Software compatibility
|
- Software Version TC 7.1 or later
- Cisco Collaboration Endpoint Software 8.0 or later |
|
Language support
|
- English, Arabic, Catalan, Czech, Danish, Dutch, Finnish, French, German, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese-Brazilian, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish; depends on software version
|
|
Bandwidth
|
- H.323/SIP up to 6 Mbps point-to-point
- Up to 10 Mbps total MultiSite bandwidth |
|
Minimum bandwidth for resolution/frame rate (H.264)
|
- 720p30 from 768 kbps
- 720p60 from 1152 kbps
- 1080p30 from 1472 kbps
- 1080p60 from 2560 kbps |
|
Firewall traversal
|
- Cisco TelePresence Expressway technology
- H.460.18 and H.460.19 firewall traversal |
|
Video standards
|
- H.261, H.263, H.263+, H.264 and H.265
(SIP only for H.265) |
|
Video features
|
- Advanced screen layouts
- Custom video layouts
- Local auto layout |
|
Video inputs (five inputs)
|
Three HDMI Inputs; supported formats:
- 1920 x 1080@60 and 59.94 Hz (1080p60)
- 1920 x 1080@50 Hz (1080p50)
- 1920 x 1080@30 and 29.97 Hz (1080p30)
- 1920 x 1080@25 Hz (1080p25)
- 1920 x 1080@24, and 23.97 Hz (1080p24)
- 1280 x 720@60, and 59.94 Hz (720p60)
- 1280 x 720@50 Hz (720p50)
- 720 x 480@60, and 59.94 Hz (480p60)
- 640 x 480@60 Hz (480p60)
- 1280 x 1024@60, and 75 Hz (SXGA)
- 1024 x 768@60, 70, 75, and 85 Hz (XGA)
- 800 x 600@56, 60, 72, 75, and 85 Hz (SVGA)
- 1680 x 1050@60 Hz (WSXGA+)
- 1440 X 900@60 Hz (WXGA+)
- 1280 x 768@60 Hz (WXGA)
- 1920 x 1200@60 Hz (WUXGA) 3
- 1920 x 1200@50 Hz (WUXGA) 3
One DVI-I Input; supported formats:
Analog (VGA or YPbPr):
- 1920 x 1080@60 Hz (1080p)
- 1280 x 720@60 Hz (720p)
- 1280 x 1024@60 and 75 Hz (SXGA)
- 1280 x 960@60 Hz
- 1024 x 768@60, 70, 75, and 85 Hz (XGA)
- 1680 x 1050@60 Hz (WSXGA+)
- 1440 x 900@60 Hz (WXGA+)
- 1280 x 800@60 Hz (WXGA)
- 1280 x 768@60 Hz (WXGA)
Digital (DVI-D):
- 1920 x 1080@60, 59.94 Hz (1080p60)
- 1920 x 1080@50 Hz (1080p50)
- 1920 x 1080@30, 29.97 Hz (1080p30)
- 1920 x 1080@25 Hz (1080p25)
- 1920 x 1080@24, 23.97 Hz (1080p24)
- 1280 x 720@60, 59.94 Hz (720p60)
- 1280 x 720@50 Hz (720p50)
- 720 x 480@60, 59.94 Hz (480p60)
- 640 x 480@60 Hz (480p60)
- 1280 x 1024@60, 75 Hz (SXGA)
- 1024 x 768@60, 70, 75, 85 Hz (XGA)
- 800 x 600@56, 60, 72, 75, 85 Hz (SVGA)
- 1680 x 1050@60 Hz (WSXGA+)
- 1440 X 900@60 Hz (WXGA+)
- 1280 x 768@60 Hz (WXGA)
- 1920 x 1200@60 Hz (WUXGA)3
- 1920 x 1200@50 Hz (WUXGA) 3
One Composite/S-Video Input (BNC Connectors)
- PAL/NTSC
Extended Display Identification Data (EDID)
|
|
Video outputs (three outputs
|
Two HDMI Outputs and one DVI-I Output; supported formats:
- 1920 x 1080@60 Hz (1080p60)
- 1920 x 1080@50 Hz (1080p50)
- 1280 x 720@60 Hz (720p60)
- 1280 x 720@50 Hz (720p50)
- 1920 x 1200@60 Hz (WUXGA) 3
- 1920 x 1200@50 Hz (WUXGA) 3
VESA Monitor Power Management
Extended Display Identification Data (EDID)
|
|
Live video resolutions (encode and decode)
|
- 176 x 144@30 frames per second (fps) (QCIF)
- 352 x 288@30 fps (CIF)
- 512 x 288@30 fps (w288p)
