Item
|
Specifications
|
|
Scalability and performance
|
Optimized to enable 802.11ac Wave 2 next-generation networks. Consolidate multiple controllers into one controller with support for up to 6000 access points and 64,000 clients with a single point of touch
- 40-Gbps throughput
- 6000 access points
- 64,000 clients
- 4096 VLANs
- 100 access points in up to 2000 Cisco FlexConnect groups
|
|
Wireless
|
IEEE 802.11a, 802.11b, 802.11g, 802.11d, WMM/802.11e, 802.11h, 802.11n, 802.11k, 802.11r, 802.11u, 802.11w, 802.11ac Wave1 and Wave2
|
|
Wired, switching, and routing
|
IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX specification, 1000BASE-T. 1000BASE-SX, 1000-BASE-LH, IEEE 802.1Q VLAN tagging, IEEE 802.1AX Link Aggregation
|
|
Data Request For Comments (RFC)
|
- RFC 768 UDP
- RFC 791 IP
- RFC 2460 IPv6
- RFC 792 ICMP
- RFC 793 TCP
- RFC 826 ARP
- RFC 1122 Requirements for Internet Hosts
- RFC 1519 CIDR
- RFC 1542 BOOTP
- RFC 2131 DHCP
- RFC 5415 CAPWAP Protocol Specification
- RFC 5416 CAPWAP Binding for 802.11
|
|
Security standards
|
- Wi-Fi Protected Access (WPA)
- IEEE 802.11i (WPA2, RSN)
- RFC 1321 MD5 Message-Digest Algorithm
- RFC 1851 ESP Triple DES Transform
- RFC 2104 HMAC: Keyed Hashing for Message Authentication
- RFC 2246 TLS Protocol Version 1.0
- RFC 2401 Security Architecture for the Internet Protocol
- RFC 2403 HMAC-MD5-96 within ESP and AH
- RFC 2404 HMAC-SHA-1-96 within ESP and AH
- RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV
- RFC 2407 Interpretation for ISAKMP
- RFC 2408 ISAKMP
- RFC 2409 IKE
- RFC 2451 ESP CBC-Mode Cipher Algorithms
- RFC 3280 Internet X.509 PKI Certificate and CRL Profile
- RFC 4347 Datagram Transport Layer Security
- RFC 5246 TLS Protocol Version 1.2
|
|
Encryption
|
- Wired Equivalent Privacy (WEP) and Temporal Key Integrity Protocol-Message Integrity Check (TKIP-MIC): RC4 40, 104 and 128 bits (both static and shared keys)
- Advanced Encryption Standard (AES): Cipher Block Chaining (CBC), Counter with CBC-MAC (CCM), Counter with Cipher Block Chaining Message Authentication Code Protocol (CCMP)
- Data Encryption Standard (DES): DES-CBC, 3DES
- Secure Sockets Layer (SSL) and Transport Layer Security (TLS): RC4 128-bit and RSA 1024- and 2048-bit
- DTLS: AES-CBC
- IPsec: DES-CBC, 3DES, AES-CBC
- 802.1AE MACsec encryption
|
|
Authentication, Authorization, and Accounting (AAA)
|
- IEEE 802.1X
- RFC 2548 Microsoft Vendor-Specific RADIUS Attributes
- RFC 2716 PPP EAP-TLS
- RFC 2865 RADIUS Authentication
- RFC 2866 RADIUS Accounting
- RFC 2867 RADIUS Tunnel Accounting
- RFC 2869 RADIUS Extensions
- RFC 3576 Dynamic Authorization Extensions to RADIUS
- RFC 5176 Dynamic Authorization Extensions to RADIUS
- RFC 3579 RADIUS Support for EAP
- RFC 3580 IEEE 802.1X RADIUS Guidelines
- RFC 3748 Extensible Authentication Protocol (EAP)
- Web-based authentication
- TACACS support for management users
|
|
Management
|
- Simple Network Management Protocol (SNMP) v1, v2c, v3
- RFC 854 Telnet
- RFC 1155 Management Information for TCP/IP-Based Internets
- RFC 1156 MIB
- RFC 1157 SNMP
- RFC 1213 SNMP MIB II
- RFC 1350 TFTP
- RFC 1643 Ethernet MIB
- RFC 2030 SNTP
- RFC 2616 HTTP
- RFC 2665 Ethernet-Like Interface types MIB
- RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual Extensions
- RFC 2819 RMON MIB
- RFC 2863 Interfaces Group MIB
- RFC 3164 Syslog
- RFC 3414 User-Based Security Model (USM) for SNMPv3
- RFC 3418 MIB for SNMP
- RFC 3636 Definitions of Managed Objects for IEEE 802.3 MAUs
- Cisco private MIBs
|
|
Management interfaces
|
- Web-based: HTTP/HTTPS
- Command-line interface: Telnet, Secure Shell (SSH) Protocol, serial port
- Cisco Prime Infrastructure
|
|
Interfaces and indicators
|
- 4 x 10 Gigabit Ethernet interfaces or 4 x 1 Gigabit Ethernet interfaces
- Small Form-Factor Pluggable Plus (SFP+) options (only Cisco SFP+s supported), including S-Class Optics
- Small Form-Factor Pluggable (SFP) options (only Cisco SFPs supported), including S-Class Optics
- 1 x service port: 1 Gigabit Ethernet port (RJ-45)
- 1 x redundancy port: 1 Gigabit Ethernet port (RJ-45)
- 1 x Cisco Integrated Management Controller port: 1 10/100/1000 Ethernet (RJ-45)
- 1 x console port: Serial port (RJ-45)
- LED indicators: Network Link, Diagnostics
|
|
Physical dimensions
|
- Dimensions (WxDxH): 18.96 x 30.18 x 3.43 in. (48.2 x 76.6 x 8.70 cm) including handles
- Weight: 44 lb (19.9 kg) with 2 power supplies
|
|
Environmental conditions
|
Air temperature:
- Appliance operating: 41° to 104°F (5° to 40°C), derate the maximum temperature by 1.0°C per every 1000 ft. (305m) of altitude above sea level
- Appliance nonoperating: -40° to 149°F (-40° to 65°C)
Humidity:
- Appliance operating: 10% to 90%; noncondensing at 82°F (28°C)
- Appliance nonoperating: 5% to 93% at 82°F (28°C)
Altitude:
- Appliance operating: 0 to 3,000m (0 to 10,000 ft.)
- Appliance nonoperating: 0 to 12,192 m (0 to 40,000 ft.)
Electrical input:
- AC input frequency range: 47 to 63 Hz
- Input voltage range:
◦ Minimum: 90 VAC
◦ Maximum: 264 VAC
◦ Maximum power 538W
- Heat dissipation: 1836 BTU/hr
- Sound power level measure:
◦ A-weighted per ISO 7779 LpAm (dBA), operation at 77°F (25°C): 59.4
|
|
Regulatory compliance
|
CE Markings per directives 2004/108/EC and 2006/95/EC
Safety:
- UL 60950-1 Second Edition
- CAN/CSA-C22.2 No. 60950-1 Second Edition
- EN 60950-1 Second Edition
- IEC 60950-1 Second Edition
- AS/NZS 60950-1
- GB4943 2001
EMC - Emissions:
- 47CFR Part 15 (CFR 47) Class A
- AS/NZS CISPR22 Class A
- EN55022 Class A
- ICES003 Class A VCCI Class A
- EN61000-3-2 EN61000-3-3 KN22 Class A
- CNS13438 Class A
EMC - Immunity:
- EN55024
- CISPR24
- EN300386
- KN24
|
