| Hardware |
| Hardware Type |
Outdoor IP67 rated, status LEDs, gore vent for pressure equalization |
| Number of Radios |
2 |
| Number of Antennas |
4 external N-Type |
| Peak Antenna Gain |
3.5 dBi for 2.4 GHz, 6 dBi for 5 GHz |
| Frequency Bands (GHz) |
2.400–2.4835, 5.150–5.250, 5.250–5.350, 5.470–5.725, 5.725–5.850 |
| Frequency of Radio 1 |
2.4 GHz b/g/n |
| Frequency of Radio 2 |
5 GHz a/n/ac |
| Maximum Data Rate |
Radio 1: Up to 300 Mbps, Radio 2: Up to 867 Mbps |
| Tx/Rx Streams |
2x2 MIMO with 2 spatial streams |
| Ethernet Ports |
1x GE RJ45 |
| USB Port |
- |
| Serial Console Port |
- |
| Power over Ethernet (PoE) |
IEEE 802.3at or included PoE injector |
| WME Multimedia Extensions |
Yes (4 priority queues for voice, video, data and background traffic |
| Simultaneous SSIDs |
16 (14 if background scanning enabled) |
| EAP Type(s) |
EAP-TLS, EAP-TTLS/MSCHAPv2, EAPv0/EAP-MSCHAPv2, PEAPv1/EAP-GTC EAP-SIM, EAP-AKA, EAP-FAST |
| User/Device Authentication |
WPA™ and WPA2™ with 802.1x or Preshared key, WEP and Web Captive Portal, MAC blacklist & whitelist |
| Maximum Tx Power |
26 dBm (398 mW) |
| Physical Security |
Concrete and pole mount |
| Mean Time Between Failures |
> 7 years |
| IEEE Specifications |
802.11a, 802.11b, 802.11e, 802.11g, 802.11h, 802.11i, 802.11j, 802.11k, 802.11n, 802.11r, 802.11v, 802.1x, 802.3af, 802.11ac |
| 802.11ac 80 MHz Channel |
Yes |
| Mounting Options |
Wall or pole |
| Included Accessories |
PoE injector with AC power adapter, pole mount kit, wall mount kit, grounding cable, surge protector (GPI-SGPT)**, 4x dipole antennas |
| FortiPresence Capable |
Yes |
| 802.11n Features |
20 MHz and 40 MHz High-Throughput (HT) Support
Increased maximum frame transmission by incorporating A-MPDU and A-MSDU Packet Aggregation
Conserve power via Dynamic MIMO power save |
| Advanced 802.11n to enhance rate-over-range including: |
Low-density parity check (LDPC) encoding
Maximum likelihood demodulation (MLD)
Maximum Ratio Combining (MRC) for improved receiver performance |
| Reg Domain |
Vietnam, Thailand |
| Wireless Monitoring Capabilities |
| Frequencies scanned |
2.4 and 5 GHz |
| Background scan with client access on 2.4 and 5 GHz |
Yes |
| Full-time scan as dedicated monitor |
Yes |
| Full-time scan with client access on 5G GHz |
No in AP mode |
| Dimensions |
| Length x Width x Height |
9.8 x 8.7 x 2.1 inches (249 x 220 x 53 mm) |
| Weight |
3.68 lbs (1.67 kg) |
| Package (shipping) Weight |
9.1 lbs (4.31 kg) |
| Environment |
| Power Supply |
Proprietary PoE Injector Adapter Input: 100–240V AC, 50–60 Hz |
| Power Consumption (Avg.) |
16 W |
| Power Consumption (Max.) |
18.4 W |
| Humidity |
5–90% non condensing |
| Operating Temperature |
-40–140°F (-40–60°C) |
| Storage Temperature |
-40–158°F (-40–70°C) |
| Directives |
Low Voltage Directive • RoHS |
| Certifications |
| WiFi Alliance Certified |
Yes |
| DFS Certified for Europe |
Yes |
