Thiết Bị Phát Wifi Aruba AP-303 Unified AP JZ320A

Aruba AP 303 là bộ phát wifi 5 chuẩn AC Wave 2 tốc độ 1.2Gbps, 2x2 MU MIMO giúp tăng tốc độ phát và OFDM đáp ứng nhiều người truy cập. Cung cấp khả năng kết nối Wifi  hiệu suất cao cho các địa điểm như trường học, chi nhánh bán lẻ, nhà kho, khách sạn và văn phòng, nơi có mức độ truy cập vừa phải và cần tối ưu chi phí đầu tư. CNTTShop bán Aruba AP 303 với mức giá hợp lý, dịch vụ bảo hành, chăm sóc khách hàng hẫu mãi, hỗ trợ kỹ thuật và tư vấn các giải pháp mạng không dây miễn phí.

✓ Mã sản phẩm: JZ320A
✓ Tình trạng: Còn Hàng
Models:

JZ320A

JZ320ACM
Check Giá List

So sánh với bộ phát Wifi khác:

Cam Kết Bán Hàng

✓ Đầy Đủ CO/CQ

✓ Hỗ Trợ Đại Lý Và Dự Án

✓ Giao Hàng Trên Toàn Quốc

✓ Sản Phẩm Chính Hãng™ 100%

✓ Cam Kết Giá Rẻ Nhất Thị Trường

✓ Bảo Hành, Đổi Trả Nhanh Chóng

✓ Hỗ Trợ Kỹ Thuật Chuyên Nghiệp, Nhiệt Tình

CNTTShop.vn - Trên 10 năm Uy tín cung cấp Thiết bị mạng & Dịch vụ Mạng trên toàn quốc.

NTT03, Thống Nhất Complex, Thanh Xuân, Hà Nội. Số 31B, Đường 1, Phường An Phú, Quận 2 (Thủ Đức), TP HCM.

Wifi Aruba AP 303 Indoor Access Point

Part Number
List Price
: $
Giá bán
Bảo hành
Made In
Stock
:

Aruba AP 303 là sản phẩm tầm trung, giá cả phải chăng cung cấp wifi chuẩn 802.11ac Wave 2 hiệu suất cao với công nghệ MU-MIMO cho môi trường doanh nghiệp, mật độ trung bình. Sản phẩm tích hợp BLE và hỗ trợ PoE 802.3af, AP-303 cho phép doanh nghiệp nâng cao hiệu quả làm việc và năng suất với chi phí thấp.

Wifi Aruba Ap 303 RW Unified

JZ320A Aruba AP 303 (RW) Dual 2x2:2 MU-MIMO Radio Internal Antennas Unified Campus AP. Thiết bị phát sóng wifi hỗ trợ 16 BSSIDs trên 1 radio, có tốc độ không dây rất ấn tượng đạt 867 Mbps ở băng tần 5GHz và 300 Mb / giây trên băng tần 2,4 GHz (tốc độ dữ liệu tổng hợp cao nhất đến 1.2Gbps).

Thông tin về Wifi Aruba AP 303

Wifi chuyên dụng Aruba AP 303 là sản phẩm wifi thế hệ mới của hãng công nghệ hàng đầu thế giới Aruba Networks HPE, Mỹ. Đang được ưa chuộng sử dụng với nhiều ưu điểm vượt trội, là thiết bị phát wifi được bán chạy nhất đầu năm 2022 chắc chắn đây là sản phẩm đem lại nhiều lợi ích cho người sử dụng như: tính tiện lợi, ổn định, an toàn ..vv và có mức giá hợp với túi tiền cho nhu cầu sử dụng.

Wifi aruba ap 303 wifi 5 indoor

- Điểm truy cập Wifi AP có thiết kế màu trắng nhỏ gọn đẹp mắt, chân đế đa năng phù hợp lắp đặt trong nhà trên trần, vách thạch cao hoặc tường mà không làm mất thẩm mỹ xung quanh.

- Được trang bị 2 ăng ten Dual Band +21dBm (2.4Ghz/5GHz) tích hợp công nghệ mới nhất MU-MIMO giúp tăng vùng phát sóng. Ngoài ra sản phẩm còn ứng dụng nhiều công nghệ mới hiện đại hỗ trợ 16 SSID, cho phép kết nối mượt mà tối đa lên đến 512 thiết bị đồng thời.

- Hỗ trợ cả ArubaOS (controller-base) và InstantOS (controller-less) giúp thiết bị AP 303 có thể được làm Controller để quản lý và cấu hình các AP khác.

