Feature
|
Description
|
|
Product compatibility
|
Cisco MDS 9000 Family
|
|
Software compatibility
|
Cisco MDS 9000 NX-OS Release 9.3(1) or later
|
|
Protocols
|
Supports a range of Fibre Channel standards including FC-PI-6, FC-PI-7, FC-FS-5, NVMe/FC, FC-PH, FC-SW, FC-GS, FCP, Fibre Channel classes of service (Class 2, 3, F) and standard port types.
|
|
Fibre Channel ports
|
Fixed-switch form factor with 48 SFP+ ports base
|
|
Security
|
VSAN isolation, port-level inspection, hardware zoning with ACLs, FC-SP authentication, AAA with LDAP/RADIUS/TACACS+, SFTP, SSHv2, SNMPv3, control-plane security, and Cisco TrustSec.
|
|
Performance
|
Port speed: 8-, 16-, 32-64-Gbps autosensing; 3-Tbps bandwidth; up to 24,000 buffer credits; 24-port channel grouping.
|
|
Diagnostics
|
POST, OHMS diagnostics, SPAN, traceroute, ping, debug, Fabric Analyzer, Syslog, port statistics, and link diagnostics.
|
|
Serviceability
|
Configuration management, Call Home, beaconing, LEDs, SNMP alerts.
|
|
Reliability
|
ISSU, hot-swappable power supplies, SFP+ optics, multipathing, port tracking, FEC with HBA, buffer-to-buffer notifications.
|
|
Network management
|
CLI, SNMPv3, SMI-S, NX-API, device alias service, RBAC with LDAP/RADIUS/TACACS+, SFTP, SSHv2 with AES.
|
|
Programming interfaces
|
Scriptable CLI, DCNM/NDFC API, NX-API, Python interpreter, Embedded Event Manager, NX-OS Software scheduler.
|
|
Physical dimensions
|
1RU (1.72 x 17.299 x 18 in.), 21.8 lb (9.9 kg)
|
|
Power
|
80 Plus Platinum certified; 500W and 1200W options, compatible with specific cords and configurations.
|
|
Temperature range
|
Operating: 32–104°F (0–40°C); Nonoperating: –40 to 158°F (–40 to 70°C); Humidity: 10–95%; Altitude: –197 to 6500 ft.
|
|
Approvals and compliance
|
Safety standards: CE, UL, CSA, EN, IEC; EMC: FCC, ICES, EN, CISPR, VCCI, AS/NZS
|
|
Fabric services
|
Includes name server, RSCN, login services, Fabric Configuration Server, broadcast, in-order delivery.
|
|
Advanced functions
|
VSAN, IVR, NPV, Port Channel load balancing, QoS by flow and zone.
|
|
Supported optics
|
Refer to Cisco MDS 9000 Family pluggable transceivers documentation.
|
