Thiết bị chuyển mạch HPE OfficeConnect 1850 48G 4XGT Switch thiết bị chuyển mạch HPE JL171A switch HPE JL171A chính hãng giá rẻ tại Hà Nội
Mã sản phẩm: JL171A
HPE Part Number : JL171A Thiết bị chuyển mạch HPE JL171A được thiết kế để hoạt động phù hợp với lớp Accees (lớp truy nhập mạng đầu cuối) với chi phí đầu tư là thấp trong dòng HPE OfficeConnect 1850 Switch Series. Thiết bị chuyển mạch HPE JL171A được tăng cường bảo mật bằng cách sử dụng các công nghệ virtual LANs, link aggregation, hoặc IGMP Snooping boost uplink performance, và loop prevention enhances network reliability. Switch HPE JL171A sử dụng điện AC 220V. Thiết bị chuyển mạch HPE JL171A cho phép dễ dàng quản lý ngay cả bởi người dùng không biết kỹ thuật thông qua giao diện Wed trực quan, hỗ trợ HTTP và HTTP Secure (HTTPS) Thiết bị chuyển mạch HPE OfficeConnect 1850 48G 4XGT Switch thiết bị chuyển mạch HPE JL171A switch HPE JL171A chính hãng giá rẻ tại Hà Nội 48 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only 4 RJ-45 1/10GBASE-T ports Dimensions: 17.42(w) x 9.7(d) x 1.73(h) in (44.25 x 24.64 x 4.4 cm) (1U height) 100 Mb Latency < 9.7 µs (64-byte packets) Operating temperature: 32°F to 104°F (0°C to 40°C) Frequency: 50/60 Hz ESD: IEC 61000-4-2 Radiated: IEC 61000-4-3 EFT/Burst: IEC 61000-4-4 Surge: IEC 61000-4-5 Conducted: IEC 61000-4-6 Power frequency magnetic field: IEC 61000-4-8 Voltage dips and interruptions: IEC 61000-4-11 Harmonics: EN 61000-3-2, IEC 61000-3-2 Flicker:EN 61000-3-3, IEC 61000-3-3 JL169A HPE OfficeConnect 1850 6XGT and 2XGT/SPF+ Switch JL170A HPE OfficeConnect 1850 24G 2XGT Switch JL171A HPE OfficeConnect 1850 48G 4XGT Switch JL172A HPE OfficeConnect 1850 24G 2XGT PoE+ 185W Switch JL173A HPE OfficeConnect 1850 48G 4XGT PoE+ 370W Switch Để có cấu hình, yêu cầu kỹ thuật chi tiết của thiết bị chuyển mạch HPE JL171A cho vào hồ sơ tư vấn, thiết kế kỹ thuật hoặc cho vào hồ sơ mời thầu, quý khách vui long gửi email yêu cầu đến kinhdoanh@cnttshop.vnThiết bị chuyển mạch HPE JL171A OfficeConnect 1850 48G 4XGT Switch
Bảo hành : 12 tháng
Made In : China
Stock : Hàng có sẵnMô tả sản phẩm
Thông số kỹ thuật chi tiết của thiết bị chuyển mạch HPE JL171A:
I/O ports and slots
Physical characteristics
Weight: 7.05 lb (3.2 kg)
Memory and processor
BCM53346 embedded ARM Cortex-A9 @ 400 MHz, 128 MB DDR3 SDRAM; Packet buffer size: 3 MB
Mounting and enclosure
wall, desktop and under table mounting
Performance
1000 Mb Latency < 3.7 µs (64-byte packets)
10 Gbps Latency < 3.7 µs (64-byte packets)
ThrougHPEut up to 131 Mpps (64-byte packets)
Switching capacity: 176 Gbps
MAC address table size: 16000 entries
Environment
Operating relative humidity: 5% to 95%, noncondensing
Nonoperating/Storage temperature:-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage relative humidity:15% to 95% @ 140°F (60°C)
Altitude: up to 9,842 ft (3 km)
Acoustic: Power: 34 dB
Electrical characteristics
Voltage: 100 - 127 / 200 - 240 VAC, rated
Maximum power rating: 29.5 W
Idle power 19.4 W
Notes: Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated
Safety
UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1
Emissions
VCCI Class A; CNS 13438; ICES-003 Issue5 Class A; FCC CFR 47 Part 15, Class A ; EN 55032: 2015/CISPR-32
Immunity
Quý khách có thể tham khảo thêm các dòng switch HPE OfficeConnect 1850 Switch Series:
