FG-80E Firewall Fortinet FortiGate 80E series

Firewall Fortinet FortiGate FG-80E 14x GE RJ45 ports (1x DMZ, 1x Mgmt, 1x HA, 12x RJ45 ports) 2x Shared Media pairs RJ45/SFP managed FortiAPs 32/16

✓ Mã sản phẩm: FG-80E

✓ Tình trạng: Còn Hàng

Phụ kiện dùng cho Fortinet

FG-80E Datasheet

Các tùy chọn mua hàng FG-80E

FortiGate-80E

FG-80E 14 x GE RJ45 ports (including 1 x DMZ port, 1 x Mgmt port, 1 x HA port, 12 x switch ports), 2 x Shared Media pairs (Including 2 x GE RJ45 ports, 2 x SFP slots).

#FG-80E

List Price: Liên hệ

Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP)

FG-80E-BDL-950-12 FortiGate-80E Hardware plus 1 Year 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP)

#FG-80E-BDL-950-12

List Price: Liên hệ

FG-80E-BDL-950-36 FortiGate-80E Hardware plus 3 Year 24x7 FortiCare and FortiGuard Unified (UTM) Protection

#FG-80E-BDL-950-36

List Price: Liên hệ

FG-80E-BDL-950-60 FortiGate-80E Hardware plus 5 Year 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP)

#FG-80E-BDL-950-60

List Price: Liên hệ

Fortinet FortiGate-80E Hardware plus 1 Year ASE FortiCare and FortiGuard 360 Protection

FG-80E-BDL-817-12 FortiGate-80E Hardware plus 1 Year ASE FortiCare and FortiGuard 360 Protection

#FG-80E-BDL-817-12

List Price: Liên hệ

FG-80E-BDL-817-36 FortiGate-80E Hardware plus 3 Year ASE FortiCare and FortiGuard 360 Protection

#FG-80E-BDL-817-36

List Price: Liên hệ

FG-80E-BDL-817-60 FortiGate-80E Hardware plus 5 Year ASE FortiCare and FortiGuard 360 Protection

#FG-80E-BDL-817-60

List Price: Liên hệ

Fortinet FortiGate-80E Hardware plus 1 Year 24x7 FortiCare and FortiGuard Enterprise Protection

FG-80E-BDL-811-12 FortiGate-80E Hardware plus 1 Year 24x7 FortiCare and FortiGuard Enterprise Protection

#FG-80E-BDL-811-12

List Price: Liên hệ

FG-80E-BDL-811-36 FortiGate-80E Hardware plus 3 Year 24x7 FortiCare and FortiGuard Enterprise Protection

#FG-80E-BDL-811-36

List Price: Liên hệ

FG-80E-BDL-811-60 FortiGate-80E Hardware plus 5 Year 24x7 FortiCare and FortiGuard Enterprise Protection

#FG-80E-BDL-811-60

List Price: Liên hệ

Accessories

RM-FR-T11 Rack Mount Kit for FortiGate 80E / 81E

#RM-FR-T11

List Price: Liên hệ

SP-RACKTRAY-02 Rack mount tray for all FortiGate E series and F series desktop models and backward compatible with SP-RackTray-01. For list of compatible FortiGate products, visit Documentation website.

#SP-RACKTRAY-02

List Price: Liên hệ

SP-FG60E-PDC-5 Pack of 5 AC power adaptors for FG/FWF 60E/61E, 60F/61F, 80E/81E and 80F/81F

#SP-FG60E-PDC-5

List Price: Liên hệ

Firewall Fortinet FortiGate FG-80E

Fortigate Part Number	:
List Price	: $
Giá bán	:
Bảo hành	:
Made In	:
Stock	:

Firewall Fortinet FortiGate FG-80E cung cấp một giải pháp an ninh mạng tuyệt vời được thiết kế để bàn không quạt nhỏ gọn cho các văn phòng chi nhánh của doanh nghiệp và các doanh nghiệp vừa và nhỏ. Tường lửa FortiGate FG-80E bảo vệ chống lại các mối đe doạ trực tuyến bằng giải pháp SD-WAN an toàn hàng đầu trong ngành công nghiệp, giải pháp đơn giản, giá cả phải chăng và dễ triển khai.

FG-80E Datasheet

Thông số kỹ thuật Firewall FortiGate FG-80E

Interfaces and Modules
GE RJ45/SFP Shared Media Pairs	2
GE RJ45 DMZ/HA Ports	2
GE RJ45 Ports	12
Console Port	1
USB Port	1
System Performance and Capacity
Firewall Throughput (1518 / 512 / 64 byte UDP packets)	4 / 4 / 4 Gbps
Firewall Latency (64 byte, UDP)	3 μs
Firewall Throughput (Packet per Second)	6 Mpps
Concurrent Sessions (TCP)	1.3 Million
New Sessions/Sec (TCP)	30,000
Firewall Policies	5,000
IPsec VPN Throughput (512 byte)	2.5 Gbps
Gateway-to-Gateway IPsec VPN Tunnels	200
Client-to-Gateway IPsec VPN Tunnels	2,500
SSL-VPN Throughput	200 Mbps
Concurrent SSL-VPN Users	200
SSL Inspection Throughput (IPS, HTTP)	180 Mbps
Application Control Throughput	900 Mbps
CAPWAP Throughput (1444 byte, UDP)	2.2 Gbps
Virtual Domains (Default / Maximum)	10 / 10
Maximum Number of Switches Supported	8
Maximum Number of FortiAPs (Total / Tunnel Mode)	32 / 16
Maximum Number of FortiTokens	100
Maximum Number of Registered FortiClients	200
High Availability Configurations	Active / Active, Active / Passive, Clustering
System Performance — Optimal Traffic Mix
IPS Throughput	1.5 Gbps
System Performance — Enterprise Traffic Mix
IPS Throughput	450 Mbps
NGFW Throughput	360 Mbps
Threat Protection Throughput	250 Mbps
Dimensions and Power
Height x Width x Length (inches)	1.65 x 8.5 x 7
Height x Width x Length (mm)	42 x 216 x 178
Weight	2.65 lbs (1.2 kg)

Environment
Power Required	100–240V AC, 50–60 Hz
Maximum Current	100V AC / 0.65A, 240V AC / 0.29A
Total Available PoE Power Budget	N/A
Power Consumption (Average / Maximum)	20 W / 70 W
Heat Dissipation	238.85 BTU/h
Operating Temperature	32–104°F (0–40°C)
Storage Temperature	-31–158°F (-35–70°C)
Humidity	10–90% non-condensing
Noise Level	Fanless 0 dBA
Operating Altitude	Up to 16,404 ft (5,000 m)
Compliance	FCC Part 15B, Class B, CE, RCM, VCCI, UL/cUL, CB, BSMI
Certifications	ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN
