaces |
32 x 10Gb Ethernet / FCoE - RJ-45 |
|
Manufacturer Warranty |
|
|
Service & Support |
Limited warranty - advance parts replacement - 1 year |
|
Miscellaneous |
|
|
Compliant Standards |
CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, CSA C22.2 No. 60950-1, Directive 2004/108/EC, Directive 2006/95/EC, VCCI Class A, CNS 13438(95) Class A, KN22 Class A, GB4943.1-2011 |
|
Networking |
|
|
Cabling Type |
Ethernet 1000Base-T, Ethernet 10GBase-T |
|
Capacity |
ACL entries: 256 ¦ Policies: 64 |
|
Compliant Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ae, IEEE 802.3an |
|
Connectivity Technology |
Wired |
|
Data Link Protocol |
GigE, 10 GigE, FCoE |
|
Features |
Flow control, full duplex capability, auto-negotiation, VLAN support, Cisco Gigabit EtherChannel, Syslog support, Weighted Round Robin (WRR) queuing, Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, Management Information Base (MIB), hot swappable fan, Class of Service (CoS), tagged VLAN, SNMP support, Virtual PortChannel (vPC) technology, hot swappable power supply |
|
Performance |
Forwarding performance (full duplex): 160 Gbps ¦ Forwarding performance: 560 Gbps ¦ Forwarding performance: 595 Mpps |
|
Ports |
Gigabit Ethernet / 10Gb Ethernet / FCoE x 32 + 10 Gigabit SFP+ x 8 |
|
Remote Management Protocol |
SNMP 1, SNMP 2, RMON, SNMP 3, CLI |
|
Status Indicators |
Port status, power, system, module locator, fan |
|
Power |
|
|
Power Device |
Plug-in module |
Các loại nguồn sử dụng cho switch cisco N2K-C2232TM:
| N2200-PAC-400W | Cisco Nexus 2200 AC Power supply (Std airflow, port side exhaust), spare |
| N2200-PAC-400W-B | Cisco Nexus 2200 AC Power supply, Back-to-front airflow (Reversed airflow, port side intake), spare |
| N2200-PDC-400W | Cisco Nexus 2200 DC Power supply (Std airflow, port side exhaust), spare |
Các loại module quang, cable cisco sử dụng cho switch cisco N2K-C2232TM:
| GLC-T | 1000BASE-T SFP |
| GLC-SX-MM | GE SFP, LC connector SX transceiver |
| GLC-LH-SM | GE SFP, LC connector LX/LH transceiver |
| SFP-GE-T | 1000BASE-T SFP, Extended Temperature Range |
| SFP-GE-S | GE SFP, LC connector SX transceiver, with Digital Optical Monitoring (DOM) and Extended Temperature Range |
| SFP-GE-L | GE SFP, LC connector LX/LH transceiver, with Digital Optical Monitoring (DOM) and Extended Temperature Range |
| SFP-10G-SR | 10GBASE-SR SFP+ Module |
| SFP-10G-LR | 10GBASE-LR SFP+ Module |
| SFP-H10GB-CU1M | 10GBASE-CU SFP+ Passive Cable 1 Meter |
| SFP-H10GB-CU3M | 10GBASE-CU SFP+ Passive Cable 3 Meter |
| SFP-H10GB-CU5M | 10GBASE-CU SFP+ Passive Cable 5 Meter |
| SFP-H10GB-ACU7M | 10GBASE-CU SFP+ Active Cable 7 Meter |
| SFP-H10GB-ACU10M | 10GBASE-CU SFP+ Active Cable 10 Meter |
| QSFP-40G-SR4 | 40GBASE-SR4 QSFP module, (multi-mode fiber, MMF at 100m) |
| QSFP-40G-CSR4 | 40GBASE Extended CSR4 QSFP module, (multi-mode fiber, MMF at 300m) |
| QSFP-H40G-CU1M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 1-meter, passive |
| QSFP-H40G-CU3M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 3-meter, passive |
| QSFP-H40G-CU5M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 5-meter, passive |
| QSFP-H40G-ACU7M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 7-meter, active |
| QSFP-H40G-ACU10M | Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 10-meter, active |
| QSFP-4SFP10G-CU1M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 1-meter, passive |
| QSFP-4SFP10G-CU3M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 3-meter, passive |
| QSFP-4SFP10G-CU5M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 5-meter, passive |
| QSFP-4x10G-AC7M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 7-meter, active |
| QSFP-4x10G-AC10M | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 10-meter, active |
| SFP-10G-AOC1M | Cisco 10GBASE-AOC SFP+ Cable 1 Meter |
| SFP-10G-AOC2M | Cisco 10GBASE-AOC SFP+ Cable 2 Meter |
| SFP-10G-AOC3M | Cisco 10GBASE-AOC SFP+ Cable 3 Meter |
| SFP-10G-AOC5M | Cisco 10GBASE-AOC SFP+ Cable 5 Meter |
| SFP-10G-AOC7M | Cisco 10GBASE-AOC SFP+ Cable 7 Meter |
| SFP-10G-AOC10M | Cisco 10GBASE-AOC SFP+ Cable 10 Meter |
| QSFP-4X10G-AOC1M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 1-meter |
| QSFP-4X10G-AOC2M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 2-meter |
| QSFP-4X10G-AOC3M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 3-meter |
| QSFP-4X10G-AOC5M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 5-meter |
| QSFP-4X10G-AOC7M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 7-meter |
| QSFP-4X10G-AOC10M | Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 10-meter |
| QSFP-H40G-AOC1M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 1-meter |
| QSFP-H40G-AOC2M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 2-meter |
| QSFP-H40G-AOC3M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 3-meter |
| QSFP-H40G-AOC5M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 5-meter |
| QSFP-H40G-AOC7M | Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 7-meter |
| QSFP-H40G-AOC10M | Cisco 40GBase-AOC QSFP direct-attach Active Optical, 10-meter |
| QSFP-H40G-AOC15M | Cisco 40GBase-AOC QSFP direct-attach Active Optical, 15-meter |
| SFP-10G-AOC1M | Cisco 10GBASE-AOC SFP+ Cable 1 Meter |
Bạn đang cần tư vấn về sản phẩm: #N2K-C2232TM ?
