| UAP-IW-HD |
| Environment |
Indoor |
| 2.4 GHz Radio Rate |
300 Mbps |
| 2.4 GHz MIMO |
2x2 |
| 5 GHz Radio Rate |
1733 Mbps |
| 5 GHz MIMO |
4x4 |
| Dimensions |
139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01") |
| Weight |
210 g |
| Networking Interface |
10/100/1000 Ethernet Ports |
| Secondary Ethernet Port |
(4 Additional Ports) |
| Buttons |
Reset |
| Power Method |
802.3af PoE, 802.3at PoE+ |
| Supported Voltage Range |
44 to 57VDC |
| Power Supply |
UniFi Switch (PoE) |
| Power Save |
Supported |
| PoE Out |
48V Passthrough (Pins +1, 2; -3, 6) |
| Beamforming |
Supported |
| Maximum Power Consumption |
11W
with PoE Passthrough: 23W
|
| TX Power |
2.4 GHz: 23 dBm
5 GHz: 26 dBm |
| Antennas |
(2) Single-Port, Single-Polarity Dual-Band Antennas, 2.4 GHz: 1.8 dBi Each, 5 GHz: 3.4 dBi Each
(2) Single-Port, Dual-Polarity, Single-Band Antennas, 5 GHz: 6 dBi Each
|
| Wi-Fi Standards |
802.11 a/b/g/n/ac/ac-wave2 |
| Wireless Security |
WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) 802.11w/PMF |
| BSSID |
8 per Radio |
| Mounting |
1-Gang Electrical Wall Box (Not Included) |
| Operating Temperature |
-10 to 60° C (14 to 140° F) |
| Operating Humidity |
5 to 95% Noncondensing |
| Certifications |
CE, FCC, IC |
| Advanced Traffic Management |
| VLAN |
802.1Q |
| Advanced QoS |
Per-User Rate Limiting |
| Guest Traffic Isolation |
Supported |
| WMM |
Voice, Video, Best Effort, and Background |
| Concurrent Clients |
200+ |
| Supported Data Rates (Mbps) |
| Standard |
Data Rates |
| 802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11n |
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| 802.11ac |
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80) |
| 802.11b |
1, 2, 5.5, 11 Mbps |
| 802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
Switch
.png){kind=icon}
.png){kind=logo}
.jpg)
.png){kind=logo}
Bạn đang cần tư vấn về sản phẩm: UAP-IW-HD ?
Chào anh/chị, bộ phát wifi UAP-IW-HD theo thông số của nhà sản xuất đưa ra có thể chịu tải tối đa 200 client, tuy nhiên trong thực tế nên dùng cho dưới 100 client.
