Switch fabric connection
|
160 Gbps in 6807-XL chassis
|
|
Oversubscription
|
8 ports: Oversubscription mode 2:1
|
|
Throughput (per module)
|
IPv4: up to 120 Mpps
IPv6: up to 60 Mpps
|
|
Can be used to form VSS virtual switch link
|
Yes (on all ports)
|
|
Jumbo frame support
|
Up to 9216 bytes
|
|
Supervisor engines supported
|
Cisco Catalyst 6500 Series Supervisor Engine 2T and 2TXL
Cisco Catalyst 6800 Series Supervisor Engine 6T and 6TXL
|
|
Chassis supported
|
- Cisco Catalyst 6807-XL chassis
- Not supported in 6500 non-E Series chassis, 6500-E Series chassis, and 7600 Series chassis
|
|
Slot requirements
|
- Can occupy slots 1–2 and 5–7 in a Cisco Catalyst 6807-XL chassis
|
|
Onboard memory
|
2 GB default
|
|
Minimum Cisco IOS®Software release
|
15.5(1)SY
|
|
Standard protocols
|
IEEE 802.1d, IEEE 802.1p, IEEE 802.1q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3x, IEEE 802.3ad, IEEE 802.3ba
|
|
Physical specifications
|
- Occupies one slot in 6807-XL chassis
- Dimensions (H x W x D): 1.73 x 15.4 x 16.4 inches (4.39 x 39.11 x 41.65 cm)
- Weight:
◦ 12.52 lb (5.68kg) for C6800-8P40G-XL
◦ 12.79 lb (5.80kg) for C6800-8P40G-XL-XL
|
|
Environmental conditions
|
Operating temperature:
- Agency-certified for operation: 32° to 104°F (0° to 40°C)
- Design and tested for operation: 32° to 130°F (0° to 55°C)
- Storage temperature: -40° to 167°F (-40° to 75°C)
- Relative humidity: 10 to 90 percent, noncondensing
Operating altitude:
- Agency-certified for operation: -500 to 6500 ft (-150 to 2000 m)
- Designed and tested for operation: -500 to 10K ft (-150 to 3000 m)
|
|
Regulatory compliance
|
6800 Series 40 Gigabit Ethernet module, when installed in a system, complies with the following EMC and safety standards:
EMC Standards:
- FCC Part 15 (CFR 47) Class A
- ICES-003 Class A
- VCCI Class A
- EN55022 Class A
- EN55024
- CISPR24
- CISPR 22 Class A
- AS/NZS CISPR 22 Class A
- ETS 300 386
- KN 22 Class A
- EN 50082-1
- EN61000-3-2
- EN61000-3-3
- EN61000-6-1
- CNS13438 Class A
- KN6100 -4 Series
Safety Standards:
- UL 60950-1
- CAN/CSA C22.2 No. 60950
- EN 60950-1
- IEC 60950-1
- AS/NZS 60950-1
- IEC 60825 Class 1
- EN 60825 Class 1
- 21CFR 1040
|
|
ETSI
|
- ETS 300 019-2-1, Class 1.1 Storage
- ETS 300 019-2-2, Class 2.1 and 2.2 Transportation
- ETS 300 019-2-3, Class 3.1E Stationary Use
|
|
Network management
|
- ETHERLIKE-MIB (RFC 1643)
- IF-MIB (RFC 1573)
- Bridge MIB (RFC 1493)
- CISCO-STACK-MIB
- CISCO-VTP-MIB
- CISCO-CDP-MIB
- RMON MIB (RFC 1757)
- CISCO-PAGP-MIB
- CISCO-STP-EXTENSIONS-MIB
- CISCO-VLAN-BRIDGE-MIB
- CISCO-VLAN-MEMBERSHIP-MIB
- ENTITY-MIB (RFC 2037)
- HC-RMON
- RFC1213-MIB (MIB-II)
- SMON-MIB
|
|
Power requirements
|
587.60 watts
|
|
Indicators
|
- Status: green (operational), red (faulty), and orange (module booting)
- Link: green (port enabled and connected), orange (port disabled), and off (port enabled and not connected)
- Blue beacon: Used to identify a specific module in a fully populated system within a multisystem environment
|
