| Access Point Specifications |
Max PHY
Rate |
2.4 GHz: 300 Mbps
5 GHz: 867 Mbps |
| Ports |
Five x IEEE 100/100/1000 Mbps Ethernet
Auto Sensing |
| Power |
12VDC, 1 A, 2.1 mm x 5.5 mm CP, DC barrel connector
Localized power supply included |
| Antenna |
2.4 GHz: 5 dBi
5 GHz: 5 dBi
Omni |
| Max EIRP |
2.4 GHz: 27 dBm
5 GHz: 20 dBm |
| Dimensions, weight, acoustic, MTBF, and environmental range |
| Dimensions |
190 mm x 135 mm x 40 mm
(7.48 in x 5.31 in x 1.57 in) |
| Weight |
900 g (1.98 lbs) |
| LEDs |
Power, WLAN, Port status LEDs |
Ambient Operating
Temperature |
0ºC to 40ºC
(32ºF to 104ºF) |
Storage
Temperature |
-20ºC to 70ºC
(-4ºF to 158ºF) |
| Humidity |
95% RH non-condensing |
Certifications
(Compliance) |
FCC, IC, CE, EN 60601-1-2, EN 60950-1
WEEE & RoHS |
| WLAN and Network Specifications |
| WLAN |
64 clients, 8 SSIDs |
Management
Features |
Firmware Upgrade, Web Management
Interface, Local and Remote Syslog
(RFC3164), Auto Provisioning, Time
Synchronization, Multi User Level |
Management
Protocols |
TR-069, TR-098, TR-0104, TR-0106,
TR-0143
cnMaestro Cloud or on-premises VM,
SNTP, SNMPv2, Telnet |
Authentication
SSID Security |
WEP, WPA-PSK (TKIP), WPA2-PSK (TKIP),
WPA2-PSK (AES), Open, Mixed mode |
| Subscriber QoS |
WMM, DSCP, 802.1p |
| Network |
NAT router or Bridge mode, DDNS,
MAC address cloning, wired speed NAT
Router, DHCP Server and Client, IP conflict
detection, Port forwarding |
| Security |
DMZ, Rate Limiting, Passthrough, Firewall
(SYN Flooding, IP Spoofing, Smurf Attack,
Ping of Death, DoS) |
| Wi-Fi Protocols |
VHT MCS rates, 16/64/256-QAM, 20/40/80 MHz
AMSDU, AMPDU, RIFS, STBC, LDPC, MIMO Power Save, MRC, BPSK, QPSK, CCK, DSSS, OFDM,
IEEE 802.11 a/ac/b/d/e/g/h/i/n |
Other Network
Protocols |
DHCP/PPPoE, HTTP Server for Web Management, TFTP/HTTP for Auto Provisioning, DHCP Option Codes for SIP
(RFC3361), DNS/DNS SRV (RFC1706 and RFC 2782), IEEE802.1Q VLAN, 802.1P, DSCP, IGMPv2 snooping,
PPTP/L2TP VPN |