- 576 x 448@30 fps (448p)
- 768 x 448@30 fps (w448p)
- 704 x 576@30 fps (4CIF)
- 1024 x 576@30 fps (w576p)
- 1280 x 720@30 fps (720p30)
- 1920 x 1080@30 fps (1080p30)
- 1920 x 1200@15fps (WUXGA) 3
- 640 x 480@30 fps (VGA)
- 800 x 600@30 fps (SVGA)
- 1024 x 768@30 fps (XGA)
- 1280 x 1024@30 fps (SXGA)
- 1280 x 768@30 fps (WXGA)
- 1440 x 900@30 fps (WXGA+) - 1680 x 1050@30 fps (WSXGA+)
- 1920 x 1200@15fps (WUXGA)
- 512 x 288@60 fps (w288p60)
- 768 x 448@60 fps (w448p60)
- 1024 x 576@60 fps (w576p60)
- 1280 x 720@60 fps (720p60)
- 1920 x 1080@60 fps (1080p60) |
|
Audio standards
|
- G.711, G.722, G.722.1, G.728, G.729AB, 64 kbps and 128 kbps MPEG4 AAC-LD mono and stereo, OPUS |
|
Audio features
|
- CD-quality 20 kHz mono and stereo
- Eight separate acoustic echo cancellers
- Eight-port audio mixer
- Eight assignable equalizers
- Automatic Gain Control (AGC)
- Automatic noise reduction
- Active lip synchronization |
|
Audio inputs (fifteen inputs)
|
- Eight microphones, 48V phantom powered, Euroblock connector, each with separate echo cancellers and noise reduction; all microphones can be set for balanced line level
- Four balanced line level inputs, Euroblock connector
- Three HDMI, digital: stereo PC/DVD input |
|
Audio outputs (eight outputs)
|
- Six balanced line level outputs, Euroblock connector
- Two HDMI outputs |
|
Dual stream
|
- H.239 (H.323) dual stream
- BFCP (SIP) dual stream
- Support for resolutions up to 1080p30, and independent of main stream resolution |
|
Multipoint support
|
- Five way embedded SIP/H.323 multipoint (reference MultiSite)
- Cisco ad-hoc conferencing (requires CUCM, Cisco TelePresence Server and Conductor)
- Cisco Conferencing Active Control
- Switched Conferencing (SVC) 3 |
|
MultiSite features
(embedded multipoint)
|
- Five way 720p30, three way and four way 1080p30 MultiSite
- Full individual audio and video transcoding
- Individual layouts in MultiSite continuous presence
- H.323/SIP/VoIP in the same conference
- Support for Presentation (H.239/BFCP) from any participant at resolutions up to 1080p15
- Best Impression (Automatic continuous presence layouts)
- H.264, encryption, and dual stream from any site
- Additional telephone call (no license required)
- IP downspeeding
- Dial in and dial out
- Conference rates up to 10 Mbps |
|
Protocols
|
- H.323
- SIP
- Dual call stack support (SIP and H.323)
- ISDN (requires Cisco ISDN Link) |
|
Embedded encryption
|
- H.323/SIP point-to-point
- Standards-based: H.235 v3 and Advanced Encryption Standard (AES)
- Automatic key generation and exchange
- Supported in dual stream |
|
IP network features
|
- DNS lookup for service configuration
- Differentiated Services (QoS)
- IP adaptive bandwidth management (including flow control)
- Auto gatekeeper discovery
- Dynamic playout and lip-sync buffering
- H.245 DTMF tones in H.323
- Date and Time support via NTP
- Packet Loss based downspeeding
- URI Dialing
- TCP/IP
- DHCP
- 802.1x Network authentication
- 802.1Q Virtual LAN
- 802.1p (QoS and Class of Service [CoS])