Thiết bị phát wifi aruba ap 303

Tính năng nổi bật của wifi Aruba AP 303

- Phát sóng với tốc độ dữ liệu tổng hợp cao lên đến 1,2 Gbps

- Có khả năng cấp nguồn cho 1 AP khác trên cổng PoEOut thứ 2

- Tích hợp đài phát Zigbee và Bluetooth 5 giúp kết nối IoT nhanh chóng và an toàn

- Tối ưu các kết nối với MU-MIMO-aware ClientMatch

- Áp dụng công nghệ Aruba Dynamic Segmentation giúp doanh nghiệp dễ dàng triển khai và quản lý hoạt động mạng, IoT, thiết bị khách cũng như tối ưu hóa trải nghiệm kết nối một cách đơn giản và bảo mật.

Thông số kỹ thuật

Datasheet Aruba AP 303
WI-FI Radio Specifications
• AP type: Indoor, dual radio, 5GHz 802.11ac 2x2 MIMO and 2.4GHz 802.11n 2x2 MIMO
• 5GHz:
-Two spatial stream Single User (SU) MIMO for up to 867 Mbps wireless data rate to individual 2SS VHT80
client devices
-Two spatial stream Multi User (MU) MIMO for up to 867 Mbps wireless data rate to two 1SS MU-MIMO
capable client devices simultaneously
• 2.4GHz: Two spatial stream Single User (SU) MIMO for up to 300 Mbps wireless data rate to individual 2SS HT40 client devices
• Support for up to 255 associated client devices per radio, and up to 16 BSSIDs per radio
• Supported frequency bands (country-specific restrictions apply):
- 2.400 to 2.4835GHz
- 5.150 to 5.250GHz
- 5.250 to 5.350GHz
- 5.470 to 5.725GHz
- 5.725 to 5.850GHz
• Available channels: Dependent on configured regulatory domain
• Dynamic frequency selection (DFS) optimizes the use of available RF spectrum
• Supported radio technologies:
- 802.11b: Direct-sequence spread-spectrum (DSSS)
- 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
• Supported modulation types:
- 802.11b: BPSK, QPSK, CCK
- 802.11a/g/n/ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
• Transmit power: Configurable in increments of 0.5 dBm
• Maximum (conducted) transmit power (limited by local regulatory requirements):
- 2.4GHz band: +21dBm (18dBm per chain)
- 5GHz band: +21dBm (18dBm per chain)
- NOTE: conducted transmit power levels exclude antenna gain. For total (EIRP) transmit power, add antenna gain
• Advanced Cellular Coexistence (ACC) minimizes interference from cellular networks
• Maximum ratio combining (MRC) for improved receiver performance
• Cyclic delay/shift diversity (CDD/CSD) for improved downlink RF performance
• Short guard interval for 20MHz, 40MHz and 80MHz channels
• Space-time block coding (STBC) for increased range and improved reception
• Low-density parity check (LDPC) for high-efficiency error correction and increased throughput
• Transmit beam-forming (TxBF) for increased signal reliability and range
• Supported data rates (Mbps):
- 802.11b: 1, 2, 5.5, 11
- 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
- 802.11n: 6.5 to 300 (MCS0 to MCS15)
- 802.11ac: 6.5 to 867 (MCS0 to MCS9, NSS = 1 to 2 for VHT20/40/80
• 802.11n high-throughput (HT) support: HT 20/40
• 802.11ac very high throughput (VHT) support: VHT 20/40/80
• 802.11n/ac packet aggregation: A-MPDU, A-MSDU
WI-FI Antennas • Two vertically polarized dual-band downtilt omnidirectional antennas for 2x2 MIMO with peak antenna
gain of:
--3.3dBi in 2.4GHz and 5.8dBi in 5GHz for AP-303
--3.4dBi in 2.4GHz and 7.8dBi in 5GHz for AP-303P
• The antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.
• Combining the patterns of both antennas per radio, the peak gain of the average (effective) pattern is:
--2.1dBi in 2.4GHz and 5.7dBi in 5GHz for AP-303
--2.1dBi in 2.4GHz and 5.9dBi in 5GHz for AP-303P
Other Interfaces • E0: One 10/100/1000BASE-T Ethernet network interface (RJ-45)
--Auto-sensing link speed and MDI/MDX
--802.3az Energy Efficient Ethernet (EEE)
--PoE-PD: 48Vdc (nominal) 802.3af/at/bt PoE
• DC power interface
• E1 (AP-303P models only): One 10/100/1000BASE-T Ethernet network interface (RJ-45)
--Auto-sensing link speed and MDI/MDX
--802.3az Energy Efficient Ethernet (EEE)
--PoE-PSE (output): 48Vdc (nominal) 802.3af/at PoE
• Bluetooth Low Energy (BLE) radio
• Zigbee 802.15.4 radio (AP-303P models only)
• Visual indicators (tri-color LEDs): for System and Radio status
• Reset button: factory reset (during device power-up), LED mode control (normal/off)
• Serial console interface (proprietary, μUSB physical jack)
• Kensington security slot
Power Sources and Consumption

