WS-X45-SUP8L-E Cisco Catalyst 4500E Series Supervisor 8L-E Card
Part Number : WS-X45-SUP8L-E
Spare Part Number : WS-X45-SUP8L-E=
Bảo hành : 12 tháng
Made In : Asia
Cisco Supervisor WS-X45-SUP8L-E là một cơ chế giám sát kết hợp giá / hiệu suất cấp doanh nghiệp được thiết kế để cung cấp băng thông lên tới 560 Gbps mỗi hệ thống kết nối với 4500E-Series Chassis. Cisco WS-X45-SUP8L-E cung cấp 48 Gbps mỗi khe với các tính năng tốt nhất trong lớp như Flexible NetFlow (FNF), tích hợp Wireshark, TrustSec và bảo mật MACSec và APIC-EM dẫn đến giảm tổng chi phí sở hữu (TCO) và bảo vệ đầu tư hàng đầu trong ngành.
Các tính năng này, cùng với 4 cổng SFP / SFP + uplinks, hỗ trợ lên tới 240 cổng PoE (PoE) PoE Plus (PoE+)và Universal PoE (UPOE), làm cho WS-X45-SUP8L-E trở thành giám sát viên hàng đầu của Cisco Catalyst Family. Cisco Supervisor WS-X45-SUP8L-E cũng được xây dựng với những triển khai tổng hợp về giá cả, giúp cho phép triển khai mạng Gigabit Ethernet rộng hơn và 10 Gigabit Ethernet với các chức năng của enterprise-class.
Supervisor WS-X45-SUP8L-E tạo điều kiện cho người dùng kinh nghiệm cho các doanh nghiệp, khu vực công, giữa khu vực, và các ứng dụng kinh doanh quan trọng đối với khách hàng.
Thông số kỹ thuật Cisco Supervisor WS-X45-SUP8L-E
| Performance and Scalability Features | |
| Centralized wired switching capacity | 560 Gbps |
| Wireless termination capacity | 48 Gbps |
| Throughput |
- 225 Mpps for IPv4
- 110 Mpps for IPv6
- 225 Mpps for L2 Bridging
|
| IPv4 routing entries | 64,000 |
| IPv6 routing entries | 32,000 |
| Multicast routes | 32,000 |
| CPU | Quad core; 1.8 GHz |
| CPU queues | 64 |
| Synchronous Dynamic RAM (SDRAM) | 4 GB |
| Nonvolatile RAM (NVRAM) | 2 GB |
| Security and QoS hardware entries | 64,000 |
| Dynamic Host Configuration Protocol (DHCP) Snooping entries | 12,000 |
| MAC addresses | 55,000 |
| Active VLANs | 4094 |
| Address Resolution Protocol (ARP) entries | 47,000 |
| Spanning Tree Protocol instances | 12,000 |
| Switched Virtual Interfaces (SVIs) | 4094 |
| Switched Port Analyzer (SPAN) | Maximum of 8 bidirectional sessions |
| Summary of Supervisor Engine 8L-E IPv6 Capabilities | |
| IPv6 support | Unicast and multicast forwarding done in hardware |
| IPv6 performance | 110 Mpps |
| IPv6 routing entries | 32,000 |
| Dynamic hardware route table allocations | Yes |
| MLD snooping for IPv6 | Yes, in hardware |
| Unicast Reverse Path Forwarding Version 6 (URPFv6): Strict mode | Yes, in hardware |
| Industry standards |
- Ethernet: IEEE 802.3 - 10 Gigabit Ethernet: IEEE 802.3ae - IEEE 802.1D Spanning Tree Protocol - IEEE 802.1w Rapid Reconfiguration of Spanning Tree - IEEE 802.1s Multiple VLAN Instances of Spanning Tree - IEEE 802.3ad Link Aggregation Control Protocol (LACP) - IEEE 802.1p CoS Prioritization - IEEE 802.1Q VLAN - IEEE 802.1X User Authentication - RMON I and II standards |
| Software requirements | Cisco IOS XE Software Release IOS XE 3.10 |
| Environmental conditions |
- Operating temperature: 32° to 104°F (0° to 40°C) - Storage temperature: -40° to 167°F (-40° to 75°C) - Relative humidity: 10 to 90 percent, noncondensing - Operating altitude: -197 to 9843 feet |
| Power and Mean Time Between Failures (MTBF) information |
- Active supervisor power: ◦ Wired mode: 311W ◦ Wireless mode: 400W - Standby supervisor power: ◦ Wired mode: 220W ◦ Wireless mode: 265W |
| Safety certifications |
- UL 60950-1
- CAN/CSA-C22.2 No. 60950-1
- EN 60950-1
- IEC 60950-1
- AS/NZS 60950.1
- IEEE 802.3
|
| Electromagnetic emissions certifications |
- 47 CFR Part 15
- CISPR22 Class A
- EN 300 386 V1.6.1
- EN 55022 Class A
- EN 55032 Class A
- CISPR 32 Class A
- EN61000-3-2
- EN61000-3-3
- ICES-003 Class A
- TCVN 7189 Class A
- V-3 Class A
- CISPR24
- EN 300 386
- EN55024
- TCVN 7317
- V-2 Class A
|
| Industry EMC, safety, and environmental standards |
