Switch cisco Nexus N2K-C2248TP 48x100/1000Base-T + 4x10GE

Thiết bị mạng switch cisco Nexus N2K-C2248TP (N2K C2248TP) 1GE Fabric Extender, 2PS, 1 Fan Module, 48x100/1000Base-T + 4x10GE (req SFP+) chính hãng chất lượng tốt

Mã sản phẩm: N2K-C2248TP
Tình trạng: Còn hàng
Check Giá List

Thiết bị mạng switch cisco Nexus 1GE Fabric Extender, 2PS, 1 Fan Module, 48x100/1000Base-T + 4x10GE

Switch cisco Nexus N2K-C2248TP thuộc dòng sản phẩm Cisco Nexus® 2000 Series tối đa hiệu năng.

Thiết bị mạng switch cisco Nexus 1GE Fabric Extender, 2PS, 1 Fan Module, 48x100/1000Base-T + 4x10GE

Thông số kỹ thuật :

Model

Brand: Cisco
Model: N2K-C2248TP

Details

Supported Model: Expansion module - 48 ports
Specifications
4 x SFP+ (uplink)

48 x network - Ethernet 100Base-TX/1000Base-T - RJ-45

Fast Ethernet, Gigabit Ethernet

Các loại nguồn sử dụng cho switch cisco N2K-C2248TP:

N2200-PAC-400W Cisco Nexus 2200 AC Power supply (Std airflow, port side exhaust), spare
N2200-PAC-400W-B Cisco Nexus 2200 AC Power supply, Back-to-front airflow (Reversed airflow, port side intake), spare
N2200-PDC-400W Cisco Nexus 2200 DC Power supply (Std airflow, port side exhaust), spare
N2200-PDC-350W-B Cisco Nexus 2200 DC Power supply, Back-to-front airflow (Reversed airflow, port side intake), spare

Các loại module quang, cable cisco sử dụng cho switch cisco N2K-C2248TP:

GLC-T
1000BASE-T SFP
GLC-SX-MM GE SFP, LC connector SX transceiver
GLC-LH-SM GE SFP, LC connector LX/LH transceiver
SFP-GE-T 1000BASE-T SFP, Extended Temperature Range
SFP-GE-S GE SFP, LC connector SX transceiver, with Digital Optical Monitoring (DOM) and Extended Temperature Range
SFP-GE-L GE SFP, LC connector LX/LH transceiver, with Digital Optical Monitoring (DOM) and Extended Temperature Range
SFP-10G-SR 10GBASE-SR SFP+ Module
SFP-10G-LR 10GBASE-LR SFP+ Module
SFP-H10GB-CU1M 10GBASE-CU SFP+ Passive Cable 1 Meter
SFP-H10GB-CU3M 10GBASE-CU SFP+ Passive Cable 3 Meter
SFP-H10GB-CU5M 10GBASE-CU SFP+ Passive Cable 5 Meter
SFP-H10GB-ACU7M 10GBASE-CU SFP+ Active Cable 7 Meter
SFP-H10GB-ACU10M 10GBASE-CU SFP+ Active Cable 10 Meter
QSFP-40G-SR4 40GBASE-SR4 QSFP module, (multi-mode fiber, MMF at 100m)
QSFP-40G-CSR4 40GBASE Extended CSR4 QSFP module, (multi-mode fiber, MMF at 300m)
QSFP-H40G-CU1M Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 1-meter, passive
QSFP-H40G-CU3M Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 3-meter, passive
QSFP-H40G-CU5M Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 5-meter, passive
QSFP-H40G-ACU7M Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 7-meter, active
QSFP-H40G-ACU10M Cisco 40GBASE-CR4 QSFP+ direct-attach copper cable, 10-meter, active
QSFP-4SFP10G-CU1M Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 1-meter, passive
QSFP-4SFP10G-CU3M Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 3-meter, passive
QSFP-4SFP10G-CU5M Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 5-meter, passive
QSFP-4x10G-AC7M Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 7-meter, active
QSFP-4x10G-AC10M Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ direct-attach breakout cable, 10-meter, active
SFP-10G-AOC1M Cisco 10GBASE-AOC SFP+ Cable 1 Meter
SFP-10G-AOC2M Cisco 10GBASE-AOC SFP+ Cable 2 Meter
SFP-10G-AOC3M Cisco 10GBASE-AOC SFP+ Cable 3 Meter
SFP-10G-AOC5M Cisco 10GBASE-AOC SFP+ Cable 5 Meter
SFP-10G-AOC7M Cisco 10GBASE-AOC SFP+ Cable 7 Meter
SFP-10G-AOC10M Cisco 10GBASE-AOC SFP+ Cable 10 Meter
QSFP-4X10G-AOC1M Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 1-meter
QSFP-4X10G-AOC2M Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 2-meter
QSFP-4X10G-AOC3M Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 3-meter
QSFP-4X10G-AOC5M Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 5-meter
QSFP-4X10G-AOC7M Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 7-meter
QSFP-4X10G-AOC10M Cisco 40GBase-AOC QSFP to 4 SFP+ Active Optical breakout Cable, 10-meter
QSFP-H40G-AOC1M Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 1-meter
QSFP-H40G-AOC2M Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 2-meter
QSFP-H40G-AOC3M Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 3-meter
QSFP-H40G-AOC5M Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 5-meter
QSFP-H40G-AOC7M Cisco 40GBase-AOC QSFP direct-attach Active Optical Cable, 7-meter
QSFP-H40G-AOC10M Cisco 40GBase-AOC QSFP direct-attach Active Optical, 10-meter
QSFP-H40G-AOC15M Cisco 40GBase-AOC QSFP direct-attach Active Optical, 15-meter
SFP-10G-AOC1M Cisco 10GBASE-AOC SFP+ Cable 1 Meter
