Feature
|
Description
|
|
Product compatibility
|
Cisco MDS 9000 Family
|
|
Software compatibility
|
Cisco MDS 9000 NX-OS Release 9.3(1) or later
|
|
Protocols
|
- Fibre Channel standards
- FC-PI-6 (INCITS 512-2015)
- FC-PI-7 (INCITS 543-2019)
- FC-FS-4 (INCITS 488-2016)
- FC-FS-5 (INCITS 545-2019)
(Full list available upon request)
|
|
Fibre Channel ports
|
- Fixed-switch form factor with 24 SFP+ ports base
|
|
Security
|
- VSAN fabric isolation
- Intelligent packet inspection
- Hardware zoning by ACLs
- FC-SP authentication (switch-to-switch and host-to-switch)
- Role-Based Access Control (RBAC)
- Secure protocols: SSHv2, SNMPv3 (AES)
- Cisco TrustSec® payload encryption
- Secure Boot and anti-counterfeit technology
|
|
Performance
|
- Port speeds: 8-, 16-, 32-, and 64-Gbps autosensing
- Aggregate bandwidth: 1.5-Tbps full duplex
- Buffer credits: Up to 24,000 for a group of 24 ports (max 16,000 per port)
- Port groups: 1 group of 24 ports
- Port channels: Up to 24 load-balanced physical links
|
|
Diagnostics
|
- POST diagnostics
- Online Health Management System (OHMS)
- Fibre Channel tools (traceroute, ping, debug)
- Cisco Fabric Analyzer
- Syslog
- Port-level statistics
|
|
Serviceability
|
- Configuration file management
- Call Home
- Port beaconing
- System LEDs
- SNMP traps
|
|
Reliability and availability
|
- Cisco In-Service Software Upgrade (ISSU)
- Hot-swappable components (power supplies, fan trays, optics)
- Stateful process restart
- Fabric-based multipathing
- Per-VSAN fabric services
|
|
Network management
|
- Management through CLI, SNMPv3, and NX-API
- Access via out-of-band Ethernet and RS-232 serial ports
- USB power-on auto-provision port
- SMI-S compatibility
|
|
Programming interfaces
|
- Scriptable CLI
- Cisco DCNM/NDFC APIs
- NX-API
- Embedded Python interpreter
|
|
Physical dimensions (H x W x D)
|
1RU (1.72 x 17.299 x 18 in.) excluding PSU and fan-tray handles; Weight: 18.73 lb. (8.5 kg)
|
|
Power
|
- 80 Plus Platinum certified PSUs
- Options: 500W AC (exhaust or intake airflow); 1200W AC/HVAC/HVDC (bidirectional airflow)
- Input: 100–305V (AC/DC); Frequency: 50–60 Hz
- Max power consumption: 146W (24 ports with optics)
- Airflow: Back-to-front or front-to-back
|
|
Temperature range
|
- Operating: 32–104°F (0–40°C)
- Storage: –40–158°F (–40–70°C)
- Relative humidity: 10–90% (operating), 10–95% (storage)
- Altitude: –197 to 6500 ft (–60 to 2000m)
|
|
Approvals and compliance
|
- Safety: CE, UL 60950, IEC 60950
- EMC: FCC Part 15 Class A, EN 55022 Class A, CISPR 22 Class A
- RoHS compliance
|
|
Fabric services
|
- Name server
- Registered State Change Notification (RSCN)
- Fabric Configuration Server (FCS)
- In-order delivery
|
|
Advanced functions
|
- VSAN
- IVR
- NPV
- Port Channel with multipath load balancing
- Flow- and zone-based QoS
|
|
Supported Cisco optics and distances
|
For detailed information, refer to Cisco MDS 9000 Family pluggable transceivers documentation.
|