- SR-3580 NEBS level 3 (GR-63-CORE issue 4, GR-1089-CORE issue 6)
- ETS 300 019-2-1, Class 1.2 Storage
- ETS 300 019-2-2, Class 2.3 Transportation
- ETS 300 019-2-3, Class 3.2 Stationary
|
| ROHS compliance |
- ROHS5
|
Cisco Supervisor WS-X45-SUP8L-E hỗ trợ các Line Cards sau
| WS-X4748-12X48U+E | Cisco Catalyst 4500E Series 48-port (RJ-45) line card with 12 Multigigabit ports and 36 10/100/1000 ports with 802.3af PoE, 802.3at PoE+, and Cisco UPOE |
| WS-X4748-UPOE+E | Cisco Catalyst 4500E Series, 48-port 802.3af PoE, 802.3at PoE+, and Cisco UPOE 10/100/1000 |
| WS-X4748-RJ45-E | Cisco Catalyst 4500E Series, 48-port 10/100/1000 (RJ-45) |
| WS-X4748-RJ45V+E | Cisco Catalyst 4500E Series, 48-port PoE 802.3at 10/100/1000 (RJ-45) |
| WS-X4712-SFP+E | Cisco Catalyst 4500E Series, 12-port 10 Gigabit Ethernet (SFP+) |
| WS-X4748-SFP-E | Cisco Catalyst 4500E Series 48-port Gigabit Ethernet fiber line card |
| WS-X4724-SFP-E | Cisco Catalyst 4500E Series 24-port Gigabit Ethernet fiber line card |
| WS-X4712-SFP-E | Cisco Catalyst 4500E Series 12-port Gigabit Ethernet fiber line card |
| WS-X4648-RJ45V+E | Cisco Catalyst 4500E Series, 48-port Premium PoE 10/100/1000 (RJ-45) |
| WS-X4648-RJ45-E | Cisco Catalyst 4500E Series, 48-port 10/100/1000 (RJ-45) |
| WS-X4640-CSFP-E | Cisco Catalyst 4500E Series, 40- and 80-port SFP/CSFP Gigabit Ethernet line card |
| WS-X4606-X2-E | Cisco Catalyst 4500E Series, 6-port 10 Gigabit Ethernet (X2) |
| WS-X4624-SFP-E | Cisco Catalyst 4500E Series, 24-port Gigabit Ethernet (SFP) |
| WS-X4612-SFP-E | Cisco Catalyst 4500E Series 12-port Gigabit Ethernet (SFP) |
| WS-X4148-FX-MT | Cisco Catalyst 4500 Fast Ethernet switching module, 48-port 100BASE-FX Multimode Fiber (MMF) |
| WS-X4148-RJ | Cisco Catalyst 4500 10/100 module, 48 ports (RJ-45). Not supported on VSS |
| WS-X4248-FE-SFP | Cisco Catalyst 4500 Fast Ethernet switching module, 48-port 100BASE-X (SFP) |
| WS-X4306-GB | Cisco Catalyst 4500 Gigabit Ethernet Module, 6 ports (GBIC) |
| WS-X4448-GB-SFP | Cisco Catalyst 4500 Gigabit Ethernet module, 48 ports 1000BASE-X (optional SFPs) |
Cisco Supervisor WS-X45-SUP8L-E sử dụng được cho các Switch Cisco sau
|
Product Number |
Description |
|
Cisco Catalyst E-Series 4503 switch (3-slot chassis), fan, no power supply |
|
|
Cisco Catalyst E-Series 4506 switch (6-slot chassis), fan, no power supply |
|
|
Cisco Catalyst E-Series 4507R+E switch (7-slot chassis), fan, no power supply, redundant supervisor capable |
|
|
Cisco Catalyst E-Series 4510R+E switch (10-slot chassis), fan, no power supply; redundant supervisor capable |
License sử dụng cho Cisco Supervisor WS-X45-SUP8L-E
|
C4500E-LB |
LAN BASE software license |
|
C4500E-IPB |
IP BASE software license |
|
C4500E-LIC= |
Base product ID for paper delivered software upgrade licenses |
|
C4500E-LB-IPB |
LAN BASE to IP BASE upgrade license (paper delivery) |
|
C4500E-LB-ES |
LAN BASE to Enterprise Services upgrade license (paper delivery) |
|
C4500E-IP-ES |
IP BASE to Enterprise Services upgrade license (paper delivery) |
|
C4500E-LIC-PAK |
Base product ID for paper delivered software licenses for spare Supervisor Engine 8L-E |
|
C4500E-IP-ES-S |
IP BASE to Enterprise Services upgrade license for spare Supervisor Engine 8L-E (paper delivery) |
|
C4500E-IPB-S |
IP BASE software license for spare Supervisor Engine 8L-E (paper delivery) |
|
L-C4500-LIC= |
Base product ID for electronically delivered software upgrade licenses |
|
L-C4500E-LB-IP |
LAN BASE to IP BASE upgrade license (electronically delivered) |
|
L-C4500E-IP-ES |
IP BASE to Enterprise Services upgrade license (electronically delivered) |
|
L-C4500E-LB-ES |
LAN BASE to Enterprise Services upgrade license (electronically delivered) |
|
SD-X45-2GB-E |
Cisco Catalyst 4500 2GB DRAM Memory for Sup 8L-E |
