| CONFIGURATION |
| Chassis Dimensions |
11” diameter |
| Supported Standards |
802.11a/b/g/n/ac Wave 1 (Wave 2 ready) |
| Total Radio Slots |
4 |
| Total Number of Radios |
4 - 2.4GHz / 5GHz software programmable |
| Radio Type |
3X3 11ac, 1.3Gbps |
| MIMO Technology |
SU-MIMO |
| Channel Bonding |
80MHz |
| Maximum Wi-Fi Bandwith |
5.2Gbps |
| Wi-Fi Threat Sensor |
Yes |
| Integrated Antennas |
12 |
| Maximum Associated Devices |
960 |
| Radio Interface |
2.5Gbps PCI-Express |
| Max SSIDs |
16 |
| Max VLANs |
64 |
| Wired Uplinks - support four modes 802.3ad link aggregation, broadcast, link-backup, load balancing |
2-1GbE |
| Maximum Power Consumption |
37W |
| Weight |
2 lbs |
| TECHNICAL SPECIFICATIONS |
| RF Management |
• Dynamic channel configuration
• Dynamic cell size configuration
• Monitor radio for threat assessment and mitigation
• Wired and Wireless RMON / Packet Captures
• Radio assurance for radio self test and healing
• RF monitor
• 2.4 & 5Ghz Honeypot Control – Increase available 2.4 & 5Ghz wireless device density through management of spurious 2.4 & 5Ghz association traffic.
• Re-use and increase wireless device density through tight power controls. |
| High Availability |
Supports hot stand-by mode for mission critical areas |
| Environmentally Friendly |
Supports ability to turn off radios based on schedule configuration |
| Wireless Protocols |
IEEE 802.11a, 802.11ac, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11w |
| Wired Protocols |
• IEEE 802.3 10BASE-T, IEEE 802.3.u 100BASE-TX , 1000BASE-T, 802.3ab 1000BASE-T
• IEEE 802.1q – VLAN tagging
• IEEE 802.3ad– Link aggregation
• IEEE 802.1d – Spanning tree
• IEEE 802.1p – Layer 2 traffic prioritization
• DHCP option 82 |
| Carrier Applications |
Passpoint 2.0 Certification |
| RFC Support |
• RFC 768 UDP
• RFC 791 IP
• RFC 2460 IPV6 (Bridging only)
• RFC 792 ICMP
• RFC 793 TCP
• RFC 826 ARP
• RFC 1122 Requirements for internet hosts – communication layers
• RFC 1542 BOOTP
• RFC 2131 DHCP |
| Security |
• WPA
• IEEE 802.11i WPA2, RSN
• RFC 1321 MD5 Message-digest algorithm
• RFC 2246 TLS protocol version 1.0
• RFC 3280 Internet X.509 PKI certificate and CRL profile
• RFC 4347 Datagram transport layer security
• RFC 4346 TLS protocol version 1.1 |
| Encryption Types |
Open, WEP, TKIP-MIC: RC4 40, 104 and 128 bits
SSL and TLS: RC4 128-bit and RDA 1024 and 2048 bit |
| Authentication |
• IEEE 802.1x
• RFC 2548 Microsoft vendor-specific RADIUS attributes
• RFC 2716 PPP EAP-TLS
• RFC 2865 RADIUS Authentication
• RFC 2866 RADIUS Accounting
• RFC 2867 Tunnel Accounting
• RFC 2869 RADIUS Extensions
• RFC 3576 Dynamic Authorizations extensions to RADIUS
• RFC 3579 RADIUS Support for EAP
• RFC 3748 EAP-PEA
• RFC 5216 EAP-TLS
• RFC 5281 EAP-TTLS
• RFC 2284 EAP-GTC
• RFC 4186 EAP-SIM
• RFC 3748 Leap Passthrough
• RFC 3748 Extensible Authentication Protocol
• Web Page Authentication
• WPR, Landing Page, Redirect
• Support for Internal WPR, Landing Page and Authentication
• Support for External WPR, Landing Page and Authentication
• Support for Xirrus EasyPass Access Services |
| EMC, Safety and Wireless |
• FCC CFR 47 Part 15, Class B
• ICES-003 Class B
• FCC Subpart C 15.247
• FCC Subpart E 15.407
• RSS-247
• EN 301 893
• EN 300 328
• EN 301 489 1 & 17
• EN 62311
• EN 55022 (CISPR 22)
• AS/NZS4268 + CISPR22 |
| Safety |
• IEC 60950-1
• EN 60950-1
• UL 60950-1
• CSA 22.2 No.60950-1A
• AS/NZS 60950.1 |
| Environmental |
Operating Temperature: 0-50°C, 5-90% humidity, non-condensing
Storage Temperature: -40°C to 70°C |
| Channel Support 2.4GHz (based on country code selection) |
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14 |
| Channel Support 5GHz (based on country code selection) |
• U-NII-1 – Non-DFS channels
• 36 40 44 48
• U-NII-2A DFS channels
• 52 56 60 64
• U-NII-2C DFS channels
• 100 104 108 112 116 120 124 128 132 136 140 144
• U-NII-3 Non-DFS channels
• 149 153 157 161 165 |
| Management Interfaces |
• Command Line Interface (accessible via SSH or Telnet)
• Web interface (http / https)
• Xirrus Management System (XMS)
• XMS-Cloud
• XMS-Enterprise |
