N3K-C3432D-S Cisco Nexus 3432D-S Switch with 32 Ports of QSFP-DD

Switch Cisco N3K-C3432D-S Nexus 3432D-S with 32 Ports of QSFP-DD
Mã sản phẩm: N3K-C3432D-S
Tình trạng: Còn hàng
Check Giá List

Switch Cisco N3K-C3432D-S Nexus 3432D-S with 32 Ports of QSFP-DD 400GbE

Cisco Part Number        : N3K-C3432D-S
List Price                       : $

Bảo hành                       : 12 tháng
Made In                         : Asia
Stock                             : Liên hệ

Thiết bị chuyển mạch Cisco Nexus N3K-C3432D-S là dòng switch hỗ trợ các cổng 400G đầu tiên trong danh mục Nexus 3000 với Bộ giải mã nối tiếp PAM4 (SerDes) 50 Gbps, được thiết kế cho các trung tâm dữ liệu với performance-per-watt hàng đầu trong ngành với độ trễ thấp, cung cấp các công cụ phân tích hàng đầu.

View Datasheet N3K-C3432D-S

Switch Cisco Nexus N3K-C3432D-S được thiết kế 1RU, cung cấp 32 Ports Quad Small Form-Factor Pluggable – Double Density (QSFP-DD) 400G với băng thông chuyển mạch lên tới 25.6-Tbps, hỗ trợ tương thích ngược với các chuẩn QSFP+, QSFP28, và QSFP56. Mỗi cổng QSFP-DD có thể hoạt động ở các tốc độ 400, 100, 50, 40, và 25 Gbps.

Switch Cisco N3K-C3432D-S Nexus 3432D-S with 32 Ports of QSFP-DD 400GbE

Thông số kỹ thuật Switch Cisco Nexus N3K-C3432D-S

Product specifications
Physical
-  32 fixed 400-Gigabit-Ethernet QSFP-DD ports
-  Beacon LED
-  Status LED
-  Dual-redundant power supplies
-  Redundant (5+1) fans
-  Two 100/1000Mbps SFP ports in front (ports 33 and 34)
-  One RS-232 serial console port
-  One RJ45 and one SFP management port
-  One USB port
Performance 25.6-Tbps switching capacity
Typical operating power 626W
Maximum power 1240W
Typical heat dissipation 2136 BTU/hr
Maximum heat dissipation 4231 BTU/hr
Hardware tables and scalability
Number of MAC addresses 120K
Number of IPv4/IPv6 unicast routes 440K / 360K
Number of IPv4/IPv6 hosts 192K / 96K
Number of IPv4 multicast routes Up to 96K with 8K groups
Number of VLANS 4K
Number of ACL entries 3.5K ingress and 1.5K egress
Number of spanning-tree instances

Rapid Spanning Tree Protocol (RSTP): 123

Multiple Spanning Tree (MST) Protocol: 64

Number of EtherChannels

24

Number of ports per EtherChannel

24

Buffer size

70 Mb

Boot flash memory

128 GB

Latency

370 nsec

Power
Number of power supplies 2 (redundant)
Power supply types AC (forward and reversed airflow)
Input voltage 100 to 240 VAC
Frequency 50 to 60 Hz
Power supply efficiency 89 to 91% at 220V
Cooling

Forward and reversed airflow schemes

-  Forward airflow: Port-side intake (air enters through ports and exits through fan tray and power supplies)
-  Reversed airflow: Port-side exhaust (air enters through fan tray and power supplies and exits through ports)

Six individual, hot-swappable fans (5+1 redundant)

Environment
Dimensions (height x width x depth) 1.75 x 17.29 x 25.4 in. (4.44 x 43.91 x 64.51cm)
Weight

13.6 Kg

Operating temperature

32 to 104° F (0 to 40°C)

Storage temperature

-40 to 158° F (-40 to 70°C)

Relative humidity

5 to 95% non-condensing

Altitude (operating)

Designed to meet: -500 ft to 13,123 ft

Altitude (non-operating)

-1000 ft to 30,000 ft

Safety and EMC
Regulatory compliance Products should comply with CE Markings per directives 2004/108/EC and 2006/95/EC
Safety
-  UL 60950-1 Second Edition
-  CAN/CSA-C22.2 No. 60950-1 Second Edition
-  EN 60950-1 Second Edition
-  IEC 60950-1 Second Edition
-  AS/NZS 60950-1
-  GB4943
EMC: Emissions
-  47CFR Part 15 (CFR 47) Class A
-  AS/NZS CISPR22 Class A
-  CISPR22 Class A
-  EN55022 Class A
-  ICES003 Class A
-  VCCI Class A
-  EN61000-3-2
-  EN61000-3-3
-  KN22 Class A
-  CNS13438 Class A
EMC: Immunity
-  EN55024
-  CISPR24
-  EN300386
-  KN24
RoHS
RoHS 5 compliant except for lead press-fit connectors

