| CONFIGURATION |
| Chassis Dimensions |
17” |
| Total Radio Slots |
16 |
| Populated 802.11n Radios |
8 |
| Radio Type |
300Mbps Multi-State (2.4GHz or 5GHz) |
| Maximum Wi-Fi Bandwidth |
2.4Gbps |
| Dedicated Wi-Fi Threat Sensor |
Yes |
| Integrated Antennas |
16 |
| Max Wi-Fi Backhaul |
1.35Gbps |
| Integrated Wi-Fi Switch Ports |
16 |
| Gigabit Ethernet Uplink Ports |
4 |
| SFP+ 10 Gigabit Modular Expansion Port |
1 |
| Maximum Associated Users |
1920 |
| Radio Interface |
2.5Gbps PCI-Express |
| RF Management |
• In-band per IAP spectrum analysis
• Dynamic channel configuration
• Dynamic cell size configuration
• Monitor radio for threat assessment and mitigation
• Wired and wireless packet captures (including all 802.11 headers)
• Radio Assurance for radio self test and healing
• RF monitor |
| High Availability |
Supports hot stand-by Array for mission critical areas |
| Environmentally Friendly |
Supports ability to turn off radios based on schedule configuration |
| Wireless Protocols |
IEEE 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11n |
| Wired Protocols |
• IEEE 802.3 10BASE-T , IEEE 802.3.u 100BASE-TX , • 1000BASE-T, 802.3ab 1000BASE-T
• IEEE 802.1q - VLAN tagging
• IEEE 802.1AX - Link aggregation
• IEEE 802.1d - Spanning tree
• IEEE 802.1p - Layer 2 traffic prioritization |
| RFC Support |
• RFC 768 UDP
• RFC 791 IP
• RFC 2460 IPV6 (Bridging only)
• RFC 792 ICMP
• RFC 793 TCP
• RFC 826 ARP
• RFC 1122 Requirements for internet hosts - communication layers
• RFC 1542 BOOTP
• RFC 2131 DHCP |
| Security |
• WPA
• IEEE 802.11i WPA2, RSN
• RFC 1321 MD5 message-digest algorithm
• RFC 2246 TLS protocol version 1.0
• RFC 3280 Internet X.509 PKI certificate and CRL profile
• RFC 4347 Datagram transport layer security
• RFC 4346 TLS protocol version 1.1 |
| Encryption Types |
• Open, WEP, TKIP-MIC: RC4 40, 104 and 128 bits
• SSL and TLS: RC4 128-bit and RDA 1024 and 2048 bit |
| Authentication |
IEEE 802.1x
RFC 2548 Microsoft vendor-specific RADIUS attributes
RFC 2716 PPP EAP-TLS
RFC 2865 RADIUS Authentication
RFC 2866 RADIUS Accounting
RFC 2867 Tunnel Accounting
RFC 2869 RADIUS Extensions
RFC 3579 RADIUS Support for EAP
RFC 3748 EAP-PEAP
RFC 5216 EAP-TLS
RFC 5281 EAP-TTLS
RFC 2284 EAP-GTC
RFC 4186 EAP-SIM
RFC 3748 Leap Passthrough
RFC 3748 Extensible Authentication Protocol Web Page Authentication
• WPR, Landing Page, Redirect
• Support for Internal WPR, Landing Page and Authentication
• Support for External WPR, Landing Page and Authentication |
| Regulatory Compliance |
CE Mark
Safety:
• UL 60950-1:2003
• EN 60950:2000
• EMI and susceptibility (Class A)
• U.S.:FCC Part 15.107 and 15.109
• Canada: ICES-003
• Europe: EN 55022, EN 55024
• EN 60601-1-2
• EN 301 893 V1.6.1 |
| Environmental Specifications |
Operating Temperature: 0-55C, 0-90% humidity, non-condensing |
| Physical Specifications (does not include mounting bracket) |
Dimensions (WxDxH): 2.75 x 16.875 x 16.875 in.
Weight: 5 lbs |
| Channel Support 2.4GHz |
1 2 3 4 5 6 7 8 9 10 11 12 13 14 |
| Channel Support 5GHz |
UNI I - Non-DFS Channels
36 40 44 48
UNI I DFS Channels
52 56 60 64
UNI II DFS Channels
100 104 108 112 116 120 124 128 132 136 140
UNI III Non-DFS Channels
149 153 157 161 165 |
| Management Interfaces |
Command line interface
Web interface (http / https)
Xirrus Management System (XMS) |
