| CONFIGURATION |
| Chassis Dimensions |
26.8mm(H) X 86mm (W) X 150mm (L) |
| Supported Standards |
802.11a/b/g/n/ac |
| Total Number of Radios |
2 |
| Radio Type |
2x2 11ac (Wave1), 867Mbps |
| MIMO Technology |
SU-MIMO |
| Maximum Wi-Fi Bandwidth |
1.1Gbps |
| Integrated Antennas |
4 |
| Maximum Associated Devices |
256 |
| Wired Uplinks - support four modes |
1 GbE PoE/PoE+ uplink with RJ-45 or 110 punch down block 4 GbE (including 1 PoE output with PoE+ or DC input) 1 pass through port , 48 V DC connector , Reset button |
| Max SSIDs |
8 |
| Max VLANs |
52 |
| Maximum Power Consumption |
46W |
| Weight |
1lbs |
| TECHNICAL SPECIFICATIONS |
| RF Management |
- Dynamic channel configuration
- Dynamic cell size configuration
- RF monitor
- Re-use and increase wireless device density through tight power controls
|
| Wireless Protocols |
IEEE 802.11a, 802.11ac, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11k, 802.11n |
| Wired Protocols |
- IEEE 802.3 10BASE-T, IEEE 802.3.u 100BASE-TX , 1000BASE-T, 802.3ab 1000BASE-T
- IEEE 802.1q – VLAN tagging
- IEEE 802.1d – Spanning tree
- IEEE 802.11r - Fast Transition Roaming
|
| RFC Support |
- RFC 768 UDP
- RFC 791 IP
- RFC 792 ICMP
- RFC 793 TCP
|
| Security |
- IEEE 802.11i WPA2, RSN
- RFC 1321 MD5 Message-digest algorithm RFC 2246 TLS protocol version 1.0
- RFC 3280 Internet X.509 PKI certificate and CRL profile
- Per port RADIUS MAC authentication and accounting
|
| Encryption Types |
• Open, WEP, TKIP-MIC: RC4 40, 104 and 128 bits
• SSL and TLS: RC4 128-bit and RDA 1024 and 2048 bit |
| Authentication |
• IEEE 802.1x
• RFC 2548 Microsoft vendor-specific RADIUS attributes
• RFC 2716 PPP EAP-TLS
• RFC 2865 RADIUS Authentication
• RFC 2866 RADIUS Accounting
• RFC 2867 Tunnel Accounting
• RFC 2869 RADIUS Extensions
• RFC 3576 Dynamic Authorizations extensions to RADIUS
• RFC 3579 RADIUS Support for EAP
• RFC 3748 EAP-PEAP
• RFC 5216 EAP-TLS
• RFC 5281 EAP-TTLS
• RFC 2284 EAP-GTC
• RFC 4186 EAP-SIM
• RFC 3748 Leap Passthrough
• RFC 3748 Extensible Authentication Protocol
• Support for External WPR, Landing Page and Authentication
• Support for EasyPass Access Services – Guest, Onboarding, Voucher and Personal Wi-Fi |
| EMC, Safety and Wireless |
• FCC CFR 47 Part 15, Class B
• ICES-003 Class B
• FCC Subpart C 15.247
• FCC Subpart E 15.407
• RSS-247
• EN 301 893
• EN 300 328
• EN 301 489 1 & 17
• EN 62311
• EN 55022/EN 55024/EN 55032
• AS/NZS4268 + CISPR22 |
| Safety |
• IEC 60950-1
• EN 60950-1
• UL 60950-1
• CSA 22.2 No.60950-1-03
• AS/NZS 60950.1
• Air handling space (UL 2043) |
| Environmental |
• Operating Temperature: 0-50°C, 5-90% humidity, non-condensing
• Storage Temperature: -40°C to 70°C |
| Channel Support 2.4GHz (based on country code selection) |
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14 |
| Channel Support 5GHz (based on country code selection) |
• U-NII-1 – Non-DFS channels
• 36 40 44 48
• U-NII-2A DFS channels
• 52 56 60 64
• U-NII-2C DFS channels
• 100 104 108 112 116 120 124 128 132 136 140 144
• U-NII-3 Non-DFS channels
• 149 153 157 161 165 |
| Management Interfaces |
• Command Line Interface (accessible via SSH or Telnet)
• Web interface (http / https)
• Xirrus Management System (XMS)
• XMS-Cloud
• XMS-Enterprise |
