Cambium C050900D025A Antenna
| Part Number |
:
|
| List Price |
: $
|
| Giá bán |
:
|
| Bảo hành |
:
|
| Made In |
:
|
| Stock |
:
|
Thông số kỹ thuật:
| What’s Included | Dual Horn MU-MIMO Antenna assembly Pole-mount bracket Four Cables for connecting antenna to the ePMP 3000 AP (RP-SMA to RP-SMA |
| Frequency Range | 5.1 GHz to 6.1 GHz |
| Gain | 12 dBi |
| 6 dB Beamwidth - Azimuth | 60 degrees |
| Polarization | 2X Horizontal, 2X Vertical |
| Port-to-Port Isolation | > 15 dB |
| Front-to-Back Ratio | 28 dB |
| Maximum Input Power | 5 W |
| Input Impedance | 50 ohms |
| Mounting Connectors | 4 x RP SMA |
| Mounting Hardware | Included for mounting to mast diameters 1.25” to 3.0” (30-75 mm) Hardware included to connect ePMP access point to back of antenna body |
| Weight | Antenna body with bracket: 9.4 lbs. (4.2 kg) As mounted with ePMP 3000 AP: 12.1 lbs. (5.5 kg) |
| Environmental | IP55 |
| Radome Material | UV Protected ABS |
| Operating Temp | -400C to 600C (-400F to 1400F) |
