| Hardware Specifications |
| Hardware Accelerated GE WAN Port |
1 |
| Hardware Accelerated GE RJ45 Ports |
2 |
| Hardware Accelerated GE RJ45 FortiLink Port (Default) |
1 |
| USB Ports |
- |
| Console Port (RJ45) |
1 |
| Trusted Platform Module (TPM) |
Yes |
| Bluetooth Low Energy (BLE) |
- |
| Wireless Interface |
- |
| System Performance - Enterprise Traffic Mix |
| IPS Throughput |
800 Mbps |
| NGFW Throughput |
570 Mbps |
| Threat Protection Throughput |
500 Mbps |
| System Performance |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
4/ 4/ 3.9 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) |
4/ 4/ 3.9 Gbps |
| Firewall Latency (64 byte UDP packets) |
2.87 μs |
| Firewall Throughput (Packets Per Second) |
5.85 Mpps |
| Concurrent Sessions (TCP) |
600,000 |
| New Sessions/Second (TCP) |
30,000 |
| Firewall Policies |
2,000 |
| IPsec VPN Throughput (512 byte) |
3.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
200 |
| Client-to-Gateway IPsec VPN Tunnels |
250 |
| Concurrent SSL-VPN Users (Tunnel Mode) |
- |
| SSL-VPN Throughput |
- |
| SSL Inspection Throughput (IPS, avg. HTTPS) |
400 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
260 |
| SSL Inspection Concurrent Sessions (IPS, avg. HTTPS) |
55,000 |
| Application Control Throughput (HTTP 64K) |
830 Mbps |
| CAPWAP Throughput (HTTP 64K) |
TBA Gbps |
| Virtual Domains (Default/Maximum) |
Not Supported |
| Maximum Number of FortiSwitches Supported |
8 |
| Maximum Number of FortiAPs (Total/Tunnel Mode) |
16/8 |
| Maximum Number of FortiTokens |
500 |
| High Availability Configurations |
Active-Passive, Active-Active |
| Dimensions |
| Height x Width x Length (inches) |
1.6 x 5.6 x 6.3 |
| Height x Width x Length (mm) |
40.5 x 142 x 160 |
| Weight |
1.3 lbs (0.6 kg) |
| Rack Mount Type |
NA |
| Wall Mountable |
Optional |
| Form Factor (supports EIA/non‑EIA standards) |
Desktop |
| Operating Environment and Certifications |
| Power Rating |
12VDC, 2A |
| Power Source |
Powered by external DC power adapter 100-240V AC, 50/60 Hz |
| Maximum Current |
100V/0.11A, 240V/0.055A |
| Power Consumption (Average/Maximum) |
6.8 W / 8.2 W |
| Heat Dissipation |
28 BTU/hr |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Storage Temperature |
-31°F to 158°F (-35°C to 70°C) |
| Humidity |
20% to 90% non-condensing |
| Noise Level |
N/A |
| Operating Altitude |
10,000 ft (3048 m) |
| Compliance |
FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA |
| Certifications |
USGv6/IPv6 |