Các tính năng trên Switch Cisco N3K-C3432D-S

Description

Specifications

Layer 2

-  Layer 2 switch ports and VLAN trunks
-  IEEE 802.1Q VLAN encapsulation
-  Support for up to 4096 VLANs
-  Rapid Per-VLAN Spanning Tree Plus (PVRST+) (IEEE 802.1w compatible)
-  MSTP (IEEE 802.1s): 64 instances
-  Spanning Tree PortFast
-  Spanning Tree Root Guard
-  Spanning Tree Bridge Assurance
-  Cisco EtherChannel technology (up to 24 ports per EtherChannel)
-  LACP: IEEE 802.3ad, IEEE 802.1ax
-  Advanced PortChannel hashing based on layer 2, 3, and 4 information
-  Jumbo frames on all ports (up to 9216 bytes)
-  Link-level flow control (IEEE 802.3x)
-  vPC

Layer 3

-  Layer 3 interfaces: Routed ports on interfaces, Switch Virtual Interfaces (SVIs), PortChannels, and subinterfaces (total: 1024)
-  512-way equal-cost multipath (ECMP)
-  4096 ACL entries
-  Routing protocols: Static, RIPv2, EIGRP, OSPF, and BGP
-  HSRP and VRRP
-  ACL: Routed ACL with layer 3 and 4 options to match ingress and egress ACLs
-  VRF: VRF-Lite (IP VPN), VRF-aware unicast (BGP, OSPF, and RIP), and VRF‑aware multicast
-  VRF route leaking
-  Jumbo frame support (up to 9216 bytes)

Multicast

-  Multicast: PIMv2, PIM Sparse Mode (PIM-SM), SSM, and BiDir (not supported at first customer ship [FCS])
-  Bootstrap router (BSR), Auto-RP, and Static RP
-  Internet Group Management Protocol (IGMP) Versions 2 and 3

Security

-  Ingress ACLs (standard and extended) on Ethernet
-  Standard and extended layer 3 to 4 ACLs include IPv4, Internet Control Message Protocol (ICMP), Transmission Control Protocol (TCP), and User Datagram Protocol (UDP)
-  VLAN-based ACLs (VACLs)
-  Port-based ACLs (PACLs)
-  ACLs on virtual terminals (VTYs)
-  Dynamic Host Configuration Protocol (DHCP) relay
-  Control Plane Policing (CoPP)

Cisco Nexus Data Broker

-  Topology support for tap and SPAN aggregation
-  Traffic load balancing to multiple monitoring tools
-  Packet truncation
-  Traffic filtering based on layer 1 through layer 4 header information
-  Traffic replication and forwarding to multiple monitoring tools
-  Robust Role-Based Access Control (RBAC)
-  Northbound Representational State Transfer (REST) API for all programmability support

Management

-  Power On Auto Provisioning (POAP)
-  Python scripting
-  Switch management using 10/100/1000-Mbps management or console ports
-  CLI-based console to provide detailed out-of-band management
-  In-band switch management
-  Locator and beacon LEDs
-  Configuration rollback
-  SSHv2
-  Telnet
-  AAA
-  AAA with RBAC
-  RADIUS
-  TACACS+
-  Syslog
-  Embedded packet analyzer
-  SNMP v1, v2, and v3
-  Enhanced SNMP MIB support
-  XML (NETCONF) support
-  Remote monitoring (RMON)
-  Advanced Encryption Standard (AES) for management traffic
-  Unified username and passwords across CLI and SNMP
-  Microsoft Challenge Handshake Authentication Protocol (MS-CHAP)
-  Digital certificates for management between switch and RADIUS server
-  Cisco Discovery Protocol (CDP) Versions 1 and 2
-  RBAC
-  SPAN on physical, PortChannel, and VLAN
-  ERSPAN Versions 2 and 3
-  Ingress and egress packet counters per interface
-  Network Time Protocol (NTP)
-  Cisco Online Health Management System (OHMS)
-  Comprehensive bootup diagnostic tests
-  Cisco Data Center Network Manager (DCNM)
-  Active buffer monitoring

Switch Cisco Nexus N3K-C3432D-S Option

Part number

Description

Chassis

NXA-FAN-35CFM-PE

Nexus Fan, Reverse airflow (port side exhaust)

NXA-FAN-35CFM-PI

Nexus Fan, Forward airflow (port side intake)

NXA-PAC-1500W-PE

Nexus 1500W AC Power Supply, Reverse airflow (port side exhaust)

NXA-PAC-1500W-PI

Nexus 1500W AC Power Supply, Forward airflow (port side intake)

Software Licenses

N3K-LAN3K9

Nexus 3432D-S Layer 3 LAN Enterprise License
