| UAP-AC-IW-PRO |
| Environment |
Indoor |
| 2.4 GHz Radio Rate |
450 Mbps |
| 2.4 GHz MIMO |
3x3 |
| 5 GHz Radio Rate |
1300 Mbps |
| 5 GHz MIMO |
3x3 |
| Dimensions |
139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01") |
| Weight |
210 g (7.41 oz) |
| Networking Interface |
10/100/1000 Ethernet Ports |
| Secondary Ethernet Port |
(2 Additional Ports) |
| Buttons |
Reset |
| Power Method |
802.3at PoE+ Supported |
| Power Supply |
UniFi Switch (PoE) |
| Power Save |
Supported |
| PoE Out |
48V Pass-Through (Pins 1, 2+; 3, 6-) |
| Maximum Power Consumption |
10W
with PoE Passthrough: 22W
|
| TX Power |
2.4 GHz: 22 dBm
5 GHz: 22 dBm |
| Antennas |
2.4 GHz: (1) Dual-Band Antenna, Single-Polarity 5 dBi
5 GHz: (1) Dual-Band Antenna, Single-Polarity 6.5 dBi |
| Wi-Fi Standards |
802.11 a/b/g/n/ac |
| Wireless Security |
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| BSSID |
8 per Radio |
| Mounting |
1-Gang Electrical Wall Box (Not Included) |
| Operating Temperature |
-10 to 50° C (14 to 122° F) |
| Operating Humidity |
5 to 95% Noncondensing |
| Certifications |
CE, FCC, IC |
| Advanced Traffic Management |
| VLAN |
802.1Q |
| Advanced QoS |
Per-User Rate Limiting |
| Guest Traffic Isolation |
Supported |
| WMM |
Voice, Video, Best Effort, and Background |
| Concurrent Clients |
250+ |
| Supported Data Rates (Mbps) |
| Standard |
Data Rates |
| 802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n |
6.5 Mbps to 450 Mbps (MCS0 - MCS15, HT 20/40) |
| 802.11ac |
6.5 Mbps to 1300 Mbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80) |
| 802.11b |
1, 2, 5.5, 11 Mbps |
| 802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