- ClearPath
- RFC 4733 DTMF tones in SIP |
|
Call control
|
- Cisco Unified Communications Manager (CUCM)
+ Native registration with CUCM
+ Requires CUCM Version 8.6(2) or later with device pack for SX80
+ Basic CUCM provisioning
+ Firmware upgrade from CUCM
+ Cisco Discovery Protocol and DHCP option 150 support
+ Basic telephony features such as hold, resume, transfer, and corporate directory lookup
- Cisco Video Communication Server (VCS)
+ Native registration with VCS
- Cisco Webex
- Third-party H.323 Gatekeepers and standards-based SIP proxies |
|
IPv6 network support
|
- Single call stack support for both H323 and SIP
- Dual-stack IPv4 and IPv6 for DHCP, Secure Shell (SSH), HTTP, Secure HTTP (HTTPS), DNS, and Differentiated Services (DiffServ)
- Support for both static and autoconfiguration (stateless address auto configuration) |
|
Security features
|
- Management through HTTPS and SSH
- IP administration password
- Menu administration password
- Disable IP services
- Network settings protection |
|
Certificate management
|
- Certificate Authority Proxy Function (CAPF) support for additional security
- Manufacturer-Installed Certificates (MIC)
- Locally Significant Certificates (LSC)
- X.509 Digital Certificates (DER encoded binary); both DER and Base-64 formats are acceptable for the client and server certificates; certificates with a key size of 1024, 2048, and 4096 are supported |
|
Network interfaces
|
- One LAN/Ethernet (RJ-45) 10/100/1000 Mbit
- Two LAN/Ethernet (RJ-45) interfaces to be used for Cisco peripherals |
|
Other interfaces
|
- Two USB hosts for future usage
- GPIO |
|
System management
|
- Support for Cisco TelePresence Management Suite (TMS)
- Management via embedded Telnet, SSH, XML, and SOAP
- Full Application Programming Interface (APIs)
- Remote software upload via web server, SCP, HTTP, and HTTPS
- One RS-232 for local control and diagnostics
- Support for Cisco Touch 10 |
|
Directory services
|
- Support for local directories (My Contacts)
- Corporate directory (through CUCM and Cisco TMS)
- Server directory supporting LDAP and H.350 (requires Cisco TelePresence Management Suite)
- Call History with received, placed and missed calls with date and time |
|
Power
|
- Auto-sensing power supply
- 100-120/200-240 VAC, 50/60 Hz
- 170 watt maximum for codec and main camera |
|
Operating temperature and humidity
|
- 0 to 40° (32 to 104° F) ambient temperature
- 10 to 90% Relative Humidity (RH) |
|
Storage and transport temperature
|
- -20° C to 60° C (-4° F to 140° F) at RH 10-90% (non-condensing) |
|
Dimensions
|
- Length: 17.4 in. (44.2 cm)
- Height: 1.7 in (4.4 cm)
- Depth: 12.2 in. (30.98 cm)
- Weight: 8.05 lbs. (3.65 kg) |
|
Regulatory Compliance
|
- Directive 2006/95/EC (Low Voltage Directive) - Standard EN 60950-1
- Directive 2004/108/EC (EMC Directive) - Standard EN 55022, Class A - Standard EN 55024 - Standard EN 61000-3-2/-3-3
- Approved according to UL 60950-1 and CAN/CSA-C22.2 No. 60950-1
- Complies with FCC CFR 47 15B, Class A |
