| Model |
IS320-52TF-AC |
| Hardware Specification |
| Physical Traffic Port |
48*10/100/1000M Base-T interfaces
4*1G SFP interfaces
|
| Switching Capability |
104Gbps |
| Fixed Power Supply |
Dual |
| Fixed Fan |
Yes |
| Max PoE Power Consumption |
N/A |
| PoE Standard |
N/A |
|
Power Consumption
(Without PoE)
|
≤55W |
| Dimension (W×D×H)mm |
442×320×44.2 |
| Physical Management Port |
1*RJ45 Console
1*USB2.0 Port
|
| Input Voltage |
AC:100-240V/50-60Hz |
| Temperature |
Work Temperature: -5℃ to 50℃
Storage Temperature: -40℃ to 70℃
|
| Humidity |
Work Humidity:10%～90%, non-condensing
Storage Humidity:5%～95%, non-condensing
|
| Anti-Lightning |
6KV |
| Anti-Static |
6KV |
| MTBF |
>80000 hours |
| Performance Parameters |
| MAC Address Entry |
16K |
| Jumbo Frame |
12K |
| ARP Entry |
2K |
| ND Entry |
1.5K |
| VLAN Entry |
4K |
| LACP Group |
64 |
| LACP Member in Group |
8 |
| MSTP Instance |
64 |
| L2 Multicast Entry |
3K |
| Software Specification |
| Interface |
| Physical Interface |
Auto MDI/MDIX, Port Type UNI/NNI, Port Speed, Port MTU, Switch Port, Port Loopback, Port Energy Control |
| Logic Interface |
Loopback Interface, L2/L3 VLAN Interface, L3 Ethernet Interface |
| MAC Address Management |
Storm Control, Flood Control, MAC Address Aging Time, Mac Address Learning on|off, Mac Address Learning Limitation, Mac Address VLAN Bunding, MAC Debug |
| VLAN |
| VLAN Management |
VLAN, QinQ, Flexible QinQ, VLAN PVID, VLAN Tag/Untag, VLAN Trunk, MAC VLAN, Protocol VLAN, Subnet VLAN, Super VLAN, Voice VLAN, Private VLAN, Guest VLAN, VLAN Debug, GVRP, VLAN Isolation |
| Ring Protection |
| Spanning Tree Protocols |
STP/RSTP/MSTP, BPDU Guard, Flap Guard, Loop Guard, Root Guard, TC Guard |
| Other Ring Protocols |
VIST/VIST+, G.8032(ERPSv1&v2) |
| Link Aggregation |
| LACP Configuration |
LACP Link Aggregation, LACP Port Priority, LACP Load Balance, LACP Rate Monitor, LACP Debug |
| Error Handling |
| Error-disable Configuration |
Error-disable Based on bpduguard|Dai|DHCP Snooping|Link-Flap|Loopback-detect|Port Security|Storm Control|Transceiver Power, Error-disable Recovery |
| Fault Detection |
| Fault Detection Features |
ULFD, Track, Loop-back Detection, CFM (802.1ag) |
| IP Services |
| IP Protocol |
ARP, DNS, NTP Server/Client, ICMP |
| Routing Protocol |
Static Routing v4/v6 |
| DHCP Service |
DHCP v4/v6 Client, DHCP Snooping, DHCP Option51/82 |
| Multicast Protocols |
| L2 Multicast Protocols |
IGMPv1/v2/v3 Snooping, IGMP Snooping Proxy, MLD Snooping, MVR, MVP |
| QoS |
| Priority Mapping |
802.1P Priority, DSCP priority |
| Traffic Classification |
Three Color Marker, Priority Remark, Traffic Redirect, Traffic Meter, Traffic Mirror |
| Traffic Control |
Rate Limitation, Traffic Shaping |
| Scheduling Algorithm |
SP, RR, WRR, WDRR, SP+WRR, SP+WDRR |
| Congestion Management |
Tail-drop, RED, WRED |
| Security |
| Port Security |
Port Security On aging|deny|permit|violation|ACL |
| Network Access Control |
IP Source Guard (ISG), DHCP Snooping, ND Snooping, Host Guard |
| Threat Prevention |
Dynamic ARP Inspection (DAI), ARP Check, AARF ARP-Guard, ARP Speed Limit, ARP Source Suppression, PPPoE+ |
| Access Control List |
Standard IP ACL, Extended IP ACL, Standard MAC ACL, Extended MAC ACL, Standard Hybrid ACL, Extended Hybrid ACL, Standard IPv6 ACL, Extended IPv6 ACL, Time-based ACL |
| Anti-Attack |
Anti-Attack Detect|Drop|Flood|Log, URPF, White List, Black List |
| AAA |
AAA, Radius, TACACS+, 802.1x, Portal |
| High Availability |
| Device Virtualization |
H-VST, M-VST |
| Multi-Active Detection |
MAD LACP, MAD BFD, MAD Fast-Hello, MAD LACP |
| High Availability Protocols |
HA, ULFD, UDLD, G.8032, ULPP, Monitor Link, EEP, BFD with Static Route |
| Configuration and Maintenance |
| Monitoring and Diagnostics |
SPAN, RSPAN, VLAN SPAN, sFlow, Telemetry, LLDP |
| Device Management |
TR069, SNMP v1/v2/v3, MIB, RMON, SYSLOG, WEB(HTTP/HTTPS), CLI, Telnet, FTP/FTPS/TFTP/SFTP, Debug, Telemetry, ISSU, Hot Patch, Keepalive Gateway, Cloud Management |
| Zero Touch Provisioning |
ZTP Provisioning Through DHCP Server, ZTP Provisioning Through USB Flash Disk |
| IEEE Standard |
IEEE 802.3 (10BASE-T)
IEEE 802.3u (100BASE-T)
IEEE 802.3z (1000BASE-X)
IEEE 802.3ab (1000BASE-T)
IEEE 802.3ae (10G BASE-X)
IEEE 802.3ah (Ethernet in the First Mile Operations, Administration, and Maintenance)
IEEE 802.1x (Port-Based Network Access Control)
IEEE 802.3ad (Link Aggregation)
IEEE 802.3x (Flow Control)
IEEE 802.3az (Energy Efficient Ethernet)
IEEE 802.1d (Spanning Tree Protocol)
IEEE 802.1ab (Link Layer Discovery Protocol)
IEEE 802.1Q (Virtual LAN)
IEEE 802.1w (Rapid Spanning Tree Protocol)
IEEE 802.1s (Multiple Spanning Tree Protocol)
IEEE 802.1p (Class of Service Priority)
IEEE 802.1ag (Connectivity Fault Management)
|
