| Interfaces and Modules |
| Hardware Accelerated 10 GE SFP+ / GE SFP Slots |
2 |
| Hardware Accelerated GE SFP Slots |
16 |
| Hardware Accelerated GE RJ45 Ports |
16 |
| GE RJ45 Management / HA Ports |
2 |
| USB Ports (Client / Server) |
1/2 |
| Console Port |
1 |
| Internal Storage |
256 GB |
| Included Transceivers |
0 |
| System Performance and Capacity |
| Firewall Throughput (1518 / 512 / 64 byte, UDP) |
52 / 52 / 33 Gbps |
| Firewall Latency (64 byte, UDP) |
3 μs |
| Firewall Throughput (Packet per Second) |
49.5 Mpps |
| Concurrent Sessions (TCP) |
11 Million |
| New Sessions/Sec (TCP) |
280,000 |
| Firewall Policies |
10,000 |
| IPsec VPN Throughput (512 byte) |
25 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2000 |
| Client-to-Gateway IPsec VPN Tunnels |
20,000 |
| SSL-VPN Throughput |
3.6 Gbps |
| Concurrent SSL-VPN Users |
10,000 |
| SSL Inspection Throughput (IPS, HTTP) |
4 Gbps |
| Application Control Throughput (HTTP 64K) |
10 Gbps |
| CAPWAP Throughput (1444 byte, UDP) |
11 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of Switches Supported |
64 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
1024 / 512 |
| Maximum Number of FortiTokens |
1,000 |
| Maximum Number of Registered FortiClients |
2,000 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
| System Performance — Optimal Traffic Mix |
| IPS Throughput |
8 Gbps |
| System Performance — Enterprise Traffic Mix |
| IPS Throughput |
4.2 Gbps |
| NGFW Throughput |
4 Gbps |
| Threat Protection Throughput |
3 Gbps |
| Dimensions and Power |
| Height x Width x Length (inches) |
1.75 x 17.22 x 18.24 |
| Height x Width x Length (mm) |
44.45 x 437.5 x 463.2 |
| Weight |
20.24 lbs (9.18 kg) |
| Form Factor |
1 RU |
| AC Power Supply |
100–240V AC, 60–50 Hz, 300 W Redundant |
| DC Power Supply |
- |