• The AP supports direct DC power and Power over Ethernet (PoE)
• When both power sources are available, DC power takes priority over PoE
• Power sources are sold separately
AP-303 models:
• Direct DC source: 12Vdc nominal, +/- 5%
• DC power interface accepts 2.1/5.5-mm center-positive circular plug with 9.5-mm length
• Power over Ethernet (PoE): 48Vdc (nominal) 802.3af compliant source
• Maximum (worst-case) power consumption: 10.1W (PoE) or 8.8W (DC)
• Maximum (worst-case) power consumption in idle mode: 4.2W (PoE) or 4.0W (DC)
AP-303P models:
• Direct DC source: 48Vdc nominal, +/- 5%
• DC power interface accepts 1.35/3.5-mm center-positive circular plug with 9.5-mm length
• Power over Ethernet (PoE-PD) on E0: 48Vdc (nominal) 802.3af/at/bt compliant source
• PoE-PSE function on E1 disabled when powered by 802.3af PoE, limited to class 3 when powered by 802.3at PoE, unrestricted when powered by 802.3bt PoE or DC
• Maximum (worst-case) power consumption: 11.3 (PoE) or 11.5 (DC)
• Maximum (worst-case) power consumption in idle mode: 6.8 (PoE) or 7.0 (DC)
• Power consumption numbers exclude power to support PoE-PSE function on E1

Mounting • The AP ships with a (black) mount clips to attach to a 9/16- inch or 15/16-inch flat T-bar drop-tile ceiling
• Several optional mount kits are available to attach the AP to a variety of surfaces; see the Ordering Information section below for details
Mechanical
• Dimensions and weight (unit, excluding mount accessories):
--150mm (W) x 150mm (D) x 35mm (H) or 5.9” (W) x 5.9” (D) x 1.4” (H)
--AP-303 models: 260g or 9.2oz
--AP-303P models: 280g or 9.9oz
• Dimensions and weight (shipping):
--190mm (W) x 180mm (D) x 60mm (H) or 7.4” (W) x 7.0” (D) x 2.4” (H)
--AP-303 models: 410g or 14.5oz
--AP-303P models: 430g or 15.2oz
Environmental
• Operating:
--Temperature: 0° C to +40° C (+32° F to +104° F)
--Humidity: 5% to 93% non-condensing
• Storage and transportation:
--Temperature: -40° C to +70° C (-40° F to +158° F)
Reliability (at +25C operating temperature) • AP-303 models MTBF: 795khrs (91yrs)
• AP-303P models MTBF: 518khrs (59yrs)
Regulatory • FCC/Industry of Canada
• CE Marked
• R&TTE Directive 1995/5/EC
• Low Voltage Directive 72/23/EEC
• EN 300 328
• EN 301 489
• EN 301 893
• UL/IEC/EN 60950
• EN 60601-1-1 and EN 60601-1-2
Các tùy chọn Option, License cho JZ320A
Mount Kits – Spares
AP-220-MNT-C1 2x Ceiling Grid Rail Adapter for Basic Flat Rails Mount Kit
#JW044A

List Price: Updating...

Aruba CM AP-220-MNT-C1 2x Ceiling Grid Rail Adapter for Basic Flat Rails Mount Kit
#JW044ACM

List Price: Updating...

Mount Kits – Accessories
AP-220-MNT-C2 Kit with two suspended ceiling grid rail adapters for Interlude and Silhouette style rails
#JW045A

List Price: Updating...

AP-MNT-CM1 Industrial grade indoor Access Point metal suspended ceiling rail mount kit
#JX961A

List Price: Updating...

AP-220-MNT-W1 Flat surface wall/ceiling basic flat surface AP mount kit (black)
#JW046A

List Price: Updating...

AP-220-MNT-W1W Flat surface wall/ceiling basic flat surface AP mount kit (white)
#JW047A

List Price: Updating...

AP-200-MNT-W3 Low profile box style secure small flat surface AP mount kit (white)
#JY705A

List Price: Updating...

AP-MNT-W4 White Low Profile Basic AP Flat Surface Mount Kit
#Q9U25A

List Price: Updating...

Aruba CM AP-220-MNT-C2 2x Ceiling Grid Rail Adapter for Interlude and Silhouette Mt Kit
#JW045ACM

List Price: Updating...

Aruba CM AP-MNT-CM1 Metal Suspended Ceiling Rail Mount Kit
#JX961ACM

List Price: Updating...

Aruba CM AP-220-MNT-W1 Flat Surface Wall/Ceiling Black AP Basic Flat Surface Mount Kit
#JW046ACM

List Price: Updating...

Aruba CM AP-220-MNT-W1W Flat Surface Wall/Ceiling White AP Basic Flat Surface Mount Kit
#JW047ACM

List Price: Updating...

Aruba CM AP-200-MNT-W3 White Low Profile Box Style Secure Small AP Flat Surface Mount Kit
#JY705ACM

List Price: Updating...

Aruba CM AP-MNT-W4 White Low Profile Basic AP Flat Surface Mount Kit
#Q9U25ACM

List Price: Updating...

Power Accessories cho AP-303
PD-3501G-AC 15.4W 802.3af PoE 10/100/1000Base-T Ethernet Midspan Injector
#JW627A

List Price: Updating...

AP-AC2-12B 12V/48W AC/DC desktop style power adapter with 2.1/5.5mm connector
#R3K00A

List Price: Updating...

Aruba CM PD-3501G-AC 15.4W 802.3af PoE 10/100/1000Base-T Ethernet Midspan Injector
#JW627ACM

List Price: Updating...

AP-AC2-12B 12V/48W AC/DC desktop style power adapter with 2.1/5.5mm connector
#R3K00ACM

List Price: Updating...

Power Accessories cho AP-303P
AP-POE-BTSR 1-Port Smart Rate 802.3bt 60W midspan injector
#JW627A

List Price: Updating...

PD-9001GR-AC 30W 802.3at PoE+ 10/100/1000 Ethernet Indoor Rated Midspan Injector
#JW629A

List Price: Updating...

AP-POE-BTSR 1-Port Smart Rate 802.3bt 60W midspan injector
#R1C73A

List Price: Updating...

AP-AC2-48C 48V/50W AC/DC desktop style power adapter with 1.35/3.5mm connector
#R3K01A

List Price: Updating...

Bạn đang cần tư vấn về sản phẩm: JZ320A ?

Có 29 bình luận:
K
Khải
Aruba AP-303 có mấy anten trong hả shop? Có gắn thêm được anten ngoài không?
2 năm
T
Vũ ThảoQuản trị viên

Aruba AP-303 có 2 anten trong và không gắn thêm được anten ngoài anh nhé

T
Thuyên
Wifi aruba AP-303 có sẵn hàng không bạn, giá thế nào, mình cần khoảng 30c bên bạn có đủ số lượng này không
2 năm
M
Thanh MinhQuản trị viên

Wifi aruba AP-303 hiện đang sẵn hàng số lượng lớn, anh check mail nhận báo giá tốt nhất cho đơn hàng 30 chiếc anh nhé

B
Bình
Wifi Aruba AP-303 Dual 2x2:2 MU-MIMO Radio Internal Antennas Unified Campus AP có băng thông bao nhiêu nhỉ?
3 năm
C
CNTTShopAdmin

Chào anh/chị, bộ phát wifi Aruba AP-303 có băng thông ở 5 GHz là 867 Mbps và ở 2.4 GHz là 200 Mbps.

V
Vinh
AP-303 có RAM bao nhiêu và cổng console là loại gì vậy ạ?
3 năm
C
CNTTShopAdmin

Chào anh/chị, sản phẩm Aruba AP-303 không được nhà sản xuất con bố thông số RAM, cổng console của sản phẩm không có chuẩn riêng mà phải sử dụng dây cáp độc quyền của Aruba với mã AP-CBL-SERU (JY728A)

L
Lương
bộ phát wifi aruba AP-303 chịu tải thế nào ạ?
3 năm
C
CNTTShopAdmin

Bộ phát wifi Aruba AP-303 chịu tải tối đa được 256 người dùng trên 1 radio chị nhé.
